Monessen Hearth MCUF42D-F Magnum Product Specifications

PRODUCT SPECIFICATIONS
MCUF42D-R/MCUF42D-F Magnum Vent Free Firebox
M I N I M U M H E A R T H D I M E N S I O N S
Front opening width: 38-1/2"
Front opening height: 26"
Rear wall width: 30-1/4"
Firebox depth: 16"
T E C H N I C A L I N F O R M A T I O N
Clearance to Fireplace: Zero
CSA Design Certified
F A C T O R Y I N S T A L L E D O P T I O N S
Refractory Herringbone firebrick (MCUF42D-R)
Cottage Clay firebrick (MCUF42D-F)
F I E L D I N S T A L L E D A C C E S S O R I E S
Curved Trim: Brass, Pewter, Black
Variable Thermostat Controlled Forced Air Blower (160cfm) - BLOTMC
Brass Hood
Wide Profile Brass Hood
Classic and Designer Facings
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product are subject to change without notice. © 2007 Monessen Hearth Systems Co.
www.monessenhearth.com
38"
53"
47 7/16
74 7/8"
38"
33 1/4"
20 1/2"
40"
42"
5 1/4"
26 1/8"
47 1/16"
47 7/16"
FRAMING DIM.
18 1/16"
25"
37 3/8"
8 1/4"
9 7/8"
16 3/8"
18"
2 1/2"
6"
37 1/2"
FRAMING DIM.
