20G022-00 E2 – 2014-04-10

User Manual

®
G22 – 3U CompactPCI
®
Serial Intel
Core™ i7 CPU
Board
Configuration example

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MEN Mikro Elektronik G22

Summary of Contents for MEN Mikro Elektronik G22

  • Page 1: User Manual

    20G022-00 E2 – 2014-04-10 User Manual ® G22 – 3U CompactPCI ® Serial Intel Core™ i7 CPU Board Configuration example...
  • Page 2 DIN, EN or IEC industry standards. As an option, the board can be equipped with an M12 Ethernet connector. The G22 is also ready for coating so that it can be used in humid and dusty environments and has a guaranteed minimum standard availability of 7 years.
  • Page 3 USB 2.0 Board‐to‐Board  USB 2.0 Connector  (for Ethernet  Rear I/O Card) PCIe x1 USB 3.0 USB 2.0 CPCI‐ DisplayPort/HDMI USB 2.0 QM77 PCIe x1 Platform PCIe x1 Gb Ethernet Controller Hub PCIe x1 Gb Ethernet SMBus FPGA SFF‐8485 SGPIO DisplayPort/HDMI DisplayPort/HDMI SATA (6 Gb) SATA (3 Gb) USB 2.0 microSD Optionally switchable to rear connectors mSATA MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 4 - Four ports with transfer rates up to 3 Gbit/s (SATA Revision 2.x) - Two ports with transfer rates up to 6 Gbit/s (SATA Revision 3.x) - RAID level 0/1/5/10 support - Hot-plug together with G501 MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 5 • Two x1 PCIe® links to connect local 1000Base-T Ethernet controllers - Data rate 250 MB/s (2.5 Gbit/s per lane) • One x1 PCIe® link via for connection of the rear I/O card - Data rate 500 MB/s (5 Gbit/s per lane) MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 6 - PCB manufactured with a flammability rating of 94V-0 by UL recognized manufacturers - Insulation measurement test according to EN 50155 (12.2.9.1) - Voltage withstand test according to EN 50155 (12.2.9.2) - Information technology equipment test according to EN 60950 MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 7 • Dedicated Flash Storage Area Software Support • Windows® • Linux • VxWorks® (on request) • QNX® (on request) • For more information on supported operating system versions and drivers see online data sheet. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 8: Configuration Options

    • Intel® Celeron® • For more details regarding possible CPU options, please see Table 1, Processor core options for the G22, on page 26 Memory • System RAM - 2 GB, 4 GB, 8 GB or 16 GB (16 GB when components available) •...
  • Page 9 • Store the board only in its original ESD-protected packaging. Retain the original packaging in case you need to return the board to MEN for repair. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 10 "in" meaning "to the board or component", "out" meaning "coming from it". Vertical lines on the outer margin signal technical changes to the previous issue of the document. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 11: Legal Information

    About this Document Legal Information Changes MEN Mikro Elektronik GmbH ("MEN") reserves the right to make changes without further notice to any products herein. Warranty, Guarantee, Liability MEN makes no warranty, representation or guarantee of any kind regarding the suitability of its products for any...
  • Page 12 MEN. Users are nevertheless recommended to properly recycle all electronic boards which have passed their life cycle. Nevertheless, MEN is registered as a manufacturer in Germany. The registration number can be provided on request. Copyright © 2014 MEN Mikro Elektronik GmbH. All rights reserved. Germany France MEN Mikro Elektronik GmbH MEN Mikro Elektronik SAS MEN Micro Inc.

  • Page 13: Table Of Contents

    2.13 PCI Express ..........40 MEN Mikro Elektronik GmbH...
  • Page 14 General ......... 41 2.14.2 Implementation on the G22......42 2.14.3 Using the G22 as a Peripheral Board .
  • Page 15 Figure 5. CompactPCI serial P6 connector ......50 Figure 6. Position of battery on the mSATA adapter on the G22 ... . 80 Figure 7.
  • Page 16 SATA ports speed and state in peripheral mode ....32 Table 3. DisplayPort adapters for the G22 ......34 Table 4.

