Installation and Operation Manual
UDC-5212 and DTD-5225
Digital Time/Date Display Clocks
Edition D
52XX MAN
Delivering the Moment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDC-5212 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Imagine UDC-5212

  • Page 1 Installation and Operation Manual UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Edition D 52XX MAN Delivering the Moment...
  • Page 2 This publication does not in any way warrant description accuracy or guarantee the use for the product to which it refers. Imagine Communications reserves the right, without notice to make such changes in equipment, design, specifications, components, or documentation as progress may warrant to improve the performance of the product.
  • Page 3 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual Edition D August 2006...
  • Page 5: Table Of Contents

    Overview ....................1 Introduction ....................2 Installation ....................3 General ....................3 Clock Mounting ................3 Rack Mounting .................3 Rear Panel ..................4 Control Modes ..................4 Operation ....................6 Clock Mode ..................6 Timecode Reader Mode ..............6 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 6 Timecode Generator Mode ............21 Brightness Adjustment ..............22 Clock Setting Controls ................23 Manual Time Setting ..............23 Local Offset Programming ............. 24 Specifications ..................25 Electrical ..................25 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 7 Contents Inputs and Outputs ................25 Time Base ..................25 Controls ...................26 Mechanical ..................26 Chapter 3: Supporting Information Clock Battery Replacement Procedure ..........27 5225DB Display Module ...............29 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 8 Contents UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 9: Preface

    UDC-5212 and DTD-5225 Digital Time/Date Display Clocks. Revision History Table P-1. Revision History of Manual Edition Date Comments December 1998 Full release August 2006 Manual reformatted and updated UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 10: Writing Conventions

    Obtaining Documents Product support documents can be viewed or downloaded from our Web site at www.broadcast.harris.com/leitch (go to Support> Documentation). Alternatively, contact your customer service representative to request a document. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 11: Unpacking/Shipping Information

    Ship products back to us for servicing prepaid and, if possible, in the original packaging material. If the product is still within the warranty period, we will return the product prepaid after servicing. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 12: Restriction On Hazardous Substances (Rohs) Compliance

    July 1, 2006 are exempt from the legislation. Equipment that complies with the EU directive will be marked with a RoHS-compliant emblem, as shown in Figure P-1. Figure P-1. RoHS Compliance Emblem viii UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 13: Waste From Electrical And Electronic Equipment (Weee) Compliance

    Equipment that complies with the EU directive will be marked with a WEEE-compliant emblem, as shown in Figure P-2. Figure P-2. WEEE Compliance Emblem UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 14: Safety

    High voltage is present. CAUTION Statements identifying conditions or practices that can result in damage to the equipment or other property. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 15: Overview

    “Installation” on page 3 • “Control Modes” on page 4 • “Operation” on page 6 • “Clock Setting Controls” on page 10 • “Specifications” on page 12 • “Specifications” on page 12 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 16: Introduction

    When provided with a SMPTE or EBU timecode source, the UDC-5212 is instantly self-setting. In the event of a power failure, the UDC-5212 maintains the correct time internally via a battery-backed timekeeping memory. If power should be restored without timecode, the UDC-5212 will self-set to the correct time as maintained by the battery backup, and then continue to operate on internal crystal or power line timebase.
  • Page 17: Installation

    The UDC-5212 Universal Digital Clock is designed for wall mounting. Rack mounting kits are optional. The rear panel of the UDC-5212 is provided with four rubber feet and four keyholes. These are dimensioned for #8 screws. The rear panel is recessed for connectors and to allow the clock to be placed close to the wall.
  • Page 18: Rear Panel

    Selection of the clock control modes is achieved with the rear panel DIP switches. Figure 1-1illustrates the possible two DIP switch states Switch in right postiition Switch in left postiition Figure 1-1. DIP Switch Positions UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 19 (date if code is present) (See “Secondary Reference Mode” on page 12 Hour (Clock selected); 24 Hour (Clock selected); HH:MM:SS (timecode selected) MM:SS:FF (timecode DD:MM:YY (date selected) selected); MM:DD:YY (date selected) UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 20: Operation

    Operation Clock Mode To set the UDC-5212 to operate as a timecode reading clock, DIP Switch 6 must be in the CLOCK position. No setting of time is required when input timecode is provided to the UDC-5212 clock. Once valid timecode is detected, either SMPTE or EBU, the clock will instantly self-set.
  • Page 21: Secondary Reference Mode

    Switch 1. Secondary Reference Mode The UDC-5212 will run as standard wall clock when no input timecode is provided. Rear panel DIP Switch 4 selects the timebase to be used, either the clock’s internal crystal, or the power line frequency (50/60Hz).
  • Page 22: Date Display

