- Page 1 Carl Zeiss Sports Optics Victory 8 x 26 T* PRF Gebrauchshinweise Instructions for use Mode d’emploi Istruzioni d‘impiego Mode de empleo Bruksanvisning Informacje dotyczące użytkowania Инструкция по применению Használati utasítás We make it visible.
- Page 2 Victory 8 x 26 T* PRF Congratulations on the purchase of your new laser range finder. Carl Zeiss brand products are characterised by outstanding optical perform- ance, accurate processing and long durability. Please observe the following instructions for use, so that you enjoy optimum use of your product and it can be a faithful companion to you for many years.
- Page 3 Instructions for use Caution Use only battery types recommended by the manufacturer. Handle used batteries in accordance with the manufacturer’s instructions. Under no circumstances should batteries be thrown into a fire, heated up, recharged, taken apart or broken open. User information for the disposal of electrical and electronic equipment (private households) This symbol on products and/or accompanying documents indicates that used electrical and electronic products are not to be mixed with ordinary...
-
Page 4: Table Of Contents
Victory 8 x 26 T* PRF Table of contents Identification of the components ....... 17 Scope of delivery . -
Page 5: Scope Of Delivery
Instructions for use Scope of delivery Laser range finder Eyepiece cap Pouch Carry cord 3V type CR 2 lithium battery Optics cleaning cloth Instructions, guarantee card Preparation Inserting/Removing the battery The laser range finder is powered by a type CR 2 lithium battery. To insert and replace the battery, unscrew the battery cover (Fig. -
Page 6: Attaching The Carry Cord
Victory 8 x 26 T* PRF Attaching the carry cord To attach the carry cord, thread it through the carry cord eyelet (Fig. 3/8) – as shown in the illustration. Observation with and without glasses When observing without glasses, use the equipment with the eye cup extended. -
Page 7: Focusing The Aiming Mark
Instructions for use Focusing the aiming mark Use the RANGE FINDER button (Fig. 1/3) to switch on the aiming mark (Fig. 4/9) and hold down the button. Focus the aiming mark and the display (Fig. 4/10) by turning the diopter compensation (Fig. 1/2) to the left or the right. -
Page 8: Scan Mode
Victory 8 x 26 T* PRF Scan mode The equipment can also be used to measure in constant operation (scan mode). If the range finder button (Fig. 1/3) is pressed for longer than approx. 3 seconds, the equipment switches to scan mode and takes measurements continuously. -
Page 9: Selection Of The Appropriate Ballistic Programme
Instructions for use The correction value for the aiming point is displayed approx. 1.5 seconds after the range. A preceding “H” means that higher aiming is required (Fig. 5) and a preceding “L” means that lower aiming is required. The display is given in centimetres for the EU settings and in inches for the US settings. -
Page 10: Determining The Correct Trajectory Path
Victory 8 x 26 T* PRF Example: Example: Program EU 2 is selected: Programm EU 2 is selected: Bullet drop according Bullet drop according to ballistic curve 2, to ballistic curve 2, range display in metres, range display in metres,... - Page 11 Instructions for use Further information and assistance on this topic can be found on our website http://www.zeiss.de/sportsoptics First select the appropriate table for you, depending on the riflescope sight in distance: Sight in distance Table to be used 100 metres Table 1 SID/GEE (corresponds to approx.
- Page 12 Victory 8 x 26 T* PRF Table 2: Selection of the trajectory path for range specifications in metres and a sighting in at SID/GEE. Curve Range selection in metres EU 1 0.3 – 7.1 – 19.2 – 36.5 – 59.3 – 126 EU 2 –...
-
Page 13: Care And Maintenance
Instructions for use Care and maintenance The laser range finder requires no special care. Do not wipe off coarse dust (e.g. sand) from the lens, but rather blow it off or remove it using a fine animal-hair brush. Fingerprints may affect the lens surfaces after a time. The easiest way to clean lens surfaces is to breathe on them and rub them using a clean optic-cleaning cloth. -
Page 14: Technical Specifications
Victory 8 x 26 T* PRF Technical specifications Victory 8 x 26 T* PRF Magnification Lens diameter 26 mm Exit pupil diameter 3.25 mm Twilight number 14.4 Field of view at 1000 m/yd 110 m/yd Diopter adjustment range ± 3.5 dpt Exit pupil relief 17.5 mm... - Page 15 Consult the dealer or an experienced radio/ TV technician for help. Carl Zeiss Sports Optics GmbH is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Carl Zeiss Sports Optics GmbH.