  • Page 17: Getting Started

    This chapter gives an overview of the board and some hints for first installation in a system. Map of the Board Figure 1. Map of the board – front panel Optional version Standard with M12 connector ® ® CompactPCI CompactPCI Serial Serial MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 18: Figure 2. Map Of The Board - Top View With Msata Disk

    Getting Started Figure 2. Map of the board – top view with mSATA disk mSATA Heat Sink microSD  (bottom) Display Port  Connectors USB  Connectors Ethernet  Connectors Battery M12 Connector for Ethernet  (optional) MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 19: Figure 3. Map Of The Board - Top View With Ethernet Rear I/O Card

    Getting Started Figure 3. Map of the board – top view with Ethernet rear I/O card Heat Sink CompactPCI Serial Connector P6 Display Port  Connectors USB  Connectors Ethernet  Connectors M12 Connector for Ethernet  microSD Card Slot (optional) Bottom side of Ethernet card MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 20: Configuring The Hardware

    Chapter 2.9.2 mSATA Disk on page 30  Ethernet via rear I/O according to CompactPCI Serial The G22 offers the possibility to realize a different number of Ethernet ports at the rear via a special adapter card. In that case no CompactFlash or mSATA can be used and no battery is available to buffer the real time clock.

  • Page 21: Integrating The Board Into A System

    Getting Started Integrating the Board into a System You can use the following check list when installing the G22 in a system for the first time and with minimum configuration.  Power-down the system.  Remove all boards from the CompactPCI system.

  • Page 22: Troubleshooting At Start-Up

    Getting Started Troubleshooting at Start-up If you have any problems at start-up of the G22, you can start the board with UEFI default settings for troubleshooting. Please refer to Chapter 3 BIOS on page Configuring BIOS The G22 is equipped with an InsydeH2O UEFI framework. Normally you won’t need to make any changes in the BIOS setup.

  • Page 23: Functional Description

    81). Power Supply The G22 board is supplied with +12V only. The voltage range is +9 V up to +16 V (absolute maximum voltage). The voltage is monitored within these borders. The G22 board can optionally be supplied with +5V (+5%/-3%) standby voltage.

  • Page 24: Intel Active Management Technology (Amt)

    Functional Description Intel Active Management Technology (AMT) G22 boards equipped with an Intel Core i7 or i5 processor support Intel Active Management Technology (AMT 8.0). Intel AMT is powered by a separate hardware engine in Intel chipsets which enables e.g. out-of-band (OOB) diagnostics, remote control, IDE-Redirect, Serial-over-LAN (SOL), agent presence checking and network traffic filtering.

  • Page 25: Reset Behavior

    Functional Description Reset Behavior The G22 can be reset using the reset button on the front panel or the PRST# signal on the backplane. (See also Chapter 2.15 Reset Button on page 55.) Real-Time Clock 2.6.1 Internal Real-Time Clock The board includes a real-time clock connected to the chipset. For data retention during power off the RTC is backed up by a supercapacitor.

  • Page 26: Processor Core

    Functional Description Processor Core The G22 can be equipped with different types of Intel Core i7, i5 or i3 processors. The following table gives a performance overview: Table 1. Processor core options for the G22 Cores/ Power Processor Type Core Frequency...

  • Page 27: Memory

    SDRAM. The memory bus is 2x72 bits wide (dual channel) and operates with up to 1066 MHz. 2.8.2 Boot Flash The G22 has an 64-Mbit SPI Serial Flash implemented as on-board Flash for BIOS data. 2.8.3 EEPROM The board has a 2-kbit serial EEPROM for factory data.

  • Page 28: Mass Storage

    Functional Description Mass Storage The G22 offers the possibility to connect an mSATA disk and a microSD card on a small adapter card in the heat sink area which is assembled by default. The slots are controlled via one USB port and one SATA port from the chipset.
  • Page 29 The Ethernet rear I/O card (e.g. GM1) also offers a microSD card slot. To install a microSD card, please stick to the following procedure.  Power down your system and remove the G22 from the system.  Put the board on a flat surface.

  • Page 30: Msata Disk

    Installing an mSATA disk To install an mSATA disk, please stick to the following procedure.  Power down your system and remove the G22 from the system.  Put the board on a flat surface.  Insert the mSATA disk carefully in a 30° angle.
  • Page 31 Functional Description  Fix the card using two M2.5 x4 screws (highlighted in red). Heat Sink mSATA Battery MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 32: Serial Ata (Sata)

    All interfaces can be run in AHCI and RAID mode. Peripheral Use If the G22 is used in a peripheral slot, the interfaces on the CompactPCI Serial connectors are switched off. For a detailed listing of the SATA ports and their state in peripheral mode see the following table.

