Microdigital MDC-4 Series User Manual

Supreme resolution day & night color camera
Hide thumbs Also See for MDC-4 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
www.microdigital.co.kr
Supreme Resolution
Day & Night Color Camera
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDC-4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microdigital MDC-4 Series

Summary of Contents for Microdigital MDC-4 Series

  • Page 1 Supreme Resolution Day & Night Color Camera USER MANUAL...
  • Page 2 Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. MICRODIGITAL...
  • Page 3 • Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • This installation should be made by a qualified service person and should abide to all local codes. MICRODIGITAL...
  • Page 4 If it gets wet, wipe it dry immediately. Liquids • Do not expose the camera to can contain minerals that corrode the rain or spill beverage on it. electronic components. • Do not expose the camera to If exposed to radioactivity the CCD will fail. radioactivity. MICRODIGITAL...
  • Page 5 - To avoid fire or shock hazard, must use a UL listed power supply. • Monitor Impedance. - Set the impedance switch to 75ohm standard position. - When monitor is set to high impedance mode, the picture becomes blurred. In this case, just check the position of the monitor impedance switch. MICRODIGITAL...

  • Page 6: Table Of Contents

    ▪ BULLET CAMERA ▪ DOME CAMERA ▪ VANDAL CAMERA 34 - 35 • OSD OPERATION 36 - 42 ▪ BOX CAMERA 36 - 37 ▪ BULLET CAMERA 37 - 39 ▪ DOME CAMERA ▪ VANDAL CAMERA • INSTRUCTIONS • OSD STRUCTURE MICRODIGITAL...
  • Page 7 51 - 52 • DAY & NIGHT • • 54 - 59 SPECIAL ▪ CAM TITLE ▪ MOTION ▪ PRIVACY ▪ PARK LINE ▪ IMAGE ADJ. ▪ COMM ADJ. ▪ LANGUAGE ▪ VERSION ▪ RETURN • RESET & EXIT MICRODIGITAL...

  • Page 8: Description

    • EX) MDC - H8220 - VTD - 30 HU Built in Heater / UTC Number of IR-LED H 8 2 2 0 Day / Night Filter mechanism Power source Number of Pixels B/W(1) / Color(2) Case type Model type MICRODIGITAL...
  • Page 9 9: MINI VANDAL F(E) MF : FLUSH V(E) MOUNT TYPE IR & HEATER (MDC-6xxx, 7xxx, 8xxx MODEL) Heater Built-in Heater UTC Remote Control Heater -30H Built-in IR LED Built-in IR LED and CDS Sensor and CDS Sensor With Heater MICRODIGITAL...

  • Page 10: Description

    DAY / NIGHT FILTER CHANGE TRUE DAY / NIGHT (ICR-IR Cut Filter Removable) POWER SOURCE AC 24V AC 230V DC 12V DC 12V MDC-xxx0 MDC-xxx1 MDC-xxx2 - DC 12V - AC 24V / DC 12V, Dual-Power - AC 230V MICRODIGITAL...

  • Page 11: Specification

    ON / OFF (4 Zone Selectable) Sharpness 0~31 (Level Selectable) Electronic Shutter 1/60sec ~ 1/100,000sec 1/50sec ~ 1/100,000sec Built-In OSD Controller Operating Temperature (-)30°C ~ (+)50°C, (-)40°C ~ (+)50°C (Built-In Heater Model) Operating Humidity 90% RH max Power Voltage DC12V ± 10% MICRODIGITAL...

  • Page 12: Specification

    0.2 (Color) / 0.05 (BW) / Lux at F1.4 MDC-8xxx 0.3 (Color) / 0.03 (BW) / Lux at F1.4 0 Lux at IR LEDs On (ICR-IR Cut Filter Removable Mechanism) ▶Specifications are subject to change without prior notice due to improvement MICRODIGITAL...

  • Page 13: Features

    When the camera becomes hot after operating a couple of days, white spots are shown on the screen especially at low light condition and they are recorded together with normal image. By using thise function, white spots are removed and you can get clean images. MICRODIGITAL...

  • Page 14: Features

    2. Surface or Flush Mounting using the supplied surface mount bracket. C / CS Mount Lens Adjustable MDC-4xxx MODEL UTC Remote Controller - Long distance controller. - Menu can be adjusted without opening the camera case. - It is of conveniently portable size. MICRODIGITAL...

  • Page 15: Components

    COMPONENTS 1. Camera 2. Auto IRIS Lens Connection Plug 3. L-WRENCH 4. C - Mount Adaptor 5. Manual Width Height depth MICRODIGITAL...

