Sharp CD-XP500A Service Manual

Hide thumbs Also See for CD-XP500A:

Operation manual (32 pages)

Service manual (64 pages)

Table of Contents

Quick Links

Summary of Contents for Sharp CD-XP500A

Page 1: Table Of Contents
CD-XP500A/CD-XP500W SERVICE MANUAL No. S5238CDXP500A MINI COMPONENT SYSTEM CD-XP500A MODEL CD-XP500A Mini Component System consisting of CD-XP500A (main unit) and CP-XP500 (speaker system). Illustration: CD-XP500A MINI COMPONENT SYSTEM CD-XP500W MODEL CD-XP500W Mini Component System consisting of CD-XP500W (main unit) and CP-XP500 (speaker system).
Page 2: Safety Precaution For Service Manual
CD-XP500A/CD-XP500W SAFETY PRECAUTION FOR SERVICE MANUAL WARNINGS THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1 BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR CLASS 1. THEREFORE IT IS IMPORTANT THAT THE FOLLOWING PRECAUTIONS ARE OBSERVED DURING SERVICING TO PROTECT YOUR EYES AGAINST EXPOSURE TO THE LASER BEAM.
Page 3: Specifications
Height: 330 mm (13") Wow and flutter 0.3 % (WRMS) Depth: 360 mm (14-3/16") Weight 8.7 kg (19.1 lbs.) CP-XP500 (For CD-XP500A) Type Twin-Drive speaker system Amplifier 5 cm (2") Tweeter Output power MPO: 540 W (270 W + 270 W) (10 % T.H.D.) 13 cm (5-1/8") Woofer 2...
Page 4: Names Of Parts
CD-XP500A/CD-XP500W NAMES OF PARTS CD-XP500A/CD-XP500W Front panel 1. Disc Tray 2. Timer Set Indicator 3. On/Stand-by Button 4. Tuner (Band) Button 5. CD Button 6. Headphone Socket 7. Microphone Level Control 8. Microphone Socket 9. Tape (1 2) Button 10. Video/Auxiliary Button 11.
Page 5: Remote Control
21. Tape (1 2) Button 22. Volume Up and Down Buttons Buttons with " " mark in the illustration can be operated on the remote control only. CP-XP500 (For CD-XP500A) 1. Tweeter 2. Bass Reflex Duct 3. Woofers 4. Speaker Wire CP-XP500 (For CD-XP500W) 1.
Page 6: Disassembly
CD-XP500A/CD-XP500W DISASSEMBLY CD-XP500A/CD-XP500W Caution on Disassembly Follow the below-mentioned notes when disassembling Top Cabinet the unit and reassembling it, to keep it safe and ensure Front (A1)x2 excellent performance: Panel ø3x12mm 1. Take cassette tape and compact disc out of the unit.
Page 7 CD-XP500A/CD-XP500W (E2)x1 (M1)x3 Loading Tray Tape Mechanism (E3)x1 (E2)x1 (E2)x1 (E1)x1 ø3x6mm (E2)x1 (F3)x1 Front Panel Power PWB (E4)x1 (F2)x1 Transformer Headphones (M1)x3 Main PWB (F2)x1 Figure 7-4 (F1)x2 ø3x10mm (N1)x2 Figure 7-1 ø3x10mm Loading Tray (H3)x1 CD Servo (N3)x2...
Page 8 CD-XP500A/CD-XP500W CP-XP500 (For CD-XP500A) CP-XP500 (For CD-XP500W) REMOVAL PROCEDURE FIGURE REMOVAL PROCEDURE FIGURE STEP STEP Woofer 1. Front Panel ..... (A1) x1 Super Tweeter 1. Front Panel ..... (A1) x1 2. Screw ...... (A2) x8 2. Screw ...... (A2) x4 Tweeter 1.
Page 9: Removing And Reinstalling The Main Parts
CD-XP500A/CD-XP500W REMOVING AND REINSTALLING THE MAIN PARTS TAPE MECHANISM SECTION TAPE 2 Perform steps 1 to 6 and 9 of the disassembly method to Clutch Ass'y remove the tape mechanism. Record/Playback Head How to remove the record/playback and erase heads (TAPE 2) (See Fig. 9-1) 1.
