DIGITAL CAMERA

FinePix S5100/
S5500/
SERVICE MANUAL
US/CA/EU/EG/GE/AS/CH-Model
WARNING
THE COMPONENTS IDENTIFIED BY THE MARK "
" ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY.
PLEASE REPLACE ONLY BY THE COMPONENTS SPECIFIED ON THE SCHEMATIC
DIAGRAM AND IN THE PARTS LIST.
IF YOU USE PARTS NOT SPECIFIED, IT MAY RESULT IN A FIRE AND AN
ELECTRICAL SHOCK.
Ref.No.:ZM00574-102
FUJI PHOTO FILM CO., LTD.
Printed in Japan 2005.11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FinePix S5100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FujiFilm FinePix S5100

Summary of Contents for FujiFilm FinePix S5100

  • Page 1: Digital Camera

    DIGITAL CAMERA FinePix S5100/ S5500/ SERVICE MANUAL US/CA/EU/EG/GE/AS/CH-Model WARNING THE COMPONENTS IDENTIFIED BY THE MARK “ ” ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR SAFETY. PLEASE REPLACE ONLY BY THE COMPONENTS SPECIFIED ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST.
  • Page 2 FinePix S5100/S5500 Service Manual SAFETY CHECK-OUT After correcting the original problem, perform the following safety check before return the product to the customer. 1. Check the area of your repair for unsoldered or poorly CAUTION: FOR CONTINUED soldered connections. Check the entire board surface PROTECTION AGAINST FIRE for solder splasher and bridges.

  • Page 3: Table Of Contents

    3-6-7. CCD FPC BLOCK ........29 6-1. Packing and Accessories ........81 3-6-8. IPS STROBE BLOCK ......30 6-1-1. US-model (FinePix S5100) ..... 81 3-6-9. MSW BLOCK .......... 31 6-1-2. CA-model (FinePix S5100) ..... 82 3-6-10. RSW BLOCK .......... 31 6-1-3.

  • Page 4: General

    FinePix S5100/S5500 Service Manual 1. General 1-1. Product specification System Model Digital camera FinePix S5100/FinePix S5500 Effective pixels 4.0 million pixels 1/2.7 inch square pixel CCD Number of total pixels: 4.23 million pixels Number of recorded pixels Still image: 2272 × 1704 pixels/1600 × 1200 pixels/1280 × 960 pixels/ 640 ×...
  • Page 5 16 MB, xD-Picture Card (1) Included with: Anti-static case (1) Shoulder strap (1) A/V cable for FinePix S5100/FinePix S5500 (1) approx. 1.5 m (4.9 ft.), plug (2.5 mm dia.) to pin-plug ×2 USB cable (mini-B) (1) Adapter ring AR-FX5A (1)
  • Page 6 1. General FinePix S5100/S5500 Service Manual Input/Output Terminals A/V output socket 2.5 mm dia. jack USB socket For file transfer to a PC DC input Socket for specified AC power adapter AC-5VH/AC-5VHS (sold separately) Standard number of available frames/recording time per xD-Picture Card The number of available shots, recording time or file size varies slightly depending on the subjects photographed.

  • Page 7: Explanation Of Terms

    Explanation of Terms AF/AE Lock On the FinePix S5100/FinePix S5500, pressing the shutter button down half way locks the focus and exposure settings (AF and AE lock). If you want to focus on a subject that is not centered in the frame or change the picture composition after the exposure is set, you can obtain good results by changing the composition after the AF and AE settings are locked.

  • Page 8: Names Of External Components

    1. General FinePix S5100/S5500 Service Manual 1-3. Names of External Components Focus mode selector lock switch Shutter button Power switch Continuous shooting button Exposure compensation button Focus mode selector button Mode dial W (Wide zoom) button Viewfinder (EVF) T (Tele zoom) button...
  • Page 9 1. General FinePix S5100/S5500 Service Manual Flash Flash pop-up button Flash control sensor Self-timer lamp Microphone Strap mount AF-Assist illuminator Slot cover xD-Picture Card slot Lens Speaker USB socket (mini-B) DC IN 5V (power input) socket A/V OUT (Audio / Visual output) socket...