  • Page 16: Over View

    Loosen the clamp screw with a L-Wrench before adjusting the Back Focal length. 4 Mount bracket Use the screw holes provided when fixing the camera onto a mounting bracket. The mounting bracket can be attached to either the bottom or the top of the camera. MICRODIGITAL...

  • Page 17: Rear View

    5 OSD button 6 Power input terminal : Low voltage power connection. 7 AC Power Cord : Accept AC90~240V-50Hz/60Hz MDC-4xx0/ 4xx1 MDC-4xx2 AC24V / DC12V AC230V Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...

  • Page 18: Bullet Camera

    COMPONENTS 1. Varifocal IR Bullet Camera 2. Cable for Extra Video 3. L-WRENCH 4. Screw for Installation 5. Manual MICRODIGITAL...
  • Page 19 COMPONENTS MDC-6220VTD-20 & 20H (65Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Lever 4 OSD Joystick (Option) 5 Cable Management Bracket 6 VBS-Extra for connecting to LCD (Option) VBS-EXTRA MICRODIGITAL...
  • Page 20 Width 74.00 Length 146.80 20pcs IR-LED, IR LED & Heater 20pcs IR LED 3pcs Heater Power Consumption Normal 130mA IR LED ON 360mA Heater ON 260mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...
  • Page 21 COMPONENTS MDC-6220VTD-24H & 42 (70Ø) / 32 & 40H (90Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Lever 4 OSD Joystick (Option) 5 Cable Management Bracket 6 VBS-Extra for connecting to LCD (Option) VBS-EXTRA MICRODIGITAL...
  • Page 22 32pcs Giant LED, 4pcs 24pcs IR-LED, Heater IR-LED IR-LED Heaters 4pcs Heaters Power Consumption Normal 140mA IR LED ON 270mA 500mA 570mA 440mA Heater ON 440mA 570mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...
  • Page 23 MDC-6220VTD-35H & 45(77Ø) / 36H & 48 (88Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Ring 4 OSD Joystick 5 Cable Management Bracket Focus / Zoom ring Focus / Zoom lever fixing screw bolt screw MICRODIGITAL...
  • Page 24 & 33pcs IR-LED & IR-LED & IR-LED IR-LED 3pcs Heater 4pcs Heater Power Consumption Normal 140mA IR LED ON 520mA 620mA 480mA 580mA Heater ON 660mA 660mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...

  • Page 25: Dome Camera

    COMPONENTS Vandal Resistant Dome Camera Vandal Resistant Dome Camera (Surface Type) (Surface Type) Service Monitor Cable Manual L-Wrench Mounting Screw Vandal Resistant Dome Camera (Flush Type) L-Wrench Tapping Screw Manual Service Monitor Cable Surface Mount Bracket Surface Mount Screw MICRODIGITAL...
  • Page 26 · Adjust the pan and tilt to give the correct angle of view. 3 OSD Joystick / Board 4 VBS-Extra for connecting to LCD · Please use the supplied wire when connecting to an external monitor. 5 IR LED MDC-7220F MDC-7220V / VTD VBS-EXTRA MDC-7220VTD-30 MICRODIGITAL...
  • Page 27 MDC-7220V / VTD (100Φ) MDC-7220F (68Φ) MDC-7220 VTD-30 Dimension Diameter 68ø 100ø Width Height 30pcs IR LED IR-LED Power Consumption Normal 150mA 170mA IR LED ON 450mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...

  • Page 28: Vandal Camera

    4 Zoom / Focus Lever 5 VBS-Extra for connecting to LCD · Please use the supplied wire when connecting to an external monitor. 6 3 Axis bracket · Adjust the pan and tilt to give the correct angle of view. VBS-EXTRA MICRODIGITAL...

  • Page 29: Components

    Diameter 100ø Height 108mm Width 151mm 30pcs 30pcs IR LED IR-LED, 6pcs IR-LED Heater Power Consumption Normal 160mA IR LED ON 430mA 430mA Heater ON 490mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...

  • Page 30: Installation

    Strip off about 2mm of the insulation of wires inside the lens cable. · Remove the cover of the auto iris lens connection plug and solder the · wires to the connector pins inside the plug, as shown below. MICRODIGITAL...
  • Page 31 Set the lens selection switch, located on the rear of the camera, to ei- · ther DC or VIDEO, depending on the type of auto iris lens being used. MICRODIGITAL...