Page 10: Adjustment
CD-XP500A/CD-XP500W CD MECHANISM SECTION Loading Motor PWB Perform steps 1, 2, 3, 11, 12, 13 and 14 of the disassembly Loading method to remove the CD mechanism. Motor Loading How to remove the loading motor Tray (See Fig. 10-1) (A1)x5 1.
Page 11: Tuner Section
CD-XP500A/CD-XP500W TUNER SECTION CD SECTION fL: Low-range frequency • Adjustment fH: High-range frequency Since this CD system incorporates the following automatic • AM IF/RF adjustment functions, readjustment is not needed when replacing the pickup. Therefore, different PWBs and pickups Signal generator: 400 Hz, 30%, AM modulated can be combined freely.
Page 12: Test Mode
CD-XP500A/CD-XP500W TEST MODE • Setting the test mode Any one of test mode can be set by pressing several keys as follows. <X-BASS> + <CD> + <POWER> TEST: CD operation test. Function: -CD test mode. -Enter test mode. T E S T IL isn't done OPEN/CLOSE operation is using manual.
Page 13 CD-XP500A/CD-XP500W Standard Specification of Stereo System Error Message Display Contents Error Contents DISPLAY Notes TAPE Mechanism Error. 'ER-TA**' 00: Tape Mechanism Error. 01: Initial Error. CD/VCD Pickup Mechanism Error. 'ER-CD**' (*) 01: PU-IN SW Detection NG. CD Changer Mechanism Error.
Page 14: Notes On Schematic Diagram
CD-XP500A/CD-XP500W NOTES ON SCHEMATIC DIAGRAM • Resistor: • The indicated voltage in each section is the one measured To differentiate the units of resistors, such symbol as K and by Digital Multimeter between such a section and the chas- M are used: the symbol K means 1000 ohm and the symbol sis with no signal given.
Page 15: Block Diagram
CD-XP500A/CD-XP500W DISC CLAMP NUMBER OPEN/ CLOSE T/T UP DOWN LOADING TO MAIN SECTION TO DISPLAY SECTION MOTOR – 9 10 CNP8 CNP7 LC78645NE CD SERVO XOUT 17 25 CONT5 SLDO SPDO VCC4 M63001FP VCC1 FOCUS/TRACKING/ VCC2 SPIN/SLED +3.3V DRIVER VCC3 +3.3V...
Page 16 CD-XP500A/CD-XP500W SO302 IC301 FM ANTENNA ZD351 TA7358AP TERMINAL 5.1V FM FRONT END FM IF 10.7 MHz T302 CF303 BF301 X351 450 kHz CF351 456 kHz B.P.F T351 CF352 AM IF FM RF L312 T301 AM LOOP OSC BUFF ANTENNA IC303...
Page 17 CD-XP500A/CD-XP500W FL701 FL DISPLAY TO CD SECTION TAPE MECHANISM Q705 ASS'Y +B10 RX701 55 40 27 25 13 REMOTE SENSOR +B10 +B10 IC701 VLOAD AVDD IX0532AW SYSTEM SW701-SW707 SW711-SW720 MICROCOMPUTER SW723-SW726 (1/2) SW601 1 2 4 5 6 7 8...
Page 18: Schematic Diagram / Wiring Side Of P.w.board
AUDIO PROCESSOR LD+7V C609 R605 1/50 A-5V C603 R613 22/50 VREF D-5V INTERFACE – + C605,C607: Q601 LOUT ROUT CD_GND(D_GND) 0.22 [CD-XP500A] KTC3199 GR R617 0.15 [CD-XP500W] R619 C606 C607 2.2K R611 RBASS LBASS L-CH 2.2K R607 C611 C635 C605 C637 LTRE 2.7K...
Page 19 390P VIDEO/AUX R692 C690 R690 390P R-CH C603 22/50 VREF – + C610 R604 1/50 ROUT C606,C608: C606 C608 0.22 [CD-XP500A] CHASSIS RBASS 0.15 [CD-XP500W] R606 RTRE 2.7K C612 C614 1/50 0.0027 C616 4.7/50 RSEL0 A+10V C618 1/50 DGND C620...
Page 20 CD-XP500A/CD-XP500W C302 0.001 AM TRACKING AM ANTENNA C331 0.047 C323 0.022 C338 C332 0.001 0.022 T303 D301 C342 DS1SS133 0.022 VD301 AM OSC. SVC348S C335 R358 560P D302 T306 3.9K DS1SS133 R336 C334 AM BAND (UJ) AM LOOP COVERAGE fL...
