- Page 1 Volkswagen Passat B8 Rear-view camera assembly manual v. 1.0. The bundle includes: 1 pcs camera built-in VW emblem 1 pcs drain pipe 1 pcs Plug&Play wire of 6,5m 1 pcs Coding manual www.carsystems.eu...
- Page 2 VW Passat B8 rear-view camera - Assembly manual Dismantle the rear trunk lid covering . Then loosen the locking tabs which are First remove the clamp holding warning indicated on the photo. triangle. After the covering is loosened remove VW Pull the beam through the right side as shown emblem, screw the rear-view camera and on the photo.
- Page 3 VW Passat B8 rear-view camera - Assembly manual Next connect the yellow wire in charge of rear light to the chip of internal lamp PIN number 7. (black and blue wire) Dismantle the front and rear right door sill in order to pull the beam through to the storage side.
- Page 4 VW Passat B8 rear-view camera - Assembly manual Connect wires for quadlock to the blue chip 8x0035447 Connect wire no. 1 to 12th socket in the chip. Connect wire no. 2 to 6th socket in the chip. PIN NR 6 PIN NR 6 PIN NR 12 PIN NR 12...
