HD-TVI IR High Speed Camera
Operation Manual
Prior to operation, please carefully read this manual！


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD58NV-IRTVI20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for COP-USA CD58NV-IRTVI20

Summary of Contents for COP-USA CD58NV-IRTVI20

  • Page 1 HD-TVI IR High Speed Camera Operation Manual Prior to operation, please carefully read this manual！  ...
  • Page 2 Safety attentions: Caution: Electric shock, Do not open Caution: For preventing electric shock, no removal without authorization, no parts inside may be repaired by the users themselves, which may be only done by the qualified staff. A flash of light in equilateral triangle is used for reminding user that “there are non-insulated dangerous voltage points nearby this product”, endanger the personnel safety.

  • Page 3: Table Of Contents

    CONTENTS Attention ………………………………………………………………………………………………………………………………………………………………….5 Chapter I Functions and features ……………………………………………………………………………………………………………………………………7 1.1 Dome Specifications………………………………………………………………………………………………………………………………………………..7 1.2 Auxiliary lighting…………………………………………………………………………………………………………………………………………………..8 1.3 Dome functions………………………………………………………………………………………………………………………………………………………9 Chapter II Network menu Setting..………………………………………………………………………………………………………………………………………11 2.1 System connection diagram………………………………………………………………………………………………………………………………………11 2.2 ONVIF Discovery Tool configuration camera IP address………………………………………………………………………………………………………11 2.3 Log in the network………………………………………………………………………………………………………………………………………………….13 2.4 Video Activex install…………………………………………………………………………………………………………………………………………………15 2.5 Video preview……………………………………………………………………………………………………………………………………………………….17 2.6 Device parameters…………………………………………………………………………………………………………………………………………………..23...
  • Page 4 Warning………………………………………………………………………………………………………………………………………………….46 Ambient requirements…………………………………………………………………………………………………………………………………….46 Cabling safety………………………………………………………………………………………………………………………………………………….47 Installation preparation………………………………………………………………………………………………………………………………………….47 4.6 Installation ways…………………………………………………………………………………………………………………………………………………..48 4.7 Installation description………………………………………………………………………………………………………………………………………………..49 4.8 Outgoing lines of DOME…………………………………………………………………………………………………………………………………………51 Annex I: Troubleshooting……………………………………………………………………………………………………………………………………………………53 Annex Ⅱ:24VAC line gauge and transmission distance relationship…………………………………………………………………………………………………54 Annex Ⅲ: Lightning and surge protection………………………………………………………………………………………………………………………………….55 Annex Ⅳ: Maintenance of the terms of service………………………………………………………………………………………………………………………….57  ...

  • Page 5: Attention

    Attention  Electrical safety The installation and use of this product must strictly comply with national and local electrical standards. It has self-provided power supply. Power is supplied to the product in two modes: DC12V (on-board) and AC24V (ordinary DOME) (refer to product identification or connecting line identification).
  • Page 6  Installation request  Install the device at a location with sufficient bearing capacity.  Do no store, install or use the product in an inflammable, explosive and dangerous area.  Do not install the product beyond the specified temperature, humidity or power specification. Do no remove any internal component of the DOME lest it might affect the use.

  • Page 7: Chapter I Functions And Features

    Chapter I Functions and features 1.1 DOME Specifications Power supply AC24V 2.5A Power consumption Preset position 255pcs Cruising 8group, each group contain 255 presets 8pcs, each pcs can record 1024pcs DOME order Pattern 1channel alarm input, 1channel alarm output Alarm 8 area Privacy mask DOME according to current zoom to change manual control...

  • Page 8: Auxiliary Lighting

    1.2 Auxiliary lighting  Optional accessories Infrared illuminant High brightness LEDx36pcs Wavelength 850nm Projection distance >100m Ordinary infrared Power consumption Control of the infrared lamp Auto/manual Life of the infrared lamp >20000h 8 ...