Page 21 CD-XP500A/CD-XP500W MAIN PWB-A1 (2/3) TP302 C373 C342 R365 0.022 0.015 C371 R358 1/50 3.9K R350 2.7K C372 1/50 C367 1/50 20 19 18 R352 R355 C357 3.3K 2.2/50 T351 C356 0.001 AM IF R388 TP301 R393 3.9K L352 ZD351 100µH DZ5.1BSB...
Page 22 CD-XP500A/CD-XP500W IC901 STK41223 – POWER AMP. C907 L902 0.29µH 100P R903 Q903 KTC3199 GR ZD903 ZD902 R917 DZ12BSB 0.1(3W) DZ12BSB R934 C917 0.022(ML) C916 R905 100/50 R919 R926 R925 R910 1.8K D906 1.5K 1.5K DS1SS133 (1/2W) (1/2W) Q902 KTC3199 GR...
Page 23 CD-XP500A/CD-XP500W MAIN PWB-A1(3/3) FM SIGNAL L902 0.29µH R942 470(2W) C930 R943 47/50 – R944 470(2W) 1.5K R934 D912 L1_OUT R949 DS1SS133 FAN MOTOR R1_OUT R947 C931 R950 RL914 10/50 FW901 M_+13.5V SP_RLY P25 11 - B D911 DS1SS133 CNP705 TO HEADPHONES...
Page 24 CD-XP500A/CD-XP500W DISPLAY PWB-B1 FL701 LED A PWB-B3 FL DISPLAY LED DRIVER Q710 +10V R794 KRC102 M R749 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13...
Page 25 CD-XP500A/CD-XP500W HEADPHONES PWB-B2 M_+13V SP_RLY R-CH L-CH JK701 HEADPHONES CNP705 9 8 7 6 5 4 3 2 1 23 22 21 20 19 18 17 16 15 14 13 12 11 10 R795 FM SIGNAL C701 1/50 C703 C702 0.022...
Page 26 CD-XP500A/CD-XP500W CD SERVO PWB-C CD SIGNAL 100P(CH 0.022 100P(CH PICKUP UNIT 100P(CH 56P(CH) 100P(CH PICKUP HPC1LX 0.022 VREF VREF 8.2K 1.2K 8.2K 0.047 80 79 78 77 76 75 74 73 72 71 70 69 8.2K EFMIN 0.001 RFVDD 0.0027...
Page 27 CD-XP500A/CD-XP500W 100P(CH) 0.022 100P(CH) 100P(CH) 56P(CH) 100P(CH) 0.022 CD RES CLAMP SW 2.2K DISC NO 2.2K 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 LRCK ASDFIN ASDACK DATA SLCO ASLRCK...
Page 28 CD-XP500A/CD-XP500W MIC PWB-G MIC SIGNAL CK48 ICK2 220P KIA4558P RK47 CK41 8.2K OPE AMP. RK46 100/16 ICK1 CK53 DS1SS133 47/25 M65856SP CK50 100P MIC AMP. RK45 6.8K RK11 DATA MIC SW CK46 DS1SS133 0.01 CK35 2.2/50 CK51 RK10 MCLKC ONT...
Page 29 CD-XP500A/CD-XP500W P32 1 - F P31 12 - G FROM DISPLAY PWB FROM MAIN PWB CNS705 CNS801 5 4 3 2 1 CNP802 C862 C861 10 9 8 7 6 5 4 3 2 1 C860 C811 CNP801 C805 D856...
Page 30 CD-XP500A/CD-XP500W P28 5 - G TO MIC PWB CNPK1 CNSK1 2 3 4 5 6 7 8 9 MAIN PWB-A1 R374 C302 R372 X352 R373 IC302 C382 R359 2 3 4 5 6 7 8 9 10 11 C395 R376...
Page 31 CD-XP500A/CD-XP500W 8 5 - G MIC PWB NPK1 P33 12 - D 5 6 7 8 9 TO DISPLAY PWB CNS701A FFC701 P35 10 - F FROM R136 TAPE 1 PLAYBACK HEAD R138 R122 R158 R134 C120 C130 C134 B C E...
