- Page 1 AIR SOURCE HEAT PUMP ( All in one type ) TOP DISCHARGE WITH DOUBLE DUCTS Installation And Operating Instructions MODEL : KS25-C120 / KS25-C150 / KS25-C200 KS35-C300 FEB 2010...
- Page 2 THE 6 ESSENTIAL POINTS Control the delivery: before any handling, to check the state of the heat pump after having removed the packing of protection. Any degradation related to transport will have to be announced on the form of transport and by Letter Registered AR under 48 hours to the conveyor.
-
Page 3: Table Of Contents
CONTENTS Security consign ….………………………………………………….……..……………………….…………p 4 Description of the heat pump 2-1 Outside..……………….………………….…………………………………………………….………. p 6 ..……………….………………….…………………………………………………….………. p 7 2-2 Inside 2-3 Dimensional and technical characteristics …..…………….……………………………………………. p 8 Fitting and putting into service of the heat pump 3-1 Rules of establishment ……………………….………………………………………..……………… 3-2 Hydraulic connections…………..…….………………..……...…………………….…………..……... -
Page 4: Security Consign
1-Security consign Any wrong handling can cause an important risk Any wrong handling can cause an important risk being being able to result in death Any wrong handling can cause serious damage to the user and the machine TO NOT DO To follow attentively To be sure of the electric connections To be sure of the disconnection of the plug... - Page 5 CAUTION climb unit Keep out of the reach of children do not let us move when playing installed. near the unit. Never introduce a stick, your finger or others Important: Well clean the plug in the If dirtiness adheres to the plug or if it is badly inserted: air inlet/outlet.
-
Page 6: Description Of The Heat Pump
2- Description of the heat pump 2-1 Outside: Power Plug Control pannel Air Inlet Air Outlet Temperature Sensor Drainage hole Cold Water Inlet Hot Water Oulet Service valve solar coil inlet * solar coil outlet * Electrical heater *... -
Page 7: Inside
2-2 Inside: Control panel cover Gas returning pipe Drainage Pipe Power plug Exhaust pipe Rubber Cover Clip of Power Cable Filter Electrical heater * Auxilliary capillary Plastic Base Capillary Defrost sensor Water tank Assistant unit of air outlet Motor Capacitor Compressor capacitor Fan motor Compressor... -
Page 8: Dimensional And Technical Characteristics
Dimensional and technical characteristics: Sort Code KS25 KS35 Model Code C120/C150/C200 C300 Rating Heating Capacity (KW) 2.68 3.40 Rating Heating Power Input (KW) 0.85 1.09 Heating Current Refrigerant ( R410A ) Compressor Quantity Fan Quantity Noise dB(A) Temperature of output water 10-60 10-60 Unit Net Dimension... -
Page 9: Fitting And Putting Into Service Of The Heat Pump
3- Fitting and putting into service of the heat pump 3-1 Rules of establishment: Many measures define the place of the appliance; it is essential to respect them: Electric and hydraulic connections must be carried out according to national wiring regulation. The appliance must be installed outside. -
Page 10: Hydraulic Connections
3-2 Hydraulic connections: Refer imperatively to the diagram below: Connect the mouth for hot- water- in to the water tank with PP-R pipe, with other metal pipe. Pay attention to heat preservation if use metal pipe. Install water filter and one-way valve in the Tap water pipe, then connect the tap water pipe to the tank mouth of tap water inlet. Fill water into the tank: Open the tap- water-in valve to fill water;... - Page 11 Many system-design options for architects Option A: -Installation in the heating room. -Hot water heating from room air. -Optional use: cooling of the food storage or wire cellar. cooling of the room of your choice. Option B: -Installation in the laundry washing room. -Hot water heating from room air.
-
Page 12: Electric Connections
Electric connections: CAUTION: before connecting the appliance, make sure that the supply power line is disconnected from the network. Characteristics of the general power supply: mode of neutral TT and TN.S; the circuit of heat pump must be connected to an earthing circuit Connections: The electric installation must be carried out by a professional qualified (like an electrician) according to the rules and standards in force in the country of installation. -
Page 13: Description Of The Screen Of Display And Control
3-5 Description of the screen of display and control: 1 ) WITH WATER TANK ASSISTANT ELECTRICAL HEATER Description of the order and display panel : Two figures on the left : current temperature of the water tank Or two figures on the right : desired temperature Light of heat pump running 35 45 Light of electric heater running... -
Page 14: Use In Standard Mode
4- Use in standard mode Starting Operation Press " " button, and when the unit receives the signal, it gives out two " beep " tones, the operation is on and the heat pump water heater stars operation. If the interval shorter than 3 minutes from last shut down to the present switch-on, the compressor only restarts after 3 minutes to protect the system. - Page 15 Adjustment of the defrosting 1-Press on “ ” for 3 seconds , you can see (for example) MODE HEATER The first number is the symbol of the item; and the second value is the setting value of the current item. ”...
-
Page 16: Instruction For The Fitter
5- Instruction for the fitter: The fitter has to read the following notice and explain the instructions to the user. Devices of control and safety: The heat pump is equipped with: 2 control devices: A defrost temperature probe located on the evaporator, starts the defrost sequence. A thermal probe located on the exchanger, ensures the cut of the heat pump when the temperature of the water reaches the temperature instructed The meaning of code name:... -
Page 17: The Defaults Messages And What To Do
5-4 The defaults messages and what to do: Failure code: E1: sensor for T1(water temperature) failure E2: sensor for T2(ambient temperature) failure E.01 E3: sensor for T3(exhaust temperature from compressor) failure E4: sensor for T4(coil temperature in condenser) failure H EAT I N G DEFROST HEATER H EATER... -
Page 18: Gas Flow Diagram
8 – Gas Flow Diagram... -
Page 19: Wiring Diagram
9 – Wiring Diagram Without Water Tank Electrical Heater WIRING DIAGRAM BLACK WHITE B L U E (BLUE) B L U E B L U E BLUE 0UT5 0UT6 OUT3 OUT4 4WV1 4WV2 0UT7 COMPRESSOR TEMPERATURE 0057W AMBIENT TEMPERATURE WATER TEMPERATURE COPPER SENSOR... -
Page 20: Problems / Solutions
10 Problems / solutions : The difficulties met the most often can be solved by reading the table below. If nothing corresponds to the list, or if the solutions applied do not solve the problem, refer to the notice or contact your retailer. Problem Observation Probable cause...