  • Page 9: Dome Functions

    1.3 DOME functions The network DOME camera is an embedded digital surveillance product integrating a megapixel high-definition camera, a universal speed-variable DOME and a network video server. It is a real HD IP camera, supporting a resolution of above 720p(1280*720),contain 11920*1080P resolution. It adopts an embedded LINUX operating system and has high efficiency in system dispatching and high stability and reliability.
  • Page 10 changed with the visual angle of the integrated machine synchronously, ensuring the infrared lamp is not wasted and does not have an effect of a flashlight. It maximally uses infrared light and overthrows the conventional practice of tens of watts and large volume. ...

  • Page 11: Chapter Ii Network Menu Setting

    Chapter II Network menu Setting 2.1 System connection diagram 2.2 ONVIF Discovery Tool configuration camera IP address In system CD,we support ONVIF Discovery Tool for user, it can used for device management test:  Search IP camera or Video server device which in the network ...
  • Page 12 Run ONVIF Discovery Tool management tool,auto searching avaliable IP camera in current network. List IP address,UUID、Hardware..etc.information. Due to each camera from factory, all the ID address are the same,so if before install Ip camera, you can use ONVIF Discovery Tool to configurate IP address.

  • Page 13: Log In The Network

    Test whether connected After setup IP address, click left bottom of PC: Start--all program--attachment”,open”Command Prompt”,use PING command to test whether PC has connected with IP camera. Command as: Ping 192.168.1 .8 If screen show“Request timed out.”or” destination host unreachable”,it means install not OK.Pleae check below: ...
  • Page 14 When through IE brower to preview IP camrea’s image, need install VLC.EXE software firstly, after install, open IE, input IP address (Default: 192.168.1.8),Enter into login interface. In login interface,input IP camera’s username(Default: Admin),Password(Default: 888888) ,you can choose remember username and PW,then click”...

  • Page 15: Video Activex Install

    2.4 Video Activex install Log into user interface, you can click top right”Player download” Interface will popup player download dialog box,shown as right Picture,choose”Run”, will popup below dialog box: Click’Run”,install video Activex. 15 ...
  • Page 16 Click “Next” ,continue install Choose a disk to install this software, then click”Install”, Continue install. 16 ...

  • Page 17: Video Preview

    After install,as right picture,Click”Close”,finish Install, close IE. Then Login DOME IP address, can view video. Ps: If your Activex in your PC is old version, IE will popup information, to ask you install newest Activex version. 2.5 Video preview 17 ...
  • Page 18  Note：It always has delay if transmission by IP, it depends on user’s PC CPU and qualities of switcher and router.Normally, MP IP video has <500ms delay. Area 1: Toolbar: Click into corresponding function ICON Explan Enter the image code stream, DOME, camera control interface Into network parameters and speed dome function Settings Enter the picture management or local video playback and download...
  • Page 19 2.5.1 DOME control After open preview image, each key in the right of interface means: Speed key Setup DOME totate speed. ① Direction Control DOME”up,top left,top right,down,left bottom,right bottom,right,left. Click ② icon,can call OSD menu Zoom Change lens zoom(invalid for auto Zoom camer) ③...
  • Page 20 2.5.2 Camera spcification After open device preview, choose right side “Camera”, specification as below:(Different camera module, specification will different) Display camera brand Camera brand Display camera model Camera model ON/OFF D-zoom Zoom speed Auto/Manual Focus mode Day/Night/Auto ICR Mode Auto/Manual/SP/AV AE Mode 1-1/10000 Shutter speed...
  • Page 21 2.5.3 Advanced setup After open device preview, choose”AUX”, specfication is as bleow: Night vision Mode OFF/ON/AUTO Period 0-60 Threshold 0-252 Gain 0-64 Wiper Mode One /limit/N time Time 10-600 Start Start wiper Stop Stop wiper Other Defrost User hearter to defrost 21 ...
  • Page 22 2.5.4 Image setup After open device preview, choose”Image”, specfication is as bleow: Noise reduction Enable Disable/ON/Auto Mode 2D/3D/3D+/Strong noise reduction/Mixed noise reduction Level 0-168 Edge enhance Enable Disable/ON Level 0-31 Image adjust Brightness 0-127 Contrast 0-127 Saturation 0-255 Flip Image up and down prevision 2.6 Device parameters Mirror...