  • Page 33: Graphics

    The maximum resolution of one fixed DisplayPort interface is 2560x1600, the maximum resolution of the second fixed DisplayPort interface is 1920x1200 and the maximum resolution of the third DisplayPort, HDMI or DVI capable inter- face is 1920x1200. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 34: Display Port

    In the following table you can find a list of adapters that have also been tested and can be used with the G22. Table 3. DisplayPort adapters for the G22 Manufacturer Ordering Number ACTEBIS 1444334 (ROHS)

  • Page 35: Rear I/O

    The G22 provides a digital display interface on CompactPCI Serial connector P2. Chapter 2.10.1 Display Configuration for more information on supported interfaces and resolutions. When the G22 is used in peripheral mode, the rear interface is switched off. Chapter 2.14 CompactPCI Serial on page MEN Mikro Elektronik GmbH 20G022-00 E2 –...

  • Page 36: Usb Interfaces

    USB 2.0 interfaces can be used in this case. Peripheral Use If the G22 is used in a peripheral slot, the USB interfaces on the CompactPCI Serial connectors are switched off. For a detailed listing of the USB ports and their state in peripheral mode see the following table.

  • Page 37: Front-Panel Connection

    Two USB interfaces are led to the Ethernet rear I/O adapter card which is used to realize Ethernet via rear I/O and a microSD card interface. Chapter 2.14.5 Ethernet Rear I/O Card on page 50 for details on the mezzanine interface. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 38: Ethernet Interfaces

    2.12 Ethernet Interfaces The G22 has two Ethernet interfaces connected to the platform controller hub via two x1 PCI Express (PCIe) links. They are controlled by an Intel I211 Ethernet controller and an 82579LM Ethernet Controller PHY. They support 10 Mbits/s up to 1000 Mbits/s as well as full-duplex operation and autonegotiation.

  • Page 39: Rear I/O Connection (Compactpci Serial)

    To achieve more flexibility, these interfaces are not implemented directly on the G22 but on a small adapter card (e.g. the GM1) which is equipped with the CompactPCI Serial connector P6. Two cards with 4 or 8 Ethernet interfaces are already available.

  • Page 40: Pci Express

    Chapter 2.14.4 CompactPCI Serial Connectors P1..P5 on page 44 for a detailed description of the CompactPCI Serial connectors. If the G22 is used in a peripheral slot, the interfaces on the CompactPCI Serial connectors are switched off. MEN Mikro Elektronik GmbH...

  • Page 41: Compactpci Serial

    Ethernet ports from the system slot are led to the first peripheral slot, the second to the second etc. and the first SATA interface to the eighth peripheral slot, the second to the seventh etc. See Figure 4, CompactPCI Serial backplane with filling order on page MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 42: Implementation On The G22

    2.14.2 Implementation on the G22 The G22 supports up to six SATA interfaces, eight USB 2.0 ports (or four USB 2.0 and four USB 3.0), 1 DisplayPort, five PCI Express x1 links as well as two PEG x8 (PCI Express fat pipe) ports on the backplane.

  • Page 43: Using The G22 As A Peripheral Board

    Using the G22 as a Peripheral Board The G22 is designed to be a system or a peripheral slot CPU in a CompactPCI Serial system. Due to that it is possible to use more than one G22 board within a CPCI-S.0 system to build a redundant system or a cluster with more processing power.

  • Page 44: Compactpci Serial Connectors P1..P5

    PRST# RST# PS_ON# EN#) STND +12V +12V +12V +12V +12V +12V +12V Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 45: Table 13. Pin Assignment Of Compactpci Serial P2 Connector

    1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ Rx07- Rx07+ Tx07- Tx07+ Rx06- Rx06+ Tx06- Tx06+ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ 1_PE_ Rx05- Rx05+ Tx05- Tx05+ Rx04- Rx04+ Tx04- Tx04+ MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 46: Table 14. Pin Assignment Of Compactpci Serial P3 Connector

    Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. The interface 3_SATA is not supported by default, it has to be set in BIOS. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 47: Table 15. Pin Assignment Of Compactpci Serial P4 Connector

    3_PE_ 3_PE_ 3_PE_ 3_PE_ 3_PE_ Rx01- Rx01+ Tx01- Tx01+ Rx00- Rx00+ Tx00- Tx00+ Note: The signals written in gray are specified in the CompactPCI Serial specification but not supported on this board. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 48: Table 16. Pin Assignment Of Compactpci Serial P5 Connector

    Note: The signals written in gray are specified in the CompactPCI Serial specifica- tion but not supported on this board. The 8_PE PCI Express interface can be made available on a special board version. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 49: Table 17. Signal Mnemonics Of Compactpci Serial Rear Connectors