    36 is the least significant bit (LSB), while bit 54 is the most significant bit (MSB). When DIP Switch 3 on the UDC-5212 clock is in the USE AUX OFFSET position, the auxiliary offset found in the input timecode’s user bits is added to the input timecode. The clock then displays the total.
  • Page 23: Brightness Adjustment

    (as viewed from the back) increases brightness. To illuminate all the LEDs, press and hold both the CW and CCW buttons for ten seconds. Re-power the UDC to return to normal operations. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 24: Clock Setting Controls

    Chapter 1: UDC-5212 Universal Digital Clock Clock Setting Controls The UDC-5212 Clock may be set using the three push button switches located on the rear panel. The push buttons, labeled MANUAL SET, CW, and CCW, may be used to program a local time zone offset, or to manually set the time.
  • Page 25: Time Zone Changes

    10 seconds. The clock will automatically self-set to the new time. For information on the module that controls the UDC-5212, please See -5100DL Drive Logic Module on page 1 of this manual. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 26: Specifications

    Table 1-7. Time Base Item Specification Timecode SMPTE/EBU, automatic selection Internal Crystal, ± 4 sec/month, 0°—50°C Power line 50 or 60 Hz, automatic selection Battery backup Crystal, ± 10 sec/month, 0°—50°C UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 27: Controls

    12 or 24 hour format, H:M:S or M:S:F Mechanical Table 1-9. Mechanical Specifications Item Specification Style Wall-mount Face diameter 11.5 in. (292 mm) Overall dimensions 14.0×14.0×3.375 in. (356×356×86 mm) UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 28 Chapter 1: UDC-5212 Universal Digital Clock UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 29: Overview

    “Table 2-10 lists the Clock Control mode DIP switch options.” on page 18 • “Clock Setting Controls” on page 23 • “Specifications” on page 25 • “Specifications” on page 25 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 30: Introduction

    If operated as a timecode reader display, the DTD continually tracks the input code and stops when the input fails. The colon LEDs extinguish when timecode is absent in this mode. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 31: Installation

    Master or Slave configuration. All clocks are shipped configured for timecode input (slave) operation, unless otherwise specified when ordering. A standard AC power connector and cord are also included. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 32: Control Modes

    (date if code is present) (See “Secondary Reference Mode” on page 12 Hour (Clock selected); 24 Hour (Clock selected); HH:MM:SS (timecode selected) MM:SS:FF (timecode DD:MM:YY (date selected) selected); MM:DD:YY (date selected) UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 33: Operation

    If there is a failure of input timecode, the colons will extinguish and the last valid time will remain displayed. No switching to a secondary reference occurs. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 34: Secondary Reference Mode

    The offset is encoded using timecode bits 36, 37, 38, 52, 53, and 54. Bit 36 is the least significant bit (LSB), while bit 54 is the most significant bit (MSB). UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 35: Date Display

    INTERNAL position. The clock uses the internal crystal for a timebase when operated in this fashion. Additionally, DIP switch 2 must be set to the RUN ON SECONDARY position. This disables the flashing colons. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 36: Brightness Adjustment

    MANUAL SET and either the CW or CCW buttons simultaneously. Holding MANUAL SET and CW increases the brightness one level per second, while holding MANUAL SET and CCW decreases the brightness. There are 16 levels of brightness. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 37: Clock Setting Controls

    10 seconds. The clock will automatically self-set to the new time. • To set the time back by one hour, press and hold the CCW button for 10 seconds. The clock will automatically self-set to the new time. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 38: Local Offset Programming

    Clock System Driver. All offsets are additive. Note The offset value programmed is always ADDED to the current time. To achieve a -3 hour offset, program an offset value of 21 hours. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 39: Specifications

    Table 2-14. Time Base Item Specification Timecode SMPTE/EBU, automatic selection Internal Crystal, ± 4 sec/month, 0°—50°C Power line 50 or 60 Hz, automatic selection Battery backup Crystal, ± 10 sec/month, 0°—50°C UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 40: Controls

    12 or 24 hour format, H:M:S or M:S:F Mechanical Table 2-16. Mechanical Specifications Item Specification Style Wall-mount Face diameter 11.5 in. (292 mm) Overall dimensions 14.0×14.0×3.375 in. (356×356×86 mm) UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 41: Chapter 3: Supporting Information

    8. Re-apply AC power to the clock, and confirm start-up (LED remains on, hands do NOT move). 9. Remove AC power from the clock, and again remove the back panel. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 42 13. Apply AC power to the clock. The LED will remain ON. Immediately perform the Local Offset procedure described in “Clock Setting Controls” for the appropriate model of clock. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 43: 5225Db Display Module

    LEDs. The voltage regulator provides 12 Volts for half of the digits, while the regulator on the 5100DL board provides this voltage for the other half of the digits. UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
  • Page 44 Chapter 3: Supporting Information UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual...
