Other products from GSD
standalone products
GSD also offers fully functional standalone door controls for less complex door
management. This attractive design, with modern aesthestics, will complement
any building
- GSD Digital Keypad
- GSD Proximity Switch
- GSD Pin&Prox Switch
- GSD Biometric Switch
Features:
50 users
Access control
Door Monitoring
Manager User
Fire and Intruder alarm interface
Backlighting
Tamper resistant
5 amp relays
Indoor or outdoor use
Robust polycarbonate housing with stainless steel keys
Mounts onto a standard electrical back box
No.1 Turnpike Business Park,
Ballymount,
Dublin 22, Ireland.
Telephone: +353 1 524 2691.
Fax: +353 1 4430 430.
Contents
Technical Specification
2
Output Data format
3
Installation Diagrams
4
Wiring Diagram
6
Smart Slave
Installation & User Manual
V1.1
Advertisement
Related Manuals for GSD Smart Slave
Summary of Contents for GSD Smart Slave
- Page 1 Other products from GSD standalone products GSD also offers fully functional standalone door controls for less complex door management. This attractive design, with modern aesthestics, will complement any building - GSD Digital Keypad - GSD Proximity Switch - GSD Pin&Prox Switch...
- Page 2 Output Format Technical Specifcation Technical Specs Output Data Format - Wiegand 26 bit Power Supply 12V DC Current consumption 70mA Step Description Current consumption with load (max) 100mA Relay Contact Rating 5 Amps /240V ac Programming Present Programming Card 1 Time Operating Temperature -20 C to +60 C Card x 1...
- Page 3 Installation Diagrams Installation Diagrams Flush Mounting Door Control is mounted to electrical pattress box using security screws provided. Both Security Caps are then clipped onto Door Control. When Surface Mounting the Door Control a Surface Mount Collar is required. - Fix Surface Mount Collar to wall, ensure arrow is pointing upwards Surface Mounting...
-
Page 4: Wiring Diagrams
Buzzer Control Input 12V DC Green LED Input Only Red LED Input Common the OV from the Smart Slave and the OV from the Door Control to avoid any ground loop issues. Tamper Alarm Output Card Present Output Data0/Data Output...
