Screen Excellence RM2-T Installation Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Contents ...................................................................................................................................................2
Electric Screen Installation Instructions ..................................................................................................4
Wall Mount ..................................................................................................................... 4
Ceiling Mount ................................................................................................................. 5
MECHANICAL ADJUSMENTS IF NEEDED .................................................................. 13
WHOLE RECALIBRATION OF THE TENSIONING. ...................................................... 13
Troubleshooting .....................................................................................................................................13
Note 1): These screens are assembled in USA. All screws and nuts are in imperial standards.
Note2): Two persons are required to install the screen. Do not try to do it without the help of a
second person
RM2-T installation instructions
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RM2-T and is the answer not in the manual?

Questions and answers

Related Manuals for Screen Excellence RM2-T

Summary of Contents for Screen Excellence RM2-T

  • Page 1: Table Of Contents

    RM2-T installation instructions Contents ..............................2 Electric Screen Installation Instructions ....................4 Wall Mount ........................4 Ceiling Mount ......................... 5 MECHANICAL ADJUSMENTS IF NEEDED ..............13 NOTE: THIS SCREEN IS TENSIONED, AND THE STOP LIMITS SHOULD NOT BE USER ADJUSTABLE. MODIFYING THE LIMITS SETTING WOULD NECESSITATE A WHOLE RECALIBRATION OF THE TENSIONING.

  • Page 2: Contents

    Contents 1) Pull the inner box out of the outer box using the white plastic pull straps that are mounted to the inner box. Make sure you use both handles per side so they will adequately lift the approximately 50 to 70 pound load. Open the inner box (the straps will have to be peeled off) and you’ll see the bubble wrap top lining and a white box that contains the screen accessories.
  • Page 3 2) Slide off the screen case protective velvet bag and set aside.  Leave the internal, foam wrap on the screen. We taped it so that you can install the screen with this wrap on and avoid scratching up the case. ...

  • Page 4: Electric Screen Installation Instructions

    Electric Screen Installation Instructions Wall Mount 1) Look on the back side (since it's a wall mount) and you'll see the metal DIN rail that will mount to the wall. There are two screws fixing this into the case for shipment. Loosen these two screws to get the rail out and note how the French cleat design works.

  • Page 5: Ceiling Mount

    want to make sure it's free to drop before you let the screen surface go down. Getting that layer backwards-wound in the case is a disaster. 9) Connect the Mains supply ground and neutral to the green & yellow wire and to the blue wire of the motor, respectively.
  • Page 6 3) After the DIN rail is up and level, you can pick up the screen. Put your finger on the closest screw to your end so you can approximate the ~1.5" from the end of the DIN rail that the screw will engage. 4) Approach the DIN rail with the screen case tilted down at a 30-40 degree angle.
  • Page 7 7) Remove the foam wrap off the case. 8) Note there are several pieces of tape and things that keep the materials where they should be. First, undo the blue Velcro straps you see on each end. These keep the weight bar happy during shipment, but must be taken off prior to operating the screen.
  • Page 8 15) If there is provided a remote control system, disconnect completely the rocker switch and connect the motor wires to the control system. See the corresponding chapter below.
  • Page 9 REMOTE CONTROLS Various types of remote controls can be supplied as an option: 1) RF remote control (Receiver + Transmitter) if this is the control option you have selected Screen up Stop Screen down...
  • Page 10 Receiver connections Ground Neutral Phase Ground Yellow/Green Neutral Blue Brown Black Antena 2) Basic IR control IR Transmitter. Note: Use the left buttons. IR Receiver. See wiring diagram below.
  • Page 11 3) Advanced IR remote control (Receiver+ Control box+ EYE sensor) if this is the control option you have selected RP60 Control box Flexible EYE sensor Transmitter Alternatively, you can have the wall-mount EYE sensor on request 3) 12V trigger if this is the option you have selected RP 60 Control box LVT Bus...
  • Page 12 This device takes an optically isolated DC low voltage input commonly from a projector and turns it into a RP Bus command 4) RF control via RP box (suitable for upgrade or additional controls) if this is the option you have selected RP 60 Control box RF 433 receiver...

  • Page 13: Mechanical Adjusments If Needed

    Never consider the following indications as normal setup adjustments. Waves The RM2-T screen uses the Enlightor 4K woven material, which for acoustical transparency and fineness of video resolution is an advantage. The disadvantage is that the material doesn’t naturally stretch like a piece of plastic wrap, so balancing the tension forces across the screen is critical to not having stresses build up and cause waves.
  • Page 14 If you have horizontal wave patterns along the sides, then your vertical turnbuckles are too tight and they are lifting the bar. Loosen them up, and you’ll find the ideal tension is where the bottom black tabs are snug to the cable but still easily slid up or down with your finger.