  • Page 10: Disassembly

    2. Disassembly FinePix S5100/S5500 Service Manual 2. Disassembly 2-1. Names of internal Components CABI REAR ASSY MSW PWB ASSY KSW PWB ASSY EVF UNIT CONST LCD ASSY STROBE CONST RSW PWB ASSY BATTERY HOLDER ASSY LCD FRAME MAIN PWB ASSY...

  • Page 11: Removing The Cabi Rear Assy

    2. Disassembly FinePix S5100/S5500 Service Manual 2-2. Removing the CABI REAR ASSY [Disassembly] 1. Remove the three screws (M1.7 x 3.5). 2. Remove the two screws (M1.7 x 5). 3. Open the battery cover. 4. Raise the CABI REAR ASSY in the direction of the arrow.

  • Page 12: Removing The Lcd Assy

    2. Disassembly FinePix S5100/S5500 Service Manual 2-3. Removing the LCD ASSY [Disassembly] 1. Remove the two screws (M1.7 x 2.5). 2. Remove the connector. 3. Raise the LCD ASSY in the direction of the arrow. [Assembly] Assemble in the reverse order to disassembly.

  • Page 13: Removing The Evf Unit Const

    2. Disassembly FinePix S5100/S5500 Service Manual 2-4. Removing the EVF UNIT CONST [Disassembly] 1. Remove the connector. 2. Raise the EVF UNIT CONST in the direction of the arrow. 3. Remove the FFC. [Assembly] Assemble in the reverse order to disassembly.
  • Page 14 2. Disassembly FinePix S5100/S5500 Service Manual 4. Remove the FFC. [Assembly] Make the style of FFC and the lead wire as shown in figure below.

  • Page 15: Removing The Battery Holder Assy

    2. Disassembly FinePix S5100/S5500 Service Manual 2-6. Removing the BATTERY HOLDER ASSY [Disassembly] 1. Remove the connector. 2. Remove the screw (M1.7 x 8.0). 3. Remove the BATTERY HOLDER ASSY in the direction of the arrow. [Assembly] Set the switch lever to the off position when assembling.

  • Page 16: Removing The Dcst Pwb Assy

    2. Disassembly FinePix S5100/S5500 Service Manual 2-7. Removing the DCST PWB ASSY [Disassembly] 1. Remove the three screws (M1.7 x 2.5). 2. Remove the FFC. 3. Remove the two connectors. 4. Remove the DCST PWB ASSY in the direction of the arrow.

  • Page 17: Removing The Strobe Const

    2. Disassembly FinePix S5100/S5500 Service Manual 2-9. Removing the STROBE CONST [Disassembly] 1. Remove the ST-BUTTON. 2. Remove the screw (M1.7 x 5.5). 3. Remove the connector. 4. Remove in the STROBE CONST direction of the arrow. [Assembly] Make read-wire a style as shown in the figure below.

  • Page 18: Removing The Af Frame Assy

    2. Disassembly FinePix S5100/S5500 Service Manual 2-10. Removing the AF FRAME ASSY [Disassembly] 1. Remove two screws. 2. Remove the AF FRAME ASSY in the direction of the arrow. [Assembly] Execute the AF-Assist Light Adjustment after assembling.

  • Page 19: Schematics

    3. Schematics FinePix S5100/S5500 Service Manual 3. Schematics 3-1. Cautions <Cautions when replacing parts> • Do not reuse removed parts. Always use new parts. • Note that the negative side of tantalum condensers is readily damaged by heat. • Except for chemical condensers and tantalum condensers, voltage is not displayed on condensers with a voltage resistance of 50V or less.

  • Page 20: Description Of Main Block Functions

    3. Schematics FinePix S5100/S5500 Service Manual 3-3. Description of Main Block Functions 3-3-1. Technical Overview CCD signal processing/Camera circuit section Analog signals output from the 1/1.7 type square pixels CCD (IC701), with an effective pixel count of 4.0 mega-pixels, undergo false color compensation processing, adaptive interpolation processing, amplification (AGC) and signal mixing inside the CCD signal processing IC “AFE (IC103)”...

