REVBOX Erg Owners Manual
Introduction
Congratulations on the purchase of your new Revbox Erg – a low inertia stationary air resistance
trainer with no flywheel assistance; designed, developed and assembled in New Zealand.
The Revbox will make you stronger and more efficient as it recruits and engages all the muscle
groups throughout your pedal stroke, increasing strength and neuromuscular efficiency, and fo-
cuses your pedaling technique.
Welcome to the Revbox Community!

In the Box

Your Revbox Erg should come with the following:
1 x Revbox trainer unit
1 x Stabiliser leg
1 x Short quick release skewer for the stabilizer leg
1 x Long quick release skewer to mount the bike
1 x Velcro fastened carry handle which can/should be removed if not required
1 x 0.7mm cassette spacer
The following optional parts are also available:
Miche 10 speed cassettes different ratios (Shimano Compatible) (Different Ratios Available)
Revbox soft carry bags
Revbox foam carry bag for international travel
To purchase any of these see: http://www.revbox.co.nz/shop

Set-Up

To prepare your Revbox Erg for use, please set it up as follows:
1. Take your new trainer unit and stabiliser leg out of the box.
2. Fit the short quick release skewer to lower front of Revbox unit.
3. Attach the stabilizer leg to the Revbox unit using this short quick release skewer – make
sure the leg is pushed in as far as possible, so there is almost no gap (See Image 1) between the
leg and the unit, and the guide plates are resting on the stops (See Image 2), then tighten the
skewer as tight as possible to fix the stabiliser leg securely in place.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Erg and is the answer not in the manual?

Questions and answers

Summary of Contents for Revbox Erg

  • Page 1 REVBOX Erg Owners Manual Introduction Congratulations on the purchase of your new Revbox Erg – a low inertia stationary air resistance trainer with no flywheel assistance; designed, developed and assembled in New Zealand. The Revbox will make you stronger and more efficient as it recruits and engages all the muscle groups throughout your pedal stroke, increasing strength and neuromuscular efficiency, and fo- cuses your pedaling technique.
  • Page 2 (This is usually easiest achieved with the gears set in the smallest sprockets). 7. Adjust the rear foot of the Revbox so it sits flush against the floor – this is most accurately achieved with a rider on the bike.
  • Page 3 Transport and Care When transporting the Revbox please make sure to: 1. Keep it properly secured – we recommend the use of the optional Revbox soft carry bag to keep all the parts protected from harm. 2. Use the supplied Velcro fastened carry handle to lift the Revbox, making sure that the Velcro is fully secured with your thumb (See Pic 6) on the front side.
  • Page 4 Image 1 Image 2 Image 3 Image 4 Image 5 Image 6...
