Preparation
Please ask for professional peopleís help if you donít have
any experience changing a computerís internal storage
drive before. You will need the Drive Toolkit (shown as below)
coming with ARIES MINI to complete the following steps.
C
M
1
Special screws for fix HDD/SSSD on drive tray:
Y
CM
2
TORX T8 screw drive:
MY
CY
CMY
K
ATTENTION
ALL DATA ON DRIVE WILL BE ERASED DURING INITIALIZATION.
DO NOT COPY ANY MUSIC IN ADVANCE.
DISCONNECT POWER CORD BEFORE INSTALLATION.

Need Help?

Please visit our knowledge base:
support.auralic.com
AURALIC LIMITED | 声韵音响
1F Building No.7, 1A Chaoqian Road Beijing, 102200, China
163 E Compton Blvd, Gardena CA 90248, United States
http://www.auralic.com/
info@auralic.com
ARIES MINI
Drive Installation Guide
Choose the Right Storage
ARIES MINI is compatible with most hard disk drive or solid
state drive available on the market. Though there are some
limitation, your choice is pretty fleixble. Here are some
suggestions from AURALiC:
1
Maximum height of the drive: 9.5MM
2
Maximum current rate of the drive: 1000mA (1A)
Solid state drive is preferred because of no noise and vibration
3
4
Recommended HDD series: WD Red, Seagate Momentus
5
Recommended SSD brands: Intel, Samsung, Crucial, Plextor
Select only from major brands and high reliability series
6
7
No capacity limitation

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARIES MINI and is the answer not in the manual?

Questions and answers

Summary of Contents for Auralic ARIES MINI

  • Page 1: Need Help

    Please visit our knowledge base: Please ask for professional peopleís help if you donít have ARIES MINI is compatible with most hard disk drive or solid any experience changing a computerís internal storage state drive available on the market. Though there are some drive before.
  • Page 2 Remove drive cover screws Remove drive tray Slide the drive tray as indicated Install drive cover Remove drive cover Install drive with the screws in Drive Toolkit Install drive cover screws Make sure the tray is in position Use Lightning DS Guide Remove drive tray screws Put drive tray back Install drive tray screws...