    3 for link 3 to link 8 (x = 3 to 8) x_PE_Tx00+..x_PE_Tx03+ x_PE_CLK-, x_PE_CLK+ Differential 100 MHz reference clock for link 1 to 8 (x = 1 to 8) PE_CLKE# Presence Detect MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 50: Ethernet Rear I/O Card

    The Ethernet rear I/O card is connected to the G22 using a 40-pin connector leading two USB ports and one PCI Express interface to the card. As an option, the Ethernet port with AMT functionality at the front panel can be led to the backplane via the rear I/O card.
  • Page 51 Ethernet controllers to the heat sink of the G22. Removing the mSATA Adapter Board For installing the rear I/O card (e.g. the GM1) on the G22 you have to remove the adapter board with the mSATA disk and the microSD card. Carry out the following steps: ...
  • Page 52  Press the gap pad onto the Ethernet controller of the GM1.  Remove the plastic film on the other side.  Align the board-to-board connectors of the G22 and the rear I/O card and push the card down carefully.
  • Page 53  Press the gap pads onto the Ethernet controllers of the GM2  Remove the plastic film on the other side of the pads.  Align the board-to-board connectors of the G22 and the rear I/O card and push the card down carefully.
  • Page 54 Installing the GM3 on the G22 The GM3 also provides an onboard mSATA J3 connector for connecting an mSATA disk. The mSATA disc must be connected before the GM3 is mounted onto the G22. Instructions for installing the mSATA disc are available in the GM3 user manual.

  • Page 55: Reset Button

    Functional Description 2.15 Reset Button The G22 is equipped with a reset button which is recessed within the front panel and requires a tool, e.g. paper clip to be pressed, preventing the button from being inadvertently activated. 2.16 Status LEDs The G22 provides four status LEDs at the front panel which are controlled by the board controller using SMBus commands.

  • Page 56: Hot-Swap Led

    LED until the hot swap switch is closed. 2.16.3 User LEDs The user LEDs can be switched on and off using the MEN driver for the board controller. See MEN’s website for further information. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 57: Bios

    "x" in front of a menu item means that there is a configuration option which needs to be activated through a higher configuration option before being accessible. The G22 BIOS has two configuration modes. One mode shows only a selection of the most important items and hides items where normally no changes in the settings are required.

  • Page 58: Main

    BIOS Main InsydeH2O Setup Utility Rev. 3.5 Main Advanced Security Power Boot Exit MEN G22 Version 0.14 Processor Type Intel Core i7-3612 QE CPU 2.10 GHz System Bus Speed 100 MHz System Memory Speed 1600 MHz MEN BMC Rev 1.5.0...
  • Page 59 F10 Save and Exit Submenu MEN G22 Version / Processor Type / System Bus Speed / System Memory Speed/MEN Board Rev/ MEN BMC Rev / MEN Board Rev/ MEN Board S/N/ Cache RAM/ Total Memory / SODIMM 0 / SODIMM 1/Platform...
  • Page 60 BIOS Full Configuration Mode Description The G22 BIOS has two configuration modes. One mode shows only a selection of the most important items and hides items where normally no changes in the settings are required. Options Enable full configuration mode...

