Ultrasonic nebulizer

Advertisement

ULTRASONIC NEBULIZER
Instruction Manual
PLEASE READ AND SAVE
THIS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aroma art and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Saje Aroma art

  • Page 1 ULTRASONIC NEBULIZER Instruction Manual PLEASE READ AND SAVE THIS MANUAL...
  • Page 2 ULTRASONIC NEBULIZER ATOMISEUR ULTRASONIQUE Live healthier by improving the quality of air you breathe.
  • Page 3: Table Of Contents

    TABLE OF CONTENT Benefits of Nebulizing Diagram of Parts Specifications Operating Instructions Cleaning & Maintenance Cautions & Safety Instructions Troubleshooting Savings Coupon...
  • Page 4: Benefits Of Nebulizing

    BENEFITS OF NEBULIZING Diffusing essential oils releases into your living space the same tranquil qualities of negatively charged electric ions that you experience being near the ocean, helping to relieve feelings of stress, anxiety and low energy. Negative ions are essential to our body for sustaining and improving our general health;...
  • Page 5: Diagram Of Parts

    DIAGRAM OF PARTS 1. Cover 2. Water Tank 3. Unit Base 4. Maximum Water Level 5. LED Lights 6. Mist Setting Indicators 7. Mist Nozzle 8. Light Button 9. Mist Setting Button 10. Power Adaptor 11. DC Power Jack 12. Air Outlet 13.
  • Page 6: Specifications

    SPECIFICATIONS Product Name aromaArt 100 - 240 volts AC 50/60 HZ Input Voltage Output Voltage 18 Volts DC 500 mA Rating Power 9 Watts Water Tank Capacity 600 ml High: Approx. 12 hrs. Misting Duration Low: Approx. 18 hrs. Suitable area 10-15 m2 Dimensions 190 mm (D) x 200 mm (H)
  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS 1. Connect power adaptor to DC power jack on back of unit. DO NOT EXCEED MAX. 2. Remove the cover from the WATER LINE (600 ML). unit base to expose water reservoir. Please note: unit will shut off automatically when water level reaches the top of water sensor 3.
  • Page 8: Light Button

    4. Add 10 drops of your favourite 5. Replace the cover and ensure Saje diffuser blend to the water. that it fits properly onto base. 6. Press the control buttons and select desired settings Light button: Mist setting button: Controls mist output levels Controls 3 LED between low and high;...
  • Page 9: Cleaning & Maintenance

    CLEANING & MAINTENANCE 1. Turn off unit and unplug power adaptor. 2. Remove cover. Air outlet 4. Use a soft cloth or clean swab to clean the unit and transducer. Transducer should be kept clean of 3. Empty water from left side mineral deposits and other debris of unit.
  • Page 10: Cautions & Safety Instructions

    CAUTIONS & SAFETY INSTRUCTIONS Only use the power adaptor supplied with the device. • Use only as described in this manual. To reduce the risk • of electric shock, do not attempt to service the device in any way other than as described in the “Cleaning & Maintenance”...
  • Page 11 Do not to touch the highly sensitive transducer with bare • fingers, or scrape it with metal tools (otherwise mist output may be reduced). Remove any liquid in the water tank after each use. • Do not attempt to repair the device yourself. •...
  • Page 12: Troubleshooting

    TROUBLESHOOTING symptom possible cause solution The adaptor is not properly Plug in the adaptor correctly. plugged. No power The mist on/off button is Depress the button again. not depressed. No water or too little Fill water thank to max. No mist water in the water tank.