  • Page 21: Block Diagram

    3. Schematics FinePix S5100/S5500 Service Manual 3-4. Block Diagram UCS2 MAIN PWB IC201 LIBRA (T8K15BXB) LED_ST 3.3V (I/O), 2.5V, 1.5V Operation xD Card AF ASSIST LED Slot xD Card (20PIN) VSUB_CNT IBFC AFE_CS IC103 AUTO ANALOG DEVICES AFE Partner Chip...

  • Page 22: Overall Connection Diagram

    3. Schematics FinePix S5100/S5500 Service Manual 3-5. Overall connection Diagram LCD UNIT EVF UNIT AF LED LCD FPC EVF FPC 1 2 3 4 5 6 7 8 11 12 13 14 15 16 17 18 21 22 23 24...

  • Page 23: Circuit Diagrams

    3. Schematics FinePix S5100/S5500 Service Manual 3-6. Circuit Diagrams 3-6-1. CAM BLOCK...

  • Page 24: Dcdc Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-2. DCDC BLOCK...

  • Page 25: Ksw Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-3. KSW BLOCK...

  • Page 26: Lcd Evf Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-4. LCD EVF BLOCK...

  • Page 27: Motor Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-5. MOTOR BLOCK...

  • Page 28: Process Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-6. PROCESS BLOCK...

  • Page 29: Ccd Fpc Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-7. CCD FPC BLOCK...

  • Page 30: Ips Strobe Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-8. IPS STROBE BLOCK...

  • Page 31: Msw Block

    3. Schematics FinePix S5100/S5500 Service Manual 3-6-9. MSW BLOCK 3-6-10. RSW BLOCK...

  • Page 32: Mounted Parts Diagrams

    3. Schematics FinePix S5100/S5500 Service Manual 3-7. Mounted Parts Diagrams 3-7-1. DCST PWB ASSY <SIDE A>...
  • Page 33 3. Schematics FinePix S5100/S5500 Service Manual <SIDE B>...

  • Page 34: Main Pwb Assy

    3. Schematics FinePix S5100/S5500 Service Manual 3-7-2. MAIN PWB ASSY <SIDE A>...
  • Page 35 3. Schematics FinePix S5100/S5500 Service Manual <SIDE B>...

  • Page 36: Ksw Fpc Assy

    3. Schematics FinePix S5100/S5500 Service Manual 3-7-3. KSW FPC ASSY <SIDE A>...
  • Page 37 3. Schematics FinePix S5100/S5500 Service Manual <SIDE B>...

  • Page 38: Msw Fpc Assy

    3. Schematics FinePix S5100/S5500 Service Manual 3-7-4. MSW FPC ASSY <SIDE A>...
  • Page 39 3. Schematics FinePix S5100/S5500 Service Manual <SIDE B>...

  • Page 40: Rsw Fpc Assy

    3. Schematics FinePix S5100/S5500 Service Manual 3-7-5. RSW FPC ASSY <SIDE A> <SIDE B>...

  • Page 41: Ccd Fpc Assy

    3. Schematics FinePix S5100/S5500 Service Manual 3-7-6. CCD FPC ASSY <SIDE A> <SIDE B>...

  • Page 42: Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4. Adjustment 4-1. Important point Adjustment when Replacing Major Parts When replacing the MAIN PWB or LENS CONST or DCST PWB or STROBE or AF FRAME ASSY, adjust the items marked with an in the table below. (Other part replacements need not be adjusted. )

  • Page 43: Calibration Method Of Pattern Box

    4. Adjustment FinePix S5100/S5500 Service Manual 4-4. Calibration method of pattern box < Use the pattern box for CAMERA adjustment > Turn on the power supply in the pattern box. Afterwards, wait for about ten minutes so that the source of Pattern BOX light may stabilize.

  • Page 44: Installation Of Dsc Jig Driver

    4. Adjustment FinePix S5100/S5500 Service Manual <Step3> My Computer The folder named ZJ00840-100 can be made by defrosting without specifying anything <Fig. 4-5-2>. 3.5inch FD(A:) Then, copy the folder named FinePixS5100_5500_W in this (C:) folder in C drive <Fig. 4-5-3>.

