XDVD236BT
INSTALLATION/OWNER'S MANUAL
DVD Multimedia Receiver with Bluetooth
®
featuring a
6.2"
Touch Screen Display
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XDVD236BT and is the answer not in the manual?

Questions and answers

Related Manuals for Dual XDVD236BT

Summary of Contents for Dual XDVD236BT

  • Page 1 XDVD236BT INSTALLATION/OWNER’S MANUAL DVD Multimedia Receiver with Bluetooth ® featuring a 6.2" Touch Screen Display Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the...
  • Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 3: Table Of Contents

    XDVD236BT PREPARATION Table of Contents Page Warning Statement ..........
  • Page 4 XDVD236BT PREPARATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside the vehicle and/or...

  • Page 5: Safety Information/Precautions

    Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your DUAL XDVD236BT is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.
  • Page 6 XDVD236BT INSTALLATION Preparation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.

  • Page 7: Wiring Diagram

    XDVD236BT INSTALLATION Wiring Diagram - Inputs/Outputs ACC (B+) Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATM mini style fuse located inside the in-line filter box.

  • Page 8: Control Locations

    XDVD236BT OPERATION Control Locations Mode Auxiliary Input Tune / Track Up Eject Volume / Power / Mute Microphone Tune / Track Down SD Card Slot USB Port Go To Power Mode EQ / Loudness End Call Play / Pause Number Keys...

  • Page 9: Remote Control Preparation

    XDVD236BT OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly.

  • Page 10: General Operation

    XDVD236BT OPERATION General Operation Momentarily press to turn the unit on. Press and hold to turn Power On/Off the unit off. Rotate the volume knob to increase or decrease the volume level. Volume Momentarily press the volume knob to silence the audio. Momentarily...
  • Page 11 XDVD236BT OPERATION General Operation Setup Menu From the Main Menu screen, press SETUP in the bottom right corner to access the Setup menu and select from six categories across the bottom: General, Time, Video, Language, Calibration and SWC. General: • Animation - Select Off, 10 second, 30 second, 1 minute, 90 second, 2 minute, 3 minute or 4 minute to set animation length.
  • Page 12 XDVD236BT OPERATION General Operation Setup Menu Time: • Hour - Press < or > to adjust the hour down or up. • Minute - Press < or > to adjust the minutes down or up. • Format - Select between a 12HR or 24HR clock display.
  • Page 13 XDVD236BT OPERATION AM/FM/RDS Tuner Operation Radio Operation Select the Radio icon from the Main Menu screen. Press to return to Main Menu screen. Main Menu Displays current mode of operation. Current Mode Indicator Tune Frequency Down Press << to tune radio to a lower frequency. Press < to tune the unit down one step at a time.
  • Page 14 XDVD236BT OPERATION AM/FM/RDS Tuner Operation Press to toggle between Local (LOC) and Distance (DX) tuning. Local / Distance Press to adjust the Loudness setting between Low, High and Off. Loudness Press to toggle between Stereo (ST) and Mono operation, Stereo...

  • Page 15: Cd/Usb/Sd Card Operation

    XDVD236BT OPERATION CD/USB/SD Card Operation To play audio files from a disc or MP3/WMA files from a disc, USB device CD/MP3/WMA or JPG Operation or SD card, insert disc or device and playback will begin automatically. To return to disc, USB or SD card playback from another mode of operation, select the corresponding icon from the Main Menu.
  • Page 16 XDVD236BT OPERATION CD/USB/SD Card Operation Previous Options Press to see the previous screen of options. Press to mute the unit's sound. Press again to unmute, or sound can be Mute restored by adjusting the volume knob of the front panel.
  • Page 17 XDVD236BT OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2   ISO9660 Level 3 Playback   ISO9660 JOLIET File System Extension Filename 32 bytes 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3  File .wma/.WMA...
  • Page 18 XDVD236BT OPERATION Media Compatibility - USB/SD Card File Type FAT 12 File System FAT 16/FAT 32   .mp3/.MP3/.Mp3/.mP3  File .wma/.WMA  Extension .rmp/.m4a MPEG 1  MPEG MPEG 2  Format MPEG 2.5  MPEG 1 32/44.1/48kHz MPEG 2 12/16/22.05/24kHz...

  • Page 19: Media Compatibility

    XDVD236BT OPERATION Media Compatibility Media Compatibility The following types of discs/files are compatible: • CD-DA, CD-ROM (ISO), CD-R, CD-RW • DVD Video, DVD+R/RW, DVD-R/RW • AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps • Mpeg2: Max video resolution: 720x480, Max video bit rate: 5000 kbps •...

  • Page 20: Dvd Operation

    XDVD236BT OPERATION DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub- menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features.
  • Page 21 XDVD236BT OPERATION DVD Operation Random Press Random to play chapters in random order or Random Off to play disc in order. Circulate Press to select from the following repeat options: Repeat Chapter, Repeat Title, Repeat All or Repeat Off. Audio Press to adjust Audio options.

  • Page 22: Bluetooth Operation

    Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "Dual BT". The Bluetooth passcode "0000". The unit can be in any mode of operation when pairing is performed.
  • Page 23 XDVD236BT OPERATION Bluetooth Operation Press to display the keypad and make a call. Dial Press to display a list of recently Received, Missed and Dialed calls. History Press to view active and available Bluetooth connections. Connect Bluetooth Music Select this option from the Main Menu to access Bluetooth Music features.
  • Page 24 XDVD236BT OPERATION Front 3.5mm Aux Input & Rear RCA A/V Input Auxiliary Input Connect an optional audio source into the 3.5mm (front panel) input. Select auxiliary input from the Main Menu to listen to audio. Adjust volume on the external audio source as needed (if connected to the headphone output of the device).

  • Page 25: Warranty

    4. For more information and for the location of the original retail purchaser for products purchased from nearest authorized service center please contact an authorized Dual dealer and used in the U.S.A. us by one of the following methods: What is covered? This warranty covers all defects •...

  • Page 26: Specifications

    XDVD236BT OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range:...

  • Page 27: Troubleshooting

    Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your Dual product. Dealer Name...
  • Page 28 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.dualav.com ©2016 Dual Electronics Corp. All rights reserved. NSA0216-V01 Printed in China...