  • Page 23: Device Parameters

    Go into <Device parameters>→<Network parameters>.then you can setup network parameters. As other IP device, connect and use IP caemra, must let IP camera’s IP address Full-Mesh as user PC’s IP address. Please note that: In the sameLAN, IP address can not be the same, it will has clash, and let device can’t work. After modity IP address, click”SAVE”...
  • Page 24 device ID is when the caemra catch alarm information, will according to this ID to send alarm information. Note: All the paramerters are provide by 28181 device, details please ask28181 server manager. 2.6.3 Stream setup Enter<Device parameters>→<Stream setup>, can setting stream 24 ...
  • Page 25 Stream type: Main stream, sub-stream,both of them are video stream, also can do customize setting for size,frame,rate,Frame interval, level. All these seting are used for adjust video (or preview) image quality and storage file bit. Main stream are default choose, sub-stream can be choose, but not default choose. Full frame rate is default output frame rate of camera,MAX.frame rate Frame interval: also means Keyframe, 1 frame interval, will influence with image quality and stream.
  • Page 26 2.6.4 Record setting After enabled manually video, can make control front-end device video effective. Default,front-end video function not enabled. Video mode has 3 kinds manual record, when manual click in”Real-time video interfac”--”Record control” . Alarm record, when trigger alarm, automatic record. Timing record, according to order plan to timing record.
  • Page 27 When record time too long, can make video file integral point automatic subdivision,this can convenience to search or playback image file. When TF card’s free space is lower than setting value, will stop record or automatic to delete oldest record file then record again. 2.6.5 Video setup Input can set as 1080P25、1080P30、720P50、720P60, change this option will change camera video type,and influence coding and ouput video.
  • Page 28 2.6.6 Alarm setup  Alarm input attribute contain high level and low level. Please accrording to input alarm device and real used control type to choose best suitable attribute. Normally close: Normally open circuit, when alram signal trigger connect circuit; Normally open: Normally short out, when alarm signal trigger switch off circuit.
  • Page 29 2.6.8 Other setup  Auto flip: When camera come to the tilt position, pan can auto run 180°, ON/OFF for option.  Speed limit: When camera in high zoo, DOME or speed dome will automatic let speed slow, ON/OFF for optiona. ...
  • Page 30 2.6.9 Interface setup Hide character which on the top left of preview interface(OSD menu can are all hide both in analog image or IP image)/Image mode(Display image mode OSD menu)/TXT mode(Display TXT mode OSD menu)、subtitle position, typeface’s size, edge distance,code flow superposition, and other thing to edit. Edge distance means preview interface top left character the distance of video edge.
  • Page 31 When chooseTXT mode will display below function menu, superposition divide to 3 TXT subtitle, TXT content can be custom English or Chinese or anyother character, also can be DOME or speed dome buit-in common variations,through variations can catch some dynamic information. For instance: In “connect”...
  • Page 32 2.6.10 System setup It can setup timezone, local time,PW. Click”Restor factory setting” will change to factory setting. Click”Reboot” ,device will auto re-start. Before update, please confirm that updata routine is copy in PC, choose”Browse” to add update file, click”upload”,screen will display above dialog box” This could take a few minutes,please be patient!”...

  • Page 33: File Management

    Time quantum not write anything, Click search directly, will display all file which storage in TF.It can display: file name, time, file size, type,support file’s download and delete function. means this file is video, click this icon will open video file to palyback, click will back to file management interface.
  • Page 34 Version: ROM display is whole device’s version, this is main version. GUI display isGUI module’s version, this module contain interface,DOME  control, protocol. MOTOR display is motor board’s software version, through this information canconfirm motor board is suitable for main control module or not. ...