Page 32 CD-XP500A/CD-XP500W LED A PWB-B3 DISPLAY PWB-B1 RX701 C716 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 FL701 LED704 R783 R707 R792 R793 R763 B C E BI703 Q705 R702 C703 D714 D713 R703...
Page 33 CD-XP500A/CD-XP500W LED B PWB-B4 LED703 R771 RD01 LED701 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 FL701 SW701 R798 ON/STAND-BY R799 R792 R800 BI704 CNS704 R753 C706 R754 IC701 CNP701A Q710 R731 R732...
Page 34 CD-XP500A/CD-XP500W P32 1 - D P31 12 - E FROM DISPLAY PWB FROM MAIN PWB CNS701 CNS601 CD SERVO PWB-C CNP7 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 CNP8...
Page 35 CD-XP500A/CD-XP500W P32 3 - H TAPE MECHANISM TO DISPLAY PWB ASSEMBLY CNP702 TAPE MECHANISM PWB-F FFC702 SOLENOID SOLENOID TAPE MOTOR TAPE 2 TAPE 1 RECORD/PLAYBACK/ PLAYBACK HEAD ERASE HEAD CD LOADING MOTOR PWB-E OPEN/CLOSE 1 2 3 4 5 6...
Page 36: Voltage
CD-XP500A/CD-XP500W VOLTAGE IC101 IC302 IC601 IC701 ICK1 VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE 2.6 V 4.85 V 4.93 V 1.6 V 3.7 V 1.7 V 0.74 V 4.78 V 4.93 V 1.0 V 3.7 V 1.7 V 0.91 V...
Page 37: Waveforms Of Cd Circuit
CD-XP500A/CD-XP500W WAVEFORMS OF CD CIRCUIT Stopped Stopped 1999/04/07 09:51:15 CH1=500 mV CH3=500 mV CH1=200 mV CH2=500 mV 500 ms/div 500 ms/div DC 10:1 DC 10:1 (500 ms/div) DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s NORM:20 kS/s IC1 21 IC1 21...
Page 38: Troubleshooting
CD-XP500A/CD-XP500W TROUBLESHOOTING When the CD does not function When the CD section does not operate when the objective lens of the optical pickup is dirty, this section may not operate. Clean the objective lens, and check the playback operation. When this section does not operate even after the above step is taken, check the following items.
Page 39 CD-XP500A/CD-XP500W Stopped (1) Focus-HF system check. CH1=500 mV CH3=500 mV 500 ms/div DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s Although a CD is inserted and the cover is closed, "NO DISC" is displayed. Press the OPEN/CLOSE switch (SW1) without inserting a disc, and try starting the playback operation.
Page 40 CD-XP500A/CD-XP500W (2) Tracking system check. Check the TE waveform at pin 15 on IC1. The tracking servo is not activated. If the waveform shown in Figure 40-1 appears and soon after Check the peripheral circuits at pins 14, 15 and 20 on IC1, and NO DISC appears ? CNS1A/B.
Page 41 CD-XP500A/CD-XP500W (4) PLL system check. Stopped 1999/04/05 17:33:17 CH1=500 mV CH3=1 V CH4=1 V 500 ms/div DC 10:1 DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s When a disc is loaded, start play operation. PDO1 The HF waveform is normal, but the TOC data cannot be PDO2 read.
Page 42: Function Table Of Ic
CD-XP500A/CD-XP500W FUNCTION TABLE OF IC IC1 VHiLC78645NE1: CD Servo (LC78645NE) (1/2) Terminal Name Input/Output Setting in Reset Pin No. Function SLCO Output — Control output. For slice level SLCIST Input — Resistor connection terminal for SLCO output current setting. control.
Page 43 CD-XP500A/CD-XP500W IC1 VHiLC78645NE1: CD Servo (LC78645NE) (2/2) Terminal Name Input/Output Setting in Reset Function Pin No. RVSS — — GND for Right channel. Must be connected to 0 V. Right channel RCHO Output LVDD /2 Right channel output. D/A converter...
Page 44 CD-XP500A/CD-XP500W IC1 VHiLC78645NE1: CD Servo (LC78645NE) 75 74 72 71 69 68 66 65 63 62 SLCO DATA SLCIST EFMIN LRCK ASDFIN RFVDD ASDACK RFVSS ASLRCK FIN1 16MOUT FIN2 EFLG TIN1 TIN2 XVSS LC78645NE VREF FSX/16MIN REF1 XOUT XVDD RVDD...
