Air Cleaning System - Guardian AC4300BPT Use & Care Instructions Manual

PRODUCT SPECIFICATIONS AND PARTS
Control Panel
UV-C
Blue Ring
Base
Front of Unit
CONTROLS
AC4300 Series Control Panel
POWER
ON/OFF
Button
FAN SPEED
SELECTION
Light
E-4
Carrying
Handle
Lock & Release
Air Outlet
Button
(for accessing
filter & bulb)
Filter Access
Cover
Air Inlet
Unit Body
Back of Unit
REPLACE HEPA
Light
Improve your indoor air quality with your new germguardian® Air Cleaning System.
Multiple levels of cleaning include a combination True HEPA filter that captures allergens,
and Charcoal filter to remove odors. UV-C light technology enhances germ-killing.
Pre-Filter
*
Captures initial dust and allergen particles.
Activated Carbon Filter
Activated Carbon Filter traps and controls household odors.
Pet Pure True HEPA Filter
™
Captures 99.97% of dust and allergens. Pet Pure
and mildew and odor causing bacteria on the surface of the filter.
UV-C Light
UV-C light technology works with Titanium Dioxide (TiO2) to enhance the elimination of
airborne germs. TiO2 is activated by the UV-C light to decompose remaining odor molecules
caused by smoking, cooking and pets.
*Pre-Filter and Carbon Filter are combined into one layer that attaches to the HEPA Filter.
UV-C
ON/OFF
Button
Main Unit

AIR CLEANING SYSTEM

treatment inhibits the growth of mold
™
AIR CLEANING LAYERS
UV-C Bulb
UV-C TiO2 Treated
Metal Shield
Combination
FILTER B Pet
Includes Pre/Carbon Filter
and Pet Pure
Lock & Release
Button
Rear Cover
with Air Inlet Grill
True HEPA Filter
™
E-5