  • Page 35: Chapter Iii Osd Menu Setup

    Chapter III OSD menu setup (This menu can display on screen and IE interface,call 64 preset or click DOME which in the middle of direction control, as below menu, up and down joystic control move, left and right is enter or choose menu) 3.1 Main menu Language：Language setup,Chinese and English two kind language for option.
  • Page 36 3.3 Camera setup  CAM Params: Enter camera parameters setup sub-menu  D-zoom: Setup digital zoom. ON/OFF  Zoom Speed: Zomm speed 0-7 adjustable. Focus Mode: Camera focus mode,auto/manual   ICR Mode: Low light setup, day/night/auto  AE Mode: Manual/Auto/shutter priority/IRIS priority ...

  • Page 37: Dome Setup

     Clear: Clear setting and return  Save: Save setting and return.  Image Enhance(Back end):Enter image setup sub-menu  NR: Denoise, ON/OFF/AUTO NR Mode: Setup denoise mode: 2D,3D,3D+,strong noise reduction,superposition of noise reduction  NR level: 0-168 level  EE: Edge enhance, ON/OFF ...
  • Page 38  Clear: Clear and return  Return: Save and return  Patrol setting: Enter patrol setup sub-menu  Patrol: 1-8 for option, when run patrol 1, can setup patrol 1  Title: Setup patrol titl, it has Chinese and English and No. And punctuation mark. etc. ...
  • Page 39 Scan Setting: Scan No. Choose,1-8 for option.   Scan Speed: Setup scan speed. 1-8 speed for option. Can set each scan.  Limit Edit: Setup scan’s start and end, then when enter, use joystic to move DOME. Press OPEN key to save current position and return. ...
  • Page 40 Schedule setting: Enter schedule setting sub-menu   Schedule No.: Schedule 1-8 for option. Title: Enter schedul No., can setup schedule title,it has Chineese,English,No.punctuation mark..etc. Date: Schedule edit,setup Sunday--Satday   Time: Schedule time edit Start hour: Start time setup, hour choose Start min: Start time setup, min.
  • Page 41  Clear: Clear configuration and return.  Return: Save configurate and return.  Alarm setting: Enter alarm setup sub-menu  Alarm:1 alarm  Title: Enter alarm title, can setup alarm title,it has Chinese,English,No. Punctuation mark...etc  Alarm Trigger: Choose trigger alram’s condition, normally open /Normally close for option. ...
  • Page 42 NV mode: Auto,ON,OFF   Nv CYCLE: Night vision surveillance cycle time setup,1-60s for option.  NV Threshold: Photosensitive resistance strength 0～255 for option.. When light is lower than this value, night vision device will auto open.  NV Gain: Adjust night vision light ,0-64 for option. ...

  • Page 43: S Y S T E M S E T U

    this option OFF.  Park time: Set park action time,means in how many time if DOME or speed dome do not be controled, it iwll be back to orignal point, 1-99mins for option.  Patrol freeze: During patrol, freeze image, ON/OFF for option. ...
  • Page 44 OSD position: Default Top left,Middle top, Top right, left Middle,right,left bottom, right bottom for option.   Font Size: 12-28 for option  Edge: 0-128 for option.  Margins: Save setting and retun. Cancel: Cancel setupt and return.   Network setting: Enter network setup sub-menu ...
  • Page 45  Input format:Setup input format:1080P25/1080P30/720P50/720P60 for optiona.  OK: Save and return.  Cancel: Cancel setup and retun.  Compas setting: Setup North. Correct setup north, When DOME run, can display current direction. Total 8 direction can display.  Factory setting: Setup back to factory setting sub-menu. ...

  • Page 46: Chapter Iv Dome Installation Description

    Chapter IV DOME Installation Description 4.1 Safety measures 4.1.1 Qualification of installation or maintenance workers  Submission of qualification certificate for CCTV system install or maintenance, and qualification certificates for relevant works (such as high altitude operations etc), these workers must have the following elementary knowledge and skills; ...