  • Page 45: Initial Settings Of The Adjustment Software

    <Step 1> Double-click on the "FFW.exe" execute file of the adjustment software to open the "FFW Startup" screen (Fig. 4-6-1). FinePix S5100/5500_W Adjustment Software Start-up Screen Select [Start] from [Operate] on the FFW Toolbar —> The adjustment software starts <Fig. 4-6-1>...
  • Page 46 4. Adjustment FinePix S5100/S5500 Service Manual <Step 3> Select the "EVR & Comm" tab ([1] in Fig. 4-6-3) in the "Customize" dialog box that appears. Set the "EVR" items ([2] in Fig. 8) as follows. Item Details etc (-V2) Check...
  • Page 47 4. Adjustment FinePix S5100/S5500 Service Manual Cautions When Adjusting *1) FinePix S5100/S5500 cannot adjust the EVR data reading and writing.(Details are right tables.) Menu Command Details Operation Start Program start *2) End Setting returns the camera from the Jig mode to...

  • Page 48: Starting The Adjustment Software

    <Fig. 4-7-1> —> The [Cautions When Using the Adjustment Software] screen appears. <Step 3> Cautions When Using the FinePix S5100/5500 Adjustment Software 1. Adjust as follows after replacing parts. [F1]Battery [F4]CCD Defect Correction [F5]Camera [F6]AF [F7]Flash [F8]Firmware Download [F9]AF-Assist [F11]Video [F12]End Setting | –...
  • Page 49 4. Adjustment FinePix S5100/S5500 Service Manual <Step 4> FinePix S5100/5500 Jig Mode Setup Procedure 1). Open the battery cover. 2). Connect the Power Cable Jig with the camera. 3). Adjust the output current of the power supply to 3.0A or less.
  • Page 50 4. Adjustment FinePix S5100/S5500 Service Manual <Step 6> FinePix S5100/5500_W adjustment item select screen 0. [ R ] : Flash memory reset *Only use for when the MAIN PWB has been replaced. 1. [ F 9 ] : AF-Assist Light Adjustment 2.

  • Page 51: R] : Flash Memory Reset

    4. Adjustment FinePix S5100/S5500 Service Manual 4-8. [R] : Flash Memory Reset <Note> Only reset the flash memory when the MAIN PWB ASSY has been replaced. When the MAIN PWB ASSY has been replaced, always reset the flash memory before making any other adjustments.
  • Page 52 4. Adjustment FinePix S5100/S5500 Service Manual <Step 2> Flash memory reset (EVR) < Attention > When the MAIN PWB ASSY has been replaced, always reset the flash memory before making any other adjustments. Only reset the flash memory when the MAIN PWB ASSY has been replaced.

  • Page 53: F9] : Af-Assist Light Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-9. [F9] : AF-Assist Light Adjustment AF-Assist light Adjustment is required when the AF FRAME ASSY is removed. Preparation for AF-Assist Light adjustment (1) Output the image to TV with a camera that works normally.
  • Page 54 4. Adjustment FinePix S5100/S5500 Service Manual <Step 1> Select [F9] from the [Adjustment Items Select Screen (Fig. 4-7-5)]. (press [F9] on the PC keyboard) ---> The [AF-Assist light adjustment Preparation Screen (Fig. 4-9-1)] appears. AF-Assist Light Adjustment (1) Prepare it in the state that the power enters with cabinet R removed.
  • Page 55 4. Adjustment FinePix S5100/S5500 Service Manual ---> The [AF-Assist light adjustment Screen (Fig. 4-9-3)] appears. AF-Assist Light Adjustment (1) Darken the lighting of the chart. (2) Adjust the position of the camera so that the center of the Line chart is displayed in the center of TV.

