Summary of Contents for Digimax 210
- Page 1 Digimax 210 Programmable Thermostat Compatible with Maxi Controller User Guide...
- Page 2 RF code which the Maxi Controller will learn during the installation process (see §8b). This code will assure that the Maxi Controller will only answer to messages sent by your DigiMax 210. This process is described at the end of this manual. 1) To start : Remove the battery insulation strip and check unit is func- tioning.
- Page 3 30 meters Please read all installation instructions before proceeding. The RF DigiMax 210 works with batteries. It does not need any wire. If you wish it to replace an old cable thermostat, isolate and secure the old wires, which are useless now. Do not forget to cut the power when you take off the old thermo- stat.
- Page 4 4) Position The ideal position to locate the DigiMax 210 is about 1.5m above floor level, accessible, free from extremes of tem- perature and draught. Do not mount it on an outside wall, above a radiator or where it may be subjected to direct sun- light.
- Page 5 4. Replace batteries being sure to observe the correct polarities. Re-fit to plastic base and tighten retaining screw. Check unit is functioning as required. RF DigiMax 210 Rear View Link 2 Link 1 Batteries Cut Link 1 for 16°C minimum set point...
- Page 6 7) Battery replacement A “flashing” battery low symbol will appear at the bottom left of the display when the batteries start to approach the end of their life. This indicates that they should be replaced within the next month. Ultimately, the display will start flashing and the thermostat will shut down until the batteries are replaced.
- Page 7 8) Connection to the the Maxi Controller a) General operation You can connect up to 4 DigiMax 210 to the Maxi Controller. Depending on the information sent by the thermostats, the Maxi Controller will send X10 messages on the power line to turn On or Off X10 modules connected to your heaters or boiler.
- Page 8 2. To install a thermostat with the console, press and hold its + and - keys together for 3 seconds. The DigiMax 210 will then transmit its unique digital code every 10 seconds for the next 5 minutes. The display will show flash ‘]]]’...
- Page 9 - thermostat on zone 2 will generate message on code B2, - thermostat on zone 3 will generate message on code B3, - thermostat on zone 4 will generate message on code B4. If the console is on Housecode B, - thermostat on zone 1 will generate message on code C1, thermostat on zone 2 message on code C2 etc...
- Page 10 5. Dial via the phone “99#”, you will hear 3 short confirmation beeps. 6. The setback differential is now applied to the comfort setpoint. Apply the comfort setting 1. Call the security console from a touch tone or mobile phone. 2.
-
Page 11: Ec Declaration Of Conformity
2. Operating troubles If the boiler does not work on the request of the security console, check the battery symbol on the DigiMax LCD. Change the batteries if necessary. If the display does not operates, it means that you probably missed the low bat- tery symbol on the LCD : replace the batteries.
