VIDEO
11 COMPONENT SET
The COMPONENT SET function is very useful when setting up High Definition, Standard Definition and
I
' NTSC signal while changing the aspect ratio and moving the Horizontal Position.
I I
CONTRAST
4 IF 100%
BRIGHTNESS
4-1) 50%
COLOR
4-I) 50%
TINT
4---l
SHARPNESS q-1) 50%
RESET
ADVANCED
SETTINGS +
MENU IT0 MENU BAR TO QUIT 1 EXIT
I
I
ADVANCED SETTINGS
q
3 DYC
0 30 VIDEO DISC
IJ AUTO COLOR
COLOR TEMPERATURE
@COOL 0 WARM
+ COMPONENT SET
ENU IT0 MENU BAR TO QUIT 1 EXIT
CURSOR
+Fpv--3
0
CH
COMPONENT SET
COLOR SYSTEM
+ OHDTV OSDTV/DVD ONTSC
ASPECT RATIO
016:9 04:3
H POSITION
4-b
6
MENUITO MENU BAR TO QUIT 1 EXIT
Press CURSOR ) to select Color System (HDTV, SDTV/DVD, NTSC).
Press CURSOR v to change position.
Press CURSOR A or v to highlight then CURSOR b to select ASPECT RATIO (16 : 9, 4 : 3).
Press CURSOR v, k to highlight then CURSOR F to select H Position.
NOTE: Set up a Component Signal and switch to Video 2 by pressing the Input Button on the Remote Control when planning to use
the component set function.
COLOR SYSTEM
The COLOR SYSTEM function allows you to change tint and color coordinate for DTV Programs.
HDTV - High Definition Television - Use for High Vision Signal Y-PBPR from HDTV Set-Top Box.
SDTV/DVD - Standard Definition Television or Digitat Video Disc Y-CBCR such as DVD (Digital Video Disc Player).
NTSC - Basic U.S. Standard Norma! Signal Standardized by the National Television Standard Committee.
ASPECT RATIO
16 : 9 - Screen changes to 16 : 9 aspect ratio.
HDTV signal is normally 16 : 9 aspect ratio.
4 : 3 - Screen changes to 4 : 3 aspect ratio.
SDTV and NTSC signals are normally 4 : 3 aspect ratio.
H POSITION
This function allows you to adjust the Horizontal Position on DTV mode. This is convenient when using SET TOP BOX.
