Summary of Contents for ADS ADS9908
- Page 1 ADS9908 Auto Battery Analyzer User manual Copyright © ADS TECH All Rights Reserved http://www.ecutool.com...
- Page 2 Before you start ● The analyzer is designed to test 12/24 volt automotive batteries. It can not be used for other batteries. ● A freshly charged battery will show a higher voltage than normal voltage; if this is the case, switch on the headlights for two or three minutes to allow the voltage to stabilize. ●...
- Page 3 Instructions Preparation before the Test Before connection the tester, clean the battery posts or side terminals with a wire brush and a mixture of baking soda and water. IMPORTANT: Do not test a steel bolts. Failure to install terminal adapters or installing terminal adapters that are worn or dirty may result in inaccurate test results.
- Page 4 State of Health (Battery Condition) Battery Condition Test result displayed Advice SOH > 80% Great Battery in peak condition SOH 61%~80% Good Serviceable / good SOH 45%~60% Caution Poor condition --- will need replacement soon SOH < 45% Suggest Replace Replace battery Select if you want to print, Y to confirm, N to exit.
- Page 5 Maintenance Adjusting the date and time: ● Press and hold UP key then connect the tester to a suitable battery. ● Use Left and Right keys to select the parameter, then use the Up and Down keys to change. Press the Enter key when finished. Replacing the Thermal Paper Roll: 1.
- Page 6 Appendix: The Conversion Tables Of Battery Size Range Table 1 EN and DIN Conversion Tables Specification Specification Type Same Type Type Same Type 52805 52815 56420 56322 88066 53517 56530 56618 56638 53520 53521 53522 56618 56619 56620 53625 53638 53836 56633 56647...
- Page 7 55564 55565 55548 64028 64035 55570 55567 55565L 64036 56012 64317 64318 64323 56048 56068 56069 65513 56049 56069 56073 65514 65515 56077 56530 67043 67045 1000 56091 55800 68032 68034 1000 56111 55048 70029 70038 70027 1050 56218 55092 70036 68040 68021...
- Page 8 36B20LS NS40ZLS 95D31R NX120-7 38B20R NX60-N24 95D31L NX120-7L 38B20RS NT60-N24S 95E41R N100 38B20L NX60-24L 95E41L N100L 38B20LS NX60-24LS 105E41R N100Z 40B20L 105E41L N100ZL 40B20R 105F51R N100Z 42B20R 105F51L N100ZL 42B20L 115E41R NS120 40B20RS 115E41L NS120L 40B20LS 115F51R N120 46B24R NS60 115F51L N120L 46B24L...