Page 45 CD-XP500A/CD-XP500W IC601 VHiLC75341/-1: Audio Processor (LC75341) ROUT LOUT LBASS RBASS LTRE RTRE LSEL0 RSEL0 R1 R2 24 23 22 21 20 19 18 17 16 15 14 13 LC75341 10 11 12 Figure 45 BLOCK DIAGRAM OF IC – 45 –...
Page 46 CD-XP500A/CD-XP500W IC701 RH-iX0532AWZZ: System Microcomputer (IX0532AW) (1/2) Pin No. Port Name Terminal Name Input/Output Function Input (+) Power supply. -20dBATT Output -20dB Attenuator. NO USE Output Open T-BIAS Output Tape record bias. T_T1/T2 Output Tape T1/T2 change. T-REC/PLAY Output Tape REC/PLAY change.
Page 47 CD-XP500A/CD-XP500W IC701 RH-iX0532AWZZ: System Microcomputer (IX0532AW) (2/2) Pin No. Port Name Terminal Name Input/Output Function P120 O/C SW Input CD OPEN/CLOSE SW. P117 MIC SW Input Mic switch input. P116 KARA_LATCH Output Karaoke latch. P115 NO USE Output Open P114...
Page 48 CD-XP500A/CD-XP500W ICK1 VHiM65856SP-1: Mic Amp. (M65856SP) (1/2) Pin No. Port Name Input/Output Function MIC SW Input Microphone SW L: MIC OFF, H: MIC ON MCLKC ONT — Clock Control. Controls built-in clock generation circuit with external R. VALCL — ALC operating voltage setting terminal.
Page 49 CD-XP500A/CD-XP500W ICK1 VHiM65856SP-1: Mic Amp. (M65856SP) (2/2) Pin No. Port Name Input/Output Function KEYCONIN Input Monaural input for external KEYCONTROL IC. Input/Output interface terminal for external KEYCONTROL IC. SOURCEOUT Output Monaural input for external KEYCONTROL IC. Input/Output interface terminal for external KEYCONTROL IC.
Page 50: Fl Display
CD-XP500A/CD-XP500W FL DISPLAY FL701 VVKNA09SS29-1 GRID ASSIGNMENT X-BASS REC ST SLEEP TP TI PTYIPTY MHz TA MEMORY h j k (1G~8G) ANODE CONNECTION X-BASS PTYI MEMORY PRO LOGIC SLEEP – 50 –...
Page 51: Parts Guide
CD-XP500A/CD-XP500W PARTS GUIDE MINI COMPONENT SYSTEM CD-XP500A MODEL CD-XP500A Mini Component System consisting of CD-XP500A (main unit) and CP-XP500 (speaker system). MINI COMPONENT SYSTEM CD-XP500W MODEL CD-XP500W Mini Component System consisting of CD-XP500W (main unit) and CP-XP500 (speaker system). “HOW TO ORDER REPLACEMENT PARTS”...
Page 52 CD-XP500A/CD-XP500W PRICE PRICE DESCRIPTION PARTS CODE DESCRIPTION PART CODE RANK RANK FILTERS CD-XP500A/CD-XP500W BF301 RFILR0008AWZZ AE Band Pass Filter INTEGRATED CIRCUITS CF303 RFILF0124AFZZ AD FM IF,10.7 MHz CF351 RFILF0003AWZZ AK FM IF VHILC78645NE1 AY CD Servo,LC78645NE CF352 RFILA0009AWZZ AE AM IF...
Page 53 AA 560 pF,50V C603 VCEAZA1HW226M J AB 47 µF,25V,Electrolytic AC 0.15 µF,50V,Thin Film [CD-XP500W] C117,118 VCEAZA1EW476M J C605~608 VCFYHA1HA154J AA 0.0022 µF,16V AC 0.22 µF,50V,Thin Film [CD-XP500A] C119,120 VCTYMN1CX222K J C605~608 VCFYHA1HA224J AA 0.022 µF,25V AB 1 µF,50V,Electrolytic C121 VCTYMN1EF223Z C609,610 VCEAZA1HW105M J AA 0.0027 µF,16V...