  • Page 32: Bullet Camera

    To avoid smear, never face the camera directly to the strong light source such as sun or spot light. 3 AXIS BRACKET 3 AXIS BRACKET 65ø TYPE 77 / 88ø TYPE MOUNTING SCREW MOUNTING SCREW MOUNTING SCREW 70 / 90ø TYPE CABLE MANAGEMENT BRACKET MICRODIGITAL...

  • Page 33: Dome Camera

    • Adjust picture direction pan & tilting. • Close the dome with the ring screwed. MDC-722F (Two Screw) Ceiling Ceiling BASE HOUSING MOUNTING SCREW DOME COVER HOLDER DOME COVER MDC-7220V / VTD MDC-7220VTD-30 (Three Screw) (Four Screw) MICRODIGITAL...

  • Page 34: Vandal Camera

    Fixed the camera to a celling using four screws. Adjust desired focus and scene by turning and moving the 3-axis camera bracket by hand. Put the dome cover over the base. Fix the dome cover on the base by L-Wrench. MICRODIGITAL...

  • Page 35: Installation

    Connect the dome base to the surface mount bracket by screws. Adjust desired focus and scene by turning and moving the 3-axis camera bracket by hand. Put the dome cover over the base. Fix the dome cover on the base by L-Wrench. MICRODIGITAL...

  • Page 36: Osd Operation

    - Set the 75Ω / Hi-Z selection switch as shown below if you have an intermediate device. 2) Connection to Power - Connect the adaptor to the power input connector as shown in the following figure. The Standard voltage for camera option : DC 12V± 10%, AC 24V ±10%. MICRODIGITAL...

  • Page 37: Bullet Camera

    - If necessary, you can connect the monitor to the REMOTE jack on the back of your camera. - Only connect the cable when the power is furned off. - Set the 75Ω / Hi-Z selection switch as shown below if you have an intermediate device. MICRODIGITAL...
  • Page 38 - Use the power rated at least 400mA (12VDC) Video Video Terminal (Yellow) (Yellow) NO Function Remark Color Video Yellow 1.0 Vp-p Output Power 12V DC(10V~15V), Power - DC 12V Power - DC 12V Input Max 4.8W / 400mA (Red) (Red) MICRODIGITAL...
  • Page 39 OSD OPERATION MDC-6xxx Push(set) MDC-6220VTD -35H, 36H, 45, 48 ♦ Unscrew the OSD button cap MDC-6220VTD-20 / 20H MDC-6220VTD ♦ Unscrew the front cover -24H, 42, 30, 40H ♦ Unscrew the front cover MICRODIGITAL...

  • Page 40: Dome Camera

    OSD OPERATION MDC-7xxx Push(set) MDC-7220F / 7220VTD-30 (OSD JOYSTICK) ♦ Unscrew the dome cover RIGHT LEFT DOWN MDC-7220V / VTD (OSD BOARD) ♦ Unscrew the dome cover MICRODIGITAL...

  • Page 41: Vandal Camera

    OSD OPERATION MDC-8xxx Without Heater type OSD Board OSD cable OSD button connecter VBS-Extra Connector With Heater type OSD Board Power Module connector connector OSD cable connecter VBS-Extra Temperature Sensor connecter OSD button MICRODIGITAL...

  • Page 42: Osd Operation

    NTSC / PAL Video Input Level 1.0 Vp-p / 75 Ohm BNC Video Output Level 1.0 Vp-p / 75 Ohm BNC Control OSD, PAN/Focus MicroDigital Compatibility Except Other Companies UTC Product Family Distance Video Output Distance TEST : 500M (RG59) Operation temperature -20°C ~ +60°C...

  • Page 43: Instructions

    • To finish and save the settings, select [EXIT] and press the SET button ( ▪ An item with the ↵ icon also has sub-menus. To select a sub-menu, press the SET button. ▪ An item with the - - - icon has no sub-menus available for selection MICRODIGITAL...

  • Page 44: Osd Structure

    ID & TITLE (0~15) SUB MENU CONTRAST 0 ~ 255 SHARPNESS 0 ~ 31 DISPLAY CRT / LCD / USER NEG. IMAGE ON / OFF COMM ADJ. CAM ID / BAUD RATE / PROTOCOL / DISPLAY ID / ID POS MICRODIGITAL...

