Limited Warranty
Limited Warranty
Products manufactured by Aritronix, Ltd are warranted by the company to the original consumer
purchaser to be free from defects in workmanship and materials. Should a product be found
defective, Aritronix shall repair or replace the product or any part of the product that Aritronix agrees
is defective without charge during the first 12 months from the date of original purchase if the
product is returned to Aritronix freight prepaid and accompanied by a copy of the purchase receipt.
This warranty does not apply to any product damaged by accident, physical or electrical misuse or
abuse, improper installation, alteration, any use contrary to its intended function, fire, flood,
unauthorized repair or any other acts of God.
Aritronix shall not be responsible for removal and/or reinstallation charges or theft of the motorcycle
or its contents or any incidental or consequential damages caused by any failure of the product to
function properly. Under no circumstances should this warranty or the product covered by warranty
be construed as an insurance policy against loss or damage of any kind.
Aritronix neither assumes nor authorizes any person or organization to make any warranties or assume
any liability in connection with the sale, installation, or use of this product.
This completes Aritronix warranty and no other warranty exists.
What should you do if you experience a problem with a Scorpio product?
First contact Aritronix, Ltd (Proof of purchase, installer and motorcycle information will be requested).
If after assistance from our trained staff it is determined that the Aritronix product may be faulty, then
you will be provided with detailed information on processing a warranty claim and instructions on
how to send the product into our repair office. All warranty claims must contain a return material
authorization (RMA). Aritronix will not accept any package that has not been approved for warranty
repair/exchange and been issued an RMA. Shipping charges may apply.
FCC Notice
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this device.
For technical assistance, please contact Aritronix:
www.scorpioalarms.com
support@aritronix.com
(800)428-0440
International
(480)951-1109
Aritronix Ltd
16055 N Dial Blvd B-10
Scottsdale, AZ 85260
Toll Free
SR-i800
Motorcycle Security System
INSTALLATION MANUAL
AND USER'S GUIDE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Scorpio SR-i800
Summary of Contents for Scorpio SR-i800
-
Page 1: Limited Warranty
Motorcycle Security System This completes Aritronix warranty and no other warranty exists. What should you do if you experience a problem with a Scorpio product? First contact Aritronix, Ltd (Proof of purchase, installer and motorcycle information will be requested). If after assistance from our trained staff it is determined that the Aritronix product may be faulty, then you will be provided with detailed information on processing a warranty claim and instructions on how to send the product into our repair office. -
Page 2: Table Of Contents
Troubleshooting Guide Table of Contents Installation Component List ---------------------------------------------------------------- Page 3 • • Planning The Installation ---------------------------------------------------- Page 3 • Mounting The Components ----------------------------------------------- Page 4 Color Codes --------------------------------------------------------------------- Page 5 • Connections --------------------------------------------------------------------- Page 5 • • Using the T-tap ------------------------------------------------------------------ Page 6 User’s Guide Standard Features ------------------------------------------------------------... -
Page 3: Standard Features
Perimeter Sensor (SN-5) Mounting the SN-5 Perimeter Sensor Standard Features The Perimeter Sensor uses high frequency microwave technology to detect mass density movement around the motorcycle. The signal can transmit through the seat, fiberglass, Ultra low power drain MCM • leather and plastic, but not metal. -
Page 4: Component List
Components List Alarm Triggers MCM (Main Control Module) 1. If the bike is shocked, the siren will sound for 5 seconds and the turn signal lights will flash. 2. If the bike is tilted, the siren will sound for 30 seconds and the turn signal lights will flash. 3. -
Page 5: Mounting The Components
Check the layout and construction of the motorcycle to decide where space is The SR-i800 can be manually armed and disarmed by using the button on the remote or available to place the components. automatically armed and disarmed by turning your ignition key on and off. When the Verify that no moving parts interfere with the components or their wires. -
Page 6: Perimeter Sensor (Sn-5)
Main Harness Note: Connect the (HAR-1) harness to the MCM only after installation is completed. If the optional factory connector kit is being used, please disregard this section of the instructions and refer to the instructions that were supplied with the factory connector kit. If the battery is to be removed, disconnect this connector first.