Page 54 CD-XP500A/CD-XP500W PRICE PRICE DESCRIPTION PARTS CODE DESCRIPTION PART CODE RANK RANK AB 0.1 µF,50V,Electrolytic C946 VCEAZA1HW104M J R132,133 VRD-MN2BD101J AA 100 ohm,1/8W AA 0.01 µF,16V VCTYPA1CX103K R134,135 VRD-MN2BD103J AA 10 kohm,1/8W AA 0.001 µF,50V VCKYPA1HB102K R136 VRD-ST2CD224J AA 220 kohms,1/6W AB 0.47 µF,50V,Electrolytic...
Page 55 CD-XP500A/CD-XP500W PRICE PRICE DESCRIPTION PART CODE PARTS CODE DESCRIPTION RANK RANK R724,725 VRD-ST2CD102J AA 1 kohm,1/6W R947 VRD-ST2CD153J AA 15 kohms,1/6W R726,727 VRD-ST2CD681J AA 680 ohms,1/6W R949 VRD-ST2CD102J AA 1 kohm,1/6W R728 VRD-ST2CD222J AA 2.2 kohms,1/6W R950 VRD-ST2CD683J AA 68 kohms,1/6W...
Page 56 SW705 92LSWICH1401AT J AC Switch,Key Type [Play] GITAR1012AWSA Rear Panel [CD-XP500W] SW706 92LSWICH1401AT J AC Switch,Key Type [Reverse Play] GITAR1022AWSA Rear Panel [CD-XP500A] SW707 92LSWICH1401AT J AC Switch,Key Type KMECB0025AWZZ J BG Tape Mechanism Ass’y [Reverse Mode] 208- 1 92PF513-853...
Page 57 AZ CD Pickup Lens Cleaner HDECQ0837AWSA J AF Light Panel LHLDZ1411AWZZ AE Holder,Light Panel GCOVA1419AWSA J AC Light Cover,Right GCOVA1420AWSA J AC Light Cover,Left CP-XP500 (For CD-XP500A) PSHEP0086AWZZ J AE Light Sheet LHLDZ1422AWZZ AE Block,Button SPEAKER BOX PARTS JKNBK0092AWSA AL Knob,Volume LANGK0327AWFW J...
Page 58 CD-XP500A/CD-XP500W CD-XP500A/CD-XP500W 306-2 306-1 306-3 703x2 305x2 PWB-D Figure 7 CD MECHANISM EXPLODED VIEW – 7 –...
Page 59 CD-XP500A/CD-XP500W CD-XP500A/CD-XP500W BELT CONNECTION 202-1 PWB-A1 FF/REW Tape FF/REW ROLLER Motor ROLLER 615x3 ASS'Y ASS'Y 623x2 604x2 IC851 FLYWHEEL FLYWHEEL IC852 ASS'Y ASS'Y MAIN BELT IC853 TAPE2 TAPE1 Silicon Grease 614x12 614x2 614x3 230 611x2 610x5 202-2 Silicon Grease PWB-F...
Page 60 CD-XP500A/CD-XP500W CD-XP500A/CD-XP500W 609x2 MECHANISM 609x2 PWB-E 619x2 PWB-C Figure 9 CABINET EXPLODED VIEW (2/2) – 9 –...
Page 61 CD-XP500A/CD-XP500W CP-XP500 (For CD-XP500A) C1, 2 Capacitor SP5, 6 C1, 2 2.7µF, 100V(N.P.) TWEETER Capacitor 2.7µF, 100V SP5, 6 Electrolytic (N.P.) TWEETER SP1, 2 WOOFER SP1, 2 WOOFER SP1, 2 SP3, 4 WOOFER 901, 902 911x4 SP5, 6 SP3, 4...
Page 62 CD-XP500A/CD-XP500W CP-XP500 (For CD-XP500W) SUPER TWEETER SUPER 901, 902 TWEETER C1, C2 SP1, SP2 Capacitor SP5,SP6 2.7µF,100V TWEETER Electrolytic (N.P.) SP1, WOOFER SP3, 918x4 WOOFER 908(with Capacitor C1, 917x2 917x2 917x4 SP5, SP6 905x2 917x2 914, 915 SP3, SP4 917x6...
Page 63 CD-XP500A/CD-XP500W — M E M O — – 13 –...
Page 64 CD-XP500A/CD-XP500W © COPYRIGHT 2002 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
