SMJ DTHL1C Instruction Manual

Item No. DTHL1C
A. Functions
1. The Programmable Digital Timer (hereinafter refer as "Timer") can preset specific on/off time
of your home electrical appliances, e.g. using in coffee machine, lamps. It is ideal for energy
saving and home security.
2. The countdown function can switch on/off your appliance on your pre-set time and random
functions allows you to switch on and off the appliance in irregular time, it is not only ideal for
home automation, also prevent burglary during your absence.
3. The LCD displays program setting status and real time.
4. With maximum 98 on/off programs per week .
B. Diagram & Descriptions
No. Description
1 LCD Display
2 CLOCK Button
3 CD Button
4 RND Button
5 On/Off Button
6 SET Button
7
Button
▼－
8 Button
▲+
9 S Printing
10 R Button
11 Socket & Plug
Instruction Manual for
Programmable Digital Timer

Functions

Shows time and program setting.
- Return to real time display when in program setting
- Press and hold to interchange between 24 hours to 12 hours display
- press together with
Press the button to start/stop countdown program when it is in AUTO
status and when Timer is plugged into AC socket
Press the button to start/stop random program when it is in AUTO status
and Timer is plugged into AC socket
Change the setting mode to ON, ATUO or OFF. When press the button
each time, the horizontal line in the LCD moves to
ONAUTOOFF which were silk printed on the Timer
Press and hold to start setting time and week and to confirm setting
Press the button to reduce the time, week or program group
Press the button to increase the time, week or program group
Press CLOCK Button and
Summer Time. Time display adds one hour automatically and "S" are
shown on the LCD.
Press and hold to reset all the programs
Connect your appliance to the socket and plug the timer to the wall AC
socket to get power
Button to change to Summer Time
▼－
Button at the same time to change to
▼－
DTHL1C Page 1 of 5