  • Page 56: F5] : Camera Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-10. [F5] : CAMERA Adjustment (shutter adjustment, adjustment for reduced aperture sensitivity, ISO sensitivity adjustment, white balance adjustment, AE adjustment, offset level adjustment) <Setup for Camera Adjustment> Maximum 60mm Maximum 5mm Maximum50mm Centerline Pattern box Filter (LB140) <Step 1>...
  • Page 57 4. Adjustment FinePix S5100/S5500 Service Manual <Step 3> Shutter adjustment (1) Set the distance between the camera and pattern box. (2) The LB140 filter is not placed in front of the lens. When preparations are complete, press the [Enter] key.
  • Page 58 4. Adjustment FinePix S5100/S5500 Service Manual <Step 5> WB adjustment without filter (1) Set the distance between the camera and pattern box. (2) Remove the LB140 filter from front of the lens. When preparations are complete, press the [Enter] key.

  • Page 59: F4] : Ccd Defect Correction

    4. Adjustment FinePix S5100/S5500 Service Manual 4-11. [F4] : CCD Defect Correction < Setup for CCD defect correction Adjustment> Maximum 30mm Centerline Pattern box <Step 1> Select [F4] CCD Defect Correction on the [Adjustment Items Select] screen. —> The [CCD Defect Correction Preparation] screen appears.
  • Page 60 4. Adjustment FinePix S5100/S5500 Service Manual <Step 3> —> Write the adjustment data to the flash ROM when adjustment has been completed correctly. CCD Defect Correction Adjust the distance between the camera and pattern box. When preparations are complete, press the [Enter] key.

  • Page 61: F6] : Af Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-12. [F6] : AF Adjustment <Backlash adjustment/zoom reset adjustment/AF adjustment> Run the adjustment in accordance with the instructions on the screen. <Caution> (1) When adjusting the camera, measure distance from the front face of the camera lens.
  • Page 62 4. Adjustment FinePix S5100/S5500 Service Manual <Step 3> When preparations are complete, press the Enter key. AF Adjustment (1) Place the AF chart at a distance of 900+-5mm from the front face of the zoom lens. (2) Place the 865.12mm conversion lens at a distance of 30.64+-1mm from the front face of the lens.
  • Page 63 4. Adjustment FinePix S5100/S5500 Service Manual <Step 5> When preparations are complete, press the Enter key. AF-900mm Adjustment (1) Remove the conversion lens. (2) Adjust the position of the camera so that the center of the AF chart is displayed in the camera LCD.

  • Page 64: F1] : Battery Voltage Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-13. [F1] : Battery Voltage Adjustment <Setup for Flash Adjustment> (1) When adjusting the battery voltage, supply power (5V) to the camera from the [Power Cable Jig] before setting the jig mode. (2) Always measure input voltage in the vicinity of the DC IN terminal.
  • Page 65 4. Adjustment FinePix S5100/S5500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. Battery Voltage Adjustment <Preparations> 1. Check that the Power Cable Jig and the camera are connected. *If not, return to the Jig Mode Setup screen, and connect the Power Cable Jig and the camera.
  • Page 66 4. Adjustment FinePix S5100/S5500 Service Manual <Step 4> Battery Voltage Adjustment (1) Supply 4.34V (+0.02V/-0.00V). When preparations are complete, press the [Enter] key. Result= (2) Supply 3.94V (+0.02V/-0.00V). When preparations are complete, press the [Enter] key. <Fig. 4-13-3> —> The [5.00V Input] screen appears.
  • Page 67 4. Adjustment FinePix S5100/S5500 Service Manual <Step 6> The BATTERY adjustment is completed. Press the [Enter] key to return to the Adjustment Item selection Screen. <Fig. 4-13-5>...

  • Page 68: F7] : Flash Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-14. [F7] : Flash Adjustment <Setup for Flash Adjustment> (1) As flash adjustment is readily affected by external light, ensure that the vicinity of the gray chart is very dark. (2) Ensure that distance is measured from the front of the camera during flash adjustment.
  • Page 69 4. Adjustment FinePix S5100/S5500 Service Manual <Step 3> Flash Adjustment (1) Adjust brightness so that the periphery of the gray chart is as dark as possible. (2) Adjust the camera so that the entire chart is shown on the LCD monitor.

