- Page 1 Varde Uniq Installation— and User guide Revision 6...
-
Page 2: Table Of Contents
Congratulation on purchasing your new stove Varde Ovne A/S is a Danish company specializing in functional, environmentally friendly and designed quality stoves. Index Welcome and index Page 2 Technical specifications Uniq 1 Page 3 Technical specifications Uniq 13 Steel Page 4... -
Page 3: Technical Specifications Uniq
Technical Specifications Uniq 1 Model 1801 Uniq 1 Hight (mm) 1044 Wide (mm) Depth (mm) Weight (kg) Effect 3-6 w Nominal Output 5,4 Kw Heated area 30-105m2 Efficiency Flue gas data: 5,5 g/sek., 288°C ved 20°C, 12 pa. Combustion chamber: (H x W x D): 380 x 350 x 250mm Flue outlet Ø... -
Page 4: Technical Specifications Uniq 13 Steel
Technical Specifications Uniq 13 Model 18013 Uniq 13 Hight (mm) 1160 Wide (mm) Depth (mm) Weight (kg) Effect 3-6 w Nominal Output 5,4 Kw Heated area 30-105m2 Efficiency Flue gas data: 5,5 g/sek., 288°C ved 20°C, 12 Combustion chamber: (H x W x D): 380 x 350 x 250mm Flue outlet Ø... -
Page 5: Technical Specifications Uniq 2 Steel
Technical Specifications Uniq 2 Model 1802 Uniq 2 Steel Hight (mm) 1044 Wide (mm) Depth (mm) Weight (kg) Effect 3-6 w Nominal Output 5,4 Kw Heated area 30-105m2 Efficiency Flue gas data: 5,5 g/sek., 288°C ved 20°C, 12 pa. Combustion chamber: (H x W x D): 380 x 350 x 250mm Flue outlet Ø... -
Page 6: Regulations And Approval
All Varde Ovne stoves are closed fireplaces. stoves. Please follow these regulations closely. The stove is designed for intermittent com- Inspection of installation... -
Page 7: Flooring And Distance
Steel Steel Weight Light Varde Uniq 110 kg 104 kg Installation distance: If walls are non-inflammable, the stove can be placed closer to them. However, we recommend a minimum distance of 5-10 cm, to allow for cleaning behind the stove. The cleanout gate must be accessible. -
Page 8: Chimney
Information about the new cast iron adapter, Part no.: 134 Your stove is equipped with the new cast iron adapter from Varde Ovne. The adapter is suitable for smoke pipes with inner diameter on 150 mm. -
Page 9: Air Supply
Continual fresh air Overheating A continual supply of fresh air is required in the Occors if too much wood is placed in the room in wich the stove is situated. This can be stove or if the Fire receives too much air. achieved by installing 1-2 vents, whilst also ensur- ring that these can not be blocked. -
Page 10: Operation
How it works Shake grate. The Shake grate is placed in the bottom of the chamber. Optart 1 Pull the handle towards yourself, so that the shake grate is fully open. Move the handle 2 Move the aircontrol handle all the way to the right. -
Page 11: How To Light And Stoke A Fire
How to light and stoke a fire The first time you light up the stove, the enamel will temper and give off some smoke and a slightly burnt smell. We recommend that you leave doors and windows open, as airing the room will make the smell disappear. -
Page 12: List Of Accessories
Operation Shake grate Wood catch Vermiculit plates Ash tray Cast iron Door Cast iron Top Cast irion cover Handle for Air regulation Storgage Plinth... -
Page 13: Vermiculite
Vermiculite is a very porous material and should be handled with care. When refilling the stove, stoke the wood carefully and use a glove. Only use original parts from Varde Ovne A/S Vermiculit set, Item no.: 1801506 og 1802506... -
Page 14: How To Choose The Wood
What kind of wood to use? The new stove Generally, beech wood is considered the best The first time you light up the stove the ena- type of wood for burning. It burns evenly mel will temper, and give off some smoke and without producing much smoke and ashes are a slight smell. -
Page 15: Maintenance
You do not need to re- place the plate until the gap is 5 mm wide. Only use original parts from Varde Ovne A/S The door is equipped with a spring, which pulls the gate closed. This is a legal requirement in many countries. -
Page 16: Troubleshooting
Troubleshooting. Smoke enters the room • Not enough draught in the chimney. • Inspect the flue pipe or the chimney for blockage. • Make sure the height of the chimney is correct. The glass or the chimney soots up • The wood is too moist. •... -
Page 17: Spare Parts
Spare Parts If Spare parts at any time should be needed, please chech the list below. Vermiculit Set, Item no.: 1802506 Vermiculit Set - Light, Item no.: 1801506 Glass inside Combustion Chamber, Item no.: 1801504 Glas - Sidepanels, Item no.: 1801505 Sealings—Door , Item no.: 10014+10008 Door , Item no.: 1800526 Door (Gray), Item no.: 1800526G... -
Page 18: Fresh Air Supply
Continual fresh air. A contiual supply of fresh air is reguired in the room in witch the stove is situated. This can be achived by installing 1 or 2 vents, whilst also ensuring that these can not be blocked. Combustion air supply (extra) When a stove is installed in a room, the requirements to air supply increase. -
Page 21: Warranty
Warranty All Varde stoves go through a close quality inspection, and we take pride in always delivering products of a consistent quality. This being so, manufacturing faults may still occur, and on these we offer a 5 year warranty. The warranty does not include: ·...
