  • Page 2: Precautions

    Precautions The monitor may be damaged if placed too near a source of heat. Be aware of the location of radiators, cookers, open fires etc. Do not cover the slots and openings on the back or top of the cabinet as the monitor requires ventilation.
  • Page 3: Package Contents

    Package contents LCD Monitor Power Cord VGA Cable Audio Cable User Manual (CD) Quick Start Guide Installation instructions Assembling the Monitor 1. Position the monitor on top of the stand. 2. Connect the stand into the neck of the monitor along the track.
  • Page 4: Detaching The Monitor

    Detaching the Monitor If you need to repackage the monitor, please separate the monitor and base, and restore them to the carton. To detach the monitor: 1. Unplug the AC power cord to make sure the power is off. 2. Pull the 4 hooks on bottom side of the base and hold. 3.
  • Page 5: Connecting The Devices

    Connecting the Devices Caution: Make sure that the computer and the monitor are both disconnected from the power supply. A U D IO IN AC IN D-SUB IN Audio Power Code Attach the monitor to the power cord which should then be inserted into a properly grounded electric socket.
  • Page 6: Adjusting Display Settings

    External Controls AUTO < MINUS > PLUS Function POWER Adjusting display settings AUTO < > MENU If OSD is active, press to exit a selection in OSD. If OSD is inactive, press and the monitor will automatically optimize the position, focus and clock of your display. If OSD is active, press to select or adjust OSD options.
  • Page 7: Osd Options

    Please refer to "External Controls" on Page 6. To adjust the OSD settings: 1. Press the MENU button to open the OSD menu. Press again to enter a selection of 10 functions on OSD. 2. Use the buttons marked < or >, to highlight a control, then adjust the control to the desired level.
  • Page 8 LANGUAGE: Select the OSD menu language from English, German, Spanish, Russian, Traditional Chinese, French, Italian, and Japanese. OSD SETTING: This changes the position of the OSD window on the screen and staying time. Auto Config: System runs auto-configuration. INFORMATION: This shows brief information on the screen. Reset: Recall to default settings.
  • Page 9: Troubleshooting

    Problems • Check to see if the power switch is in the ON position. Power LED is not • Ensure that the Power Cord is connected. • Check to see if the power switch is in the ON position. No Picture •...
  • Page 10: General Specifications

    Item LCD Panel Display Max resolution Pixel Pitch Color Brightness Contrast Ratio Response Time View Angle of Horizontal View Angle of Vertical External Controls Power Button Control Buttons OSD Function Contrast /Brightness Focus/Clock Position Color Language OSD setting Auto config Information Reset Exit...

This manual is also suitable for:

Al1914