  • Page 47: Cabling Safety

    4.4 Cabling safety  The signal transmission lines must keep a distance of at least 50m from high-voltage devices or high-voltage cables.  Outdoor cables should be laid under eaves if possible.  In open fields, cables shall be laid in sealed and earthed underground steel pipes and aerial cabling is forbidden. ...

  • Page 48: Installation Ways

    4.5.4 DOME power-on self-test To ensure normal operation of the DOME on the installation site, please connect the system control lines, video lines and power lines of the DOME into the corresponding sockets before installation (the wiring shall strictly comply with the labeling instructions of system control lines, video lines and power lines) and do power-on self-test.

  • Page 49: Installation Description

    IR HIGH SPEED DOME CAMERA (Wall mounted) 4.7 Installation description For the wall installation, should be with the wall bracket. The wall for installation must be without delaminating,to make sure that the bracket is fixed on the wall, not the surface cover. 1) Unpacking and take out the dome camera and its accessories with care.
  • Page 50 3) Please use lash electric drill fix 4 pieces M8 metal inflation bolts hole, and then fix inflation bolt tube.(Figure 5) 4) Make the hole from the wall in the middle position of the bracket, which is used for connecting the cable. Then let the cables together through the wall and pull to the outside;...

  • Page 51: Outgoing Lines Of Dome

    4.8 Outgoing lines of DOME  Comprehensive line qualification is shown in figure 10 Fig. 10 Note: Marking of alarm lines 51 ...
  • Page 52 2) Outgoing lines of alarm Alarm control lines are connected as shown in Fig. 11. After the DOME identifies an alarm signal, it may immediately start the camera according to the setting of the program and switch the images of the alarm zone to the main monitor. The dome at the alarm point is adjusted to monitor the preset recording points and record the situation of the alarm zone in the fastest way.

  • Page 53: Annex I: Troubleshooting

    Annex I: Troubleshooting Problem Phenomenon Possible cause RS485 line port connect wrong. Can’t control DOME Control protocol,ID or baud rate in RS485 of IP camera not same as DOME IP camera’s IP address had been modified. If yes, please use ONVIF Can’t connect IP camera Discovery Tool to test IP and re-set IP address.

  • Page 54: Annex Ⅱ:24Vac Line Gauge And Transmission Distance Relationship

    Annex Ⅱ: 24VAC line gauge and transmission distance relationship If the line gauge is specified, and the loss of 24VAC voltage is less than 10%, the recommended maximum transmission distance is shown as table below. (For AC equipment, the maximum permissible voltage loss is 10%. For example: the rated power of one equipment is 80VA, installed at the place 35 feet away from the transformer (10m), the required minimum line gauge is 0.8000mm.

  • Page 55: Annex Ⅲ: Lightning And Surge Protection

    23（7） 37（11） 59（17） 150（45） 21（6） 34（10） 55（16） 139（42） 20（6） 32（9） 51（15） 129（39） 18（5） 30（9） 47（14） 120（36） 17（5） 28（8） 44（13） 113（34） 16（4） 26（7） 42（12） 106（32） 15（4） 25（7） 39（11） 100（30） 14（4） 23（7） 37（11） 95（28） 14（4） 22（6） 35（10） 90（27） Annex Ⅲ: Lightning and surge protection This product adopts TVS pole lightning-proof technology to effectively protect against the damages of pulse signals such as transient lightning below 1.5KW, and surge etc to equipment.

  • Page 56: Annex Ⅳ: Maintenance Of The Terms Of Service

    The system must be equal potentially earthed. The earth device must comply with both system anti-interference and electrical safety requirements, and  not short-circuit or mixed with zero line of strong current grid. When the system is individually earthed, its earth impedance should be not more than 4Ω, with the section area of earth conductor not more than 25mm Annex Ⅳ: Maintenance of the terms of service...
  • Page 57 The problems due to force majeure (such as war, earthquake, and lightning), wrong or misused operations and modification, normal wearing or  accidents are out of warranty; The manufacturer shall be not responsible for damages or loss due to specified using or applications of product. The liability of manufacturer for ...
