Note: If you are using a USB Hub for connection, it is recommended to use a Powered USB hub to
ensure the stability of the setup.
3. Open the DJ software. Go to SETUP page and activate the INPUT and OUTPUT for connected
controller(s). As below:
4. The MIDI Channel setting of the controller allows you to control different decks in DJ software.
Please refer to below table for MIDI Channel in Deckadance Software:
MIDI CH1
MIDI CH2
MIDI CH3 to CH8
* N/A = Not Available
5. The 101 series USB MIDI controllers also support other DJ software like Traktor Pro. Please visit
DJ Tech website (http://www.djtechpro.com/ ) for software mapping and further info.
FUNCTIONS
DJM-101
1. GAIN KNOB
2. 3-BAND EQ KNOB
3. MASTER VOLUME KNOB
4. MONITOR SOURCE KNOB – Adjust the amount of master source and monitor source for the
monitor channel.
5. MONITOR LEVEL KNOB
6. PFL BUTTON
7. LED LEVEL METER – Use the switch to select between Master Channel or PFL Channel on the
LED level meter
8. CHANNEL VOLUME FADER
9. CROSSFADER
CDJ-101 VTT-101
Deck A Deck A
Deck B Deck B
N/A N/A
1
2
3 4
7
8
3
DJM-101
Deck A & B
N/A
N/A
5
6
9
MIX-101
Deck A & B
N/A
N/A