  • Page 45: Lens

    DAY & NIGHT AUTO SPECIAL RESET EXIT EXPOSURE ▹ This function is used to select Automatic or Manual shutter speed control SETUP EXPOSURE LENS SHUTTER AUTO EXPOSURE BRIGHTNESS WHITE BAL. ATW1 BACKLIGHT DWDR DAY & NIGHT AUTO RETURN SPECIAL RESET EXIT MICRODIGITAL...

  • Page 46: Shutter

    ▶ DWDR (Digital Wide Dynamic Range) • This camera which is using 2D-DNR DSP provides intelligent light level control to overcome even strong backlight conditions. When there are simultaneous bright & dark image areas DWDR makes them both distinct. MICRODIGITAL...

  • Page 47: Return

    AUTO SPECIAL RESET EXIT ▶ ATW1 (Auto Tracking White Balance) • Select this when the color temperature is between 2,500°K and 9,500°K. ▶ATW2 (Auto Tracking White Balance) • Select this when the color temperature is between 2,000°K and 11,000°K. MICRODIGITAL...
  • Page 48 (e.g. clear sky, or sunset) 2. When the ambient illumination of the subject is low. 3. If the camera is directed toward a fluorescent light, or is installed in a place where illumination changes dramatically, the White Balance operation may be- come unstable. MICRODIGITAL...
  • Page 49 • WIDTH : adjust the width of the area. • LEFT/RIGHT : adjust the horizontal movement of the area. • TOP/BOTTOM : adjust the vertical movement of the area. • RETURN : Select this to save the setting for the ‘BLC’ menu. MICRODIGITAL...
  • Page 50 » NIGHT ONLY : To operate only at night. » ALL DAY : To operate during all day. · RETURN : Select this to save the setting for the ‘HLC’ menu. ▶OFF : BACKLIGHT function does not operate. LEVEL MODE ALL DAY RETURN HLC ON HLC OFF MICRODIGITAL...

  • Page 51: Day & Night

    · RETURN : Select this to save the setting for the ‘D&N B/W’ menu ▪ IR SMART function is available to use for camera with IR LED only. ▪ It controls the IR LED(bright portion base), situation is not expected. ➜This function can be utmost only at BURST OFF MICRODIGITAL...
  • Page 52 You can control the delay time when night becomes day. (1~30) » RETURN Select this to save the setting for the ‘D&N AUTO’ menu. D&N AUTO D ➜ N LEVEL 3 SEC D ➜ N DELAY N ➜ D LEVEL 3 SEC N ➜ D DELAY RETURN MICRODIGITAL...

  • Page 53: Dpc

    By using this function, white spots are removed and you can get clean images. SETUP LENS EXPOSURE WHITE BAL. ATW1 BACKLIGHT DAY & NIGHT AUTO SPECIAL RESET EXIT COVER THE LENS PROCRSSING NOW… THEN PRESS ENTER KEY MICRODIGITAL...

  • Page 54: Special

    ▪ Choose a ( ) menu using the OSD buttons. And the press set button. Move the cursor over the letter to be edited, move the cursor to the letter to be inserted and then press the SET button MICRODIGITAL...

  • Page 55: Motion

    · DEGREE : When number is high, motion detection sensitivity is increased to recognize even small movement. · VIEW : Able to check the sensing scene of motion detection in the screen. · RETURN : Select this to save the setting for the ‘MOTION’ menu. MICRODIGITAL...

  • Page 56: Privacy

    · TOP / BOTTOM : Moves vertical position of the mask. · COLOR : Possible to choice a color of the privacy area. (16 different colors) · RETURN : Select this to save the setting for the ‘PRIVACY’ menu. MICRODIGITAL...

  • Page 57: Park Line

    » OFF: Deactivates 2DNR - noise is not reduced. • MIRROR · Horizontal flip is available according to the situation. • FONT COLOR · You can change the OSD font color. (Between 0~15) • CONTRAST · Adjust the overall brightness in the screen. (Between 0~255) MICRODIGITAL...

  • Page 58: Comm Adj

    · Select this to save the setting for the ‘COMM ADJ.’ menu. • SHARPNESS · As you increase this value, the picture outline becomes stronger and clearer. The level can be adjusted to obtain an improved image. (Between 0~255) MICRODIGITAL...

  • Page 59: Language

    • END : OSD is off the screen, not returned in ‘SETUP’ menu. SETUP LENS EXPOSURE WHITE BAL ATW1 BACKLIGHT DAY & NIGHT AUTO SPECIAL RESET EXIT EXIT Press the SET button in the EXIT menu to save the current ▶ settings and exit the SETUP menu. MICRODIGITAL...