  • Page 70: F11] : Video Adjustment

    4. Adjustment FinePix S5100/S5500 Service Manual 4-15. [F11] : Video Adjustment <Setup for Video Adjustment> (1) Set up the PCI-2746C board in the computer as explained in the instructions for the video adjustment jig. (2) If the waveform of the brightness signal (Y) or color signal (C) does not appear in the “WAVE No. 0” window during adjustments, check the connections of the video adjustment jig.
  • Page 71 4. Adjustment FinePix S5100/S5500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. VIDEO Adjustment < VIDEO Adjustment Preparations > (1) Connect the camera and video adj. jig with the video cable. (2) Confirm Video jig is connected with the video cable.

  • Page 72: F8] : Firmware Download

    4. Adjustment FinePix S5100/S5500 Service Manual 4-16. [F8] : Firmware Download Attention : When the download of the firmware is needed, FUJI SERVICE BULLETIN is contacted from FTYO/QA. Till then, disregard this item. <Setup for Firmware Download> FinePix S5100/S5500 to USB Connector to DC JACK <Step 1>...
  • Page 73 4. Adjustment FinePix S5100/S5500 Service Manual <Step 2> Run the adjustment in accordance with the instructions on the screen. Firmware Download LED lights to orange while downloading the firmware. Do not turn off the power while downloading the firmware. c:\FinePixS5100_5500_W\Firm_1_28\SU580RSC1_28.bin Press the ENTER Key to start download.

  • Page 74: F12] : End Setting

    3. USB ID write details 1) USB ID write requires that the USB device (in this case FinePix S5100/S5500) be unique throughout the world. For this reason, each device has a unique ID as determined by the USB standard. If multiple devices with the same USB ID are connected to a single PC, the PC will be unable to identify each USB device, thus preventing operation.
  • Page 75 4. Adjustment FinePix S5100/S5500 Service Manual <Step 1> Select [F12] End Setting on the [Adjustment Items Select] screen. —> The [End Setting Description] screen appears. <Step 2> Run the adjustment in accordance with the instructions on the screen. End Setting...
  • Page 76 4. Adjustment FinePix S5100/S5500 Service Manual <Step 4> Destination setting The destination is selected from an undermentioned list, according to third character from left side of the serial number. The third character <B> FinePix S5100 US/CA-model A to H,J,K <C> FinePix S5500 EU/EG/GE/AS-model L to N,P to V Selected FinePix S5100 US/CA-model.
  • Page 77 <Step 6> USB ID Selected USA. Press the [Enter] key! <Fig. 4-17-5> —> The [FinePix S5100/S5500 Adjustment End] screen appears. <Step 7> FinePix S5100/5500 Adjustment completed. 1) Remove USB cable from the camera. 2) Press the [Enter] key. --> The adjustment software returns to the Jig mode setup screen after press the [Enter] key.

  • Page 78: Inspection

    5. Inspection FinePix S5100/S5500 Service Manual 5. Inspection 5-1. Required Measuring Equipment Measuring equipment Remarks Power supply AC adapter (AC-5V), Regurated power supply Digital voltmeter For general use Ammeter For general use (able to measure 1mA or less) Power Cable Jig...

  • Page 79: Inspection And Factory Settings

    5. Inspection FinePix S5100/S5500 Service Manual 5-3. Inspection and Factory Settings Sequemnce Item Mode Preparations for adjustment Method of adjustment Measuring Measurement points (measurement points, subject, other) (VRs, waveforms, required values) equipment and jigs (VRs, positions) Check appearance Visual check of camera No dents exterior of camera.
  • Page 80 5. Inspection FinePix S5100/S5500 Service Manual Sequemnce Item Mode Preparations for adjustment Method of adjustment Measuring Measurement points (measurement points, subject, other) (VRs, waveforms, required values) equipment and jigs (VRs, positions) Battery low check Movie (1) Connect Power Cable Jig...

  • Page 81: Parts List

    6. Parts List FinePix S5100/S5500 Service Manual 6. Parts List 6-1. Packing and Accessories 6-1-1. US-model (FinePix S5100) A112 A114 A115 A118 A103 A119 A121 A111 A122 A104 A120 A105 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No.

  • Page 82: Ca-Model (Finepix S5100)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-2. CA-model (FinePix S5100) A112 A114 A115 A103 A120 A121 A111 A118 A104 A119 A105 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No. Parts No. Description Comment Ref No.

