- Page 1 TASER Axon Flex System User Manual IMPORTANT SAFETY INSTRUCTIONS. Read all warnings and instructions. Save these instructions. The most up-to-date warnings and instructions are available at www.TASER.com. MMU0040 Rev: F...
-
Page 2: Table Of Contents
Straight-to-Right-Angle Connector USB Cable Chapter 3: Hardware Details Preparing the Axon Flex Camera 10 Preparing the Magnetic Clip Assembly 11 Mounting the Axon Flex Camera to Your Shirt Collar Chapter 4: Basic Operations 12 Operating Modes BUFFERING Mode EVENT Mode... -
Page 3: Chapter 1: Introduction
What Is the Axon Flex System? The Axon Flex system is a camera system incorporating an audio and video recording device to be worn by you while performing your job duties. Multiple mounting options are available to customize the system to your needs. -
Page 4: Chapter 2: Hardware
Volume/Pairing Button – This button is used to adjust the volume of audio prompts coming from the camera. It also is used to pair the Axon Flex system with a smart phone; see the Axon Mobile for Android Devices or Axon Mobile for IOS Devices manuals for more information. - Page 5 NOTE: You can turn off the controller LEDs, if necessary. See Turning off the Controller LEDs in this manual for instructions. Top View On/Off Switch Operation LED On/Off Indicator Battery LED EVENT Button Battery Button Front View Operation LED – Shows the controller’s current operating mode: Operating Mode Controller LED Recording...
-
Page 6: Equipment Mounting Options
Equipment Mounting Options The Axon Flex system provides you with a variety of ways to wear your camera and carry your controller. Multiple holster options are available to attach the controller to your shirt or belt; and a variety of mounts enable the camera to be attached to your Oakley Flak Jacket eyewear, shirt collar or epaulet, load bearing equipment, helmet, cap, or your vehicle’s dashboard. - Page 7 For instructions on downloading your Axon Flex camera to a computer, see the TASER Axon End-to-End Deployment Guide. Chapter 2 Hardware...
-
Page 8: Chapter 3: Hardware Details
The side on which you wear the camera is configured through the Evidence Sync software. Try wearing your camera on your dominant side and your non-dominant side to find what works best for you. If you have the Axon Mobile application, you can view live video and determine if the camera is pointed where you want it. - Page 9 To Camera To Controller The Axon Flex camera has a circular bump on one side, at the rear of the camera. The cable connector has a round opening that fits around the bump, providing added security when connected. Opening in Connector Protruding Bump on Camera If you do not connect the cable to the camera properly, the connection may not be secure.
-
Page 10: Preparing The Magnetic Clip Assembly
Preparing the Magnetic Clip Assembly The most basic way to mount the camera to clothing involves two magnetic pieces. The two magnetic clips pictured below are the foundation for many camera mounting options. Each clip features a set of teeth on one side and a ring on the other. -
Page 11: Mounting The Axon Flex Camera To Your Shirt Collar
Mounting the Axon Flex Camera to Your Shirt Collar Push the two parts of the universal magnetic clip together on each side of your collar. Tug on the parts slightly to confirm the connection is secure. Attach the camera assembly to the magnetic clip on the outside of your shirt. -
Page 12: Chapter 4: Basic Operations
NOTE: An agency can turn off the BUFFERING mode. If your agency has deactivated the BUFFERING mode, your Axon system will operate the same way as described in this manual, but the camera will not record anything until you double-press the EVENT button. -
Page 13: Battery Status
To end a recording and turn off the system, move the on/off switch to the “off” position. When you end a recording with the on/off switch you will not go into BUFFERING mode; instead the system will turn off completely. NOTE: An event not recorded by the Axon Flex system cannot be played back or downloaded to your computer. Battery Status Press the Battery button to determine the percentage remaining in the controller battery. -
Page 14: Turning Off The Controller Leds
• Pressing the Battery button will momentarily light both the Operation LED and the Battery LED, displaying the current operating mode and battery level. For interpreting the LED colors, see Axon Flex Controller in Chapter 2: Hardware in this manual. -
Page 15: Chapter 5: Audio Prompts
Audio Prompts The Axon Flex system emits beeping sounds called audio prompts to notify you of the system status. These audio prompts usually occur after you perform an action with the Axon Flex system. NOTE: The camera must be connected to the controller for audio prompts to be heard. If the camera and controller are connected and you still do not hear the audio prompts, check the camera’s volume. -
Page 16: Chapter 6: Axon Signal Operations
If a light bar is turned off, the camera will continue to record. The ASU cannot turn an Axon system on. If the controller is turned off, the camera will not record even if an ASU sends an activation signal. -
Page 17: Chapter 7: Care And Maintenance
Use a soft, damp cloth to clean the surface of the system components. Do not use harsh cleaners or solvents. Do not immerse the system components in water or cleaning solutions. If the Axon Flex camera lens becomes dirty, use a lens blower brush to clean it and then wipe it with a soft cloth if necessary. -
Page 18: Chapter 8: Troubleshooting
If experiencing difficulty with the Axon Mobile application, power down the mobile device, turn the device back on, and re-pair your smart phone with the Axon Flex camera. See the Axon Mobile for Android Devices User Manual or Axon Mobile for IOS Devices User Manual, as appropriate, for more information. -
Page 19: Radio Waves
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult TASER International Customer Service for help. FCC/IC NOTICE: This device meets the body worn human exposure limits found in OET Bulletin 65, 2001, and ANSI/ IEEE C95.1, 1992. -
Page 20: Ce Declaration Of Conformity
THIS MODEL DEVICE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Declaration of Conformity TASER International declares that this Axon Flex system is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the original declaration of conformity can be found at www.TASER.com. - Page 21 Axon Signal, Evidence.com, and are trademarks of TASER International, Inc. Axon, Axon Flex, TASER, and © are trademarks of TASER International, Inc., registered in the US and other countries. For more information, visit www.TASER.com/legal. All rights reserved. © 2015 TASER International, Inc.