  • Page 61: Advanced

    >ACPI Table/Features Control >Active Management Technology Support >PCI Express Configuration Select Item F1 Help F5/F6 Change Values F9 Setup Defaults Select Menu Esc Exit Enter Select > F10 Save and Exit Submenu MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 62 600 ms delay 700 ms delay 800 ms delay Power Supply Type Description Selects the type of power supply Options Watchdog Description Enables or disables the G22 Watchdog Options 10 min 1 min 15 min 2 min 20 min 5 min...
  • Page 63 Description Enables or blocks the RESET_IN signal of the board. Options RESET_IN is RESET_IN is blocked enabled Peripheral Configuration — Sub-menu LAN-1 [Enabled] LAN-2 [Enabled] LAN-1/LAN-2 Description Enables or disables Intel 82579 GbE (AMT). Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 64 > Serial ATA Port 5 [SFSA8192U1BR4T0-I-DT] Submenu: Security Mode: Uninstall IDE Controller Description Enables or disables the IDE controllers. Options Enabled Disabled HDC Configure as Description Set hard disk controller configure type. Options RAID AHCI MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 65 Solid State Drive Port Multiplier Description Enables or disables port multiplier. Options Enabled Disabled > Serial ATA port 5 Serial ATA port 5 Description Serial ATA port 5 device configuration Options uninstall MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 66 DTS SMM is used to handle Out of Spec condition. Options Critical reporting Disabled Enabled Bidirectional PROCHOT# Description This value cannot be changed. Options Disabled ACPI 3.0 T-States Description Enable or disable ACPI 3.0 T-States Options Disabled Enabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 67 64 MB 96 MB 128 MB 160 MB 192 MB 224 MB 256 MB 288 MB 320 MB 352 MB 384 MB 416 MB 448 MB 480 MB 512 MB 1024 MB MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 68 Setting items on this screen to incorrect values may cause your system to malfunction! VT-d [Enabled] VT-d Description Check to enable the VT-d (Intel Virtualization Technology for Directed I/O) function. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 69 Options Enabled Disabled TCO Watchdog Support Description Enables or disables TCO Watchdog Support. Options Enabled Disabled Watchdog ACPI Table Description Enables or disables Watchdog ACPI Table. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 70 PCI Express Root Port 1/2/3/4/5/6/7/8 Description Enables or disables PCI Express ports. If PCI Express Root Port 1 is disabled, PCI Express Root Ports 2 to 8 will also be disabled. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 71: Security

    User Password Description Shows whether a user password has been entered. Set Supervisor Password Description Enter and confirm the supervisor password under this menu item. To delete the password enter an empty password. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 72: Power

    Description Selects the number of active processor cores. Options All Core 1 Core 2 Core 3 Core HT Support Description Enable or disable Hyper Threading. Options Auto Disabled VT Support Description Enable or disable Vanderpool technology. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 73 Description Enables or disables the C6 state (Deep Power Down Technology). Options Enabled Disabled Wake on Lan Description Determines the action taken when the system power is off and a Wake on Lan event occurs. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 74: Boot

    Description Allows InsydeH2O to skip certain tests while booting. This will decrease the time needed to boot the system. Options Enabled Disabled Quiet Boot Description Disables or enables booting in Text Mode Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 75 Description Enable: if boot to default device fails, it will directly try to boot next device. Disable: if boot to default device fails, it will pop warning then go into firmware UI. Options Enabled Disabled MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...
  • Page 76 USB-HDD before SATA- Advance Under this menu option there are no device groups. The single devices are listed and can be moved to select the boot order, e.g.: SATA-HDD1 USB-Floppy USB-DVD-DRIVE SATA-HDD2 MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 77: Exit

    Load Optimal Defaults If this option is selected, a verified factory setup is loaded. On the first BIOS setup configuration, this loads safe values for setup, which make the board boot up. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 78: Load Custom Defaults

    If this option is selected the custom defaults that have been saved in a former session with Save Custom Defaults (see Chapter 3.6.6 Save Custom Defaults) are loaded. 3.6.6 Save Custom Defaults Save custom defaults. 3.6.7 Discard Changes Discard changes. MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 79: Organization Of The Board

    INTA# INTB# INTC# INTD# INTB# INTC# INTD# INTA# INTC# INTD# INTA# INTB# INTD# INTA# INTB# INTC# INTA# INTB# INTC# INTD# INTB# INTC# INTD# INTA# INTC# INTD# INTA# INTB# INTD# INTA# INTB# INTC# MEN Mikro Elektronik GmbH 20G022-00 E2 – 2014-04-10...

  • Page 80: Maintenance

    The battery has to be UL listed. Used batteries have to be disposed of according to the local regulations concerning the disposal of hazardous waste. Figure 6. Position of battery on the mSATA adapter on the G22 Heat Sink mSATA Battery MEN Mikro Elektronik GmbH 20G022-00 E2 –...

  • Page 81: Appendix

    Appendix Appendix Literature and Web Resources • G22 data sheet with up-to-date information and documentation: www.men.de/products/02G022-.html • GM1 data sheet with up-to-date information and documentation: www.men.de/products/08GM01-.html • GM2 data sheet with up-to-date information and documentation: www.men.de/products/08GM02-.html 6.1.1 CompactPCI Serial • CompactPCI Serial Specification PICMG CPCI-S.0 Revision 1.0: 2011;...

  • Page 82: Hd Audio

    Serial Number MEN user documentation may describe several different models and/or design revisions of the G22. You can find information on the article number, the design revision and the serial number on two labels attached to the board. • Article number: Gives the product’s family and model. This is also MEN’s ordering number.