  • Page 83: Eu-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-3. EU-model (FinePix S5500) A112 A114 A115 A121 A103 A122 A123 A124 A111 A118 A119 A104 A105 A120 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No. Parts No.

  • Page 84: Eg-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-4. EG-model (FinePix S5500) A112 A114 A115 A103 A118 A120 A111 A119 A104 A105 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No. Parts No. Description Comment A101 FZ05990-100...

  • Page 85: Ge-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-5. GE-model (FinePix S5500) A112 A115 A114 A103 A119 A111 A118 A104 A105 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No. Parts No. Description Comment A101 FZ05990-100 UNITARY BOX WE...

  • Page 86: As-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-6. AS-model (FinePix S5500) A112 A115 A114 A103 A119 A111 A118 A104 A105 A117/ A106 A117B A116 A101 A113 A109 A108 A102 A110 A107 Ref No. Parts No. Description Comment A101 FZ05990-100 UNITARY BOX WE...

  • Page 87: Ch-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-1-7. CH-model (FinePix S5500) Revised: 17. Jan. 2005 A112 A114 A115 A103 A111 A113 A104 A105 A106 A116 A101 A109 A108 A102 A110 A107 Ref No. Parts No. Description Comment A101 FZ05990-300 UNITARY BOX CH...

  • Page 88: Cabi Front Block

    6. Parts List FinePix S5100/S5500 Service Manual 6-2. Cabi Front block 6-2-1. US/CA-model (FinePix S5100) M217 M216 M218 M212 M224 M215 M214 M211 M209 M210 M222 M221 M219 M213 M220 M206 M225 M226 M202 M201 M204 M207 M208 M203 M223/...

  • Page 89: Eu/Eg/Ge/As-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-2-2. EU/EG/GE/AS-model (FinePix S5500) M217 M216 M218 M212 M224 M215 M214 M211 M209 M210 M222 M221 M219 M213 M220 M206 M225 M226 M202 M201 M204 M207 M208 M203 M223/ M223B M205 Ref No.

  • Page 90: Ch-Model (Finepix S5500)

    6. Parts List FinePix S5100/S5500 Service Manual 6-2-3. CH-model (FinePix S5500) Revised: 17. Jan. 2005 M217 M216 M218 M212 M224 M215 M214 M211 M209 M210 M222 M221 M219 M213 M220 M206 M225 M226 M202 M201 M204 M207 M208 M203 M223 M205 Ref No.

  • Page 91: Inner Block

    6. Parts List FinePix S5100/S5500 Service Manual 6-3. Inner block M324 K TAPE 1 M313 M329 M322 M316 M321 M318 M314 M301 M302 M304 M303 M319 M323 M310 M327 M332 M321 M317 M311 M332 M312 M326 M309 M306 M308 M320...

  • Page 92: Cabi Rear Block

    6. Parts List FinePix S5100/S5500 Service Manual 6-4. Cabi Rear block M407 M416 M417 M414 M410 M404 M405 M415 M405 M409 M403 M406 M408 M412 M411 M401 M402 M405 M413 M405 M418 Ref No. Parts No. Description Comment Ref No.

  • Page 93: Electrical Parts

    6. Parts List FinePix S5100/S5500 Service Manual 6-5. Electrical parts [NOTE] The components indicated by mark are critical for safety. * Due to standardization, replacement in the parts list may be different from When indicated parts by reference number, please include the parts list specified in the circuit or the components used on the set.

  • Page 94: Appendix

    7. Appendix FinePix S5100/S5500 Service Manual 7. Appendix 7-1. Function of display for Firmware Version The function to display the version is installed in FinePix S5100. The version the camera equipped with of the firmware can be displayed only by operating the main body of the camera.

  • Page 95: List Of Related Technical Updates Issued

    7. Appendix FinePix S5100/S5500 Service Manual 7-2. List of Related Technical Updates Issued To ensure that after-sales srevice is performed accuratety, keep a record here of the technical updates issued that cover this device. Technical Update No. Date Title Details/Other...
  • Page 96 FUJI PHOTO FILM CO., LTD. 26-30, Nishiazabu 2-chome, Minato-ku, Tokyo 106-8620, Japan.
