Summary of Contents for Onn ONA16AV008
- Page 1 PORTABLE DVD PLAYER VALUE PACK MODEL: ONA16AV008 PRODUCT GUIDE...
- Page 2 Important Safety instructions...
- Page 3 Important Safety instructions...
- Page 4 Important Safety instructions...
-
Page 5: Important Safety Instructions
Important Safety instructions FCC STATEMENT: Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 6: Product Overview
Product Overview Control panel operation MUTE SETUP 1. MUTE: Press to turn off the sound and press again to resume the sound. 2. SETUP: Press to enter DVD system setup menu and press again to exit. Up / Tune- button Down / Tune+ button Left / Fast rewind button Right / Fast forward button... - Page 7 Product Overview Earphone jack 12. Audio/video output jack 13. Power on/ off switch: Slide to ON position to power on Slide to OFF position to power off 14. DC IN jack 15 16 15. Charging Indicator 16. Power Indicator...
- Page 8 Charging the Unit The unit has a DC (DC 7.4 V), 1900 mAh Li-ion rechargeble battery. Recharge it by the supplied AC/DC Adaptor as follows: Connect the small plug on the supplied AC/DC Adaptor to the DC Connect the AC/DC Adaptor to the wall outlet having AC 100-240V 50/60Hz. During charging, the charging indicaror will stay lit.
-
Page 9: Connecting To Tv With Av Cable
Making Connections AV cable not included Video input jack ( yellow ) Audio left channel input jack ( white ) Audio right channel input jack ( red ) Connected to the TV... -
Page 10: Speaker Setup Page
System Setup In stop playback, press the SETUP button Speaker Setup Page the setting menu will appear on the screen. Use Direction buttons and ENTER button to access menu. General Setup Page - - General Setup Page - - TV Shape Wide Angle Mark OSD Lang... -
Page 11: Preference Page
System Setup Troubleshooting Preference Page 1 .Can not play discs (1). Check whether the disk is placed correctly or TV Type Ntsc clamped well. Audio (2). Should make the disc side which has label on Subtitle upside. Disc Menu Parental (4). -
Page 12: Specifications
Disc Maintainance Cleaning Discs outwards with a soft cloth. Always keep the disc clean. They may damage the disc. Storing Discs warping. Specifications AC/DC adapter Input 100-240V~, 50/ 60Hz, 0.5A Output DC 9V~12V/1A. Video Standard: PAL/NTSC/AUTO Audio Power AMP: W (RMS) X 2 Use temperature: 0- 40°C Play time(Lithium battery inside): About 240 mins... -
Page 13: Limited Product Warranty
LIMITED PRODUCT WARRANTY This quality product is warranted to be free from manufacturer’s defects in material and workman-ship, provided that the unit is used under the normal operating conditions intended by the manufacturer. Should you have any problem with this product, please and it is highly recommended to visit our website at www.curtisint.com before you take any other steps as we have additional copies of instruction manuals, operating manuals and trouble shooting tips on our website which gives you the answer on most of the...
