Summary of Contents for MORA-TOP 100 NTR/HV
- Page 1 Operation and installation manual STORAGE WATER HEATERS WITH INDIRECT HEATING MORA-TOP 100 NTR/HV MORA-TOP 125 NTR/HV MORA-TOP 160 NTR/HV...
-
Page 2: Table Of Contents
Read this manual carefully before installation of the heater! Dear customer, MORA-TOP s. r. o. would like to thank you for deciding to use a product from made by our brand. By means of this manual we will familiarise you with the use, positioning, construction, maintenance and other information about the pressurised storage water heaters. -
Page 3: Information For The Consumer
A heat exchanger (exchangers) has been prepared in the pressure vessel. Technical description: MORA-TOP 100 NTR, MORA-TOP 125 NTR, MORA-TOP 160 NTR, MORA-TOP 200 NTR, MORA-TOP 250 NTR, MORA-TOP 200 NTRR, MORA-TOP 250 NTRR 1. Enamelled steel vessel 2. -
Page 4: Operational Activity
Technical description: MORA-TOP 100 NTR/HV, MORA-TOP 125 NTR/HV, MORA-TOP 160 NTR/HV 1. Enamelled steel vessel 2. Water heating casing 3. Polyurethane insulation Inlet for heating water 4. Pipe exchanger Inlet for cold water 5. Hot utility water outlet 6. Cold water inlet 7. -
Page 5: Operation
Operating controls for heaters with volumes of 50 to 160L are located under the see-through cover of the control panel. HEATER PANEL FOR MORA-TOP NTR / Z and MORA-TOPV NTR with volumes of 50 to 160L Thermostat dial Signal light for el. circuit... -
Page 6: Mounting On A Wall
Setting the temperature The water temperature is set by turning the thermostat dial. The required symbol is set in relation to the fixed point on the control panel. Lower border of heat range Upper border of heat range (around 5°C) (approx. -
Page 7: Plumbing Installation
Before mounting the product, the load bearing capacity of the wall must be checked and a suitable mounting bracket must be chosen according to the type of wall, or if necessary, the wall may need to be reinforced. Water heaters from the NTR/Z range are only to be mounted in a vertical position in such a way that the bottom edge of the heater is positioned at least 600mm above the floor (figs. -
Page 8: Electrical Installation
Type: CIRCULATION HOT UTILITY WATER RETURN WATER COLD WATER HEATING WATER Source of HOT UTILITY heating WATER CIRCULATION water Type RETURN WATER HEATING WATER RETURN WATER Heater exchanger HEATING Cut-off valve WATER Bleeder valve Three-way valve Circulation pump Source RETURN WATER Pressure relief valve heating... -
Page 9: 10. Setting The Heater Into Operation
MORA-TOP 100 NTR, MORA-TOP 125 NTR, MORA-TOP 160 NTR, MORA-TOP 200 NTR, MORA-TOP 200 NTRR, MORA-TOP 250 NTRR, MORA-TOP 100 NTR/HV, MORA-TOP125 NTR/HV, MORA-TOP160 NTR/HV Check that the thermostat sensors are inserted in the chamber, i.e. pushed n as far as they will go. -
Page 10: Cleaning The Heater And Replacement Of The Anode Bar
After connection of the heater to the eater mains, hot water heating system, el. network and after testing of the pressure relief valve (according to the instructions that came with the valve), the heater can be set into operation. Procedure: a) Check the water mains, electrical installation and in the case of combined heaters also the installation for the hot water heating system. -
Page 11: Fire Regulations
was delivered to ensure return and use of the packaging material. The service fee was paid according to law no. 477/2001 Coll. as amended by later regulations with EKO-KOM a.s. The company client number is F06020274. Deposit the packaging from the water heater in the location intended for disposal of waste. -
Page 12: Technical Data
The product comes with aG3/4" air relief valve and in the case of types MORA-TOP 100, 125 NTR, MORA-TOP 100, 125, 160 NTR/ HV also with a discharge valve It is in your own interest to check the completeness of the delivery. -
Page 13: Heater Dimensions
Heating time with exchagner from 10 to 60°C kWh/24h 1,39 Heat loss Heater dimensions MORA-TOP 100 NTR, MORA-TOP 125 NTR MORA-TOP 160 NTR, MORA- TOP 200 NTR, MORA-TOP 250 NTR MORA-TOP 200 NTRR, MORA-TOP 250 NTRR INLET FOR COLD WATER... - Page 14 1046 1041 *Height from low er edge of the heater to the end of the w ater inlet and outlet pipes MORA-TOP 80 NTR/Z, MORA-TOP 100 NTR/Z MORA-TOP 200 NTR/Z MORA-TOP 125 NTR/Z, MORA-TOP 160 NTR/Z Upper hinge and lower hinge...
- Page 15 Upper hinge and lower hinge 160l, 4 anchor screws Dimensions 450 and 600 mm open before drilling Type OKC 80 NTR/Z OKC 100 NTR/Z OKC 125 NTR/Z OKC 160 NTR/Z 1046 1235 1041 1230 Type OKC 200 NTR/Z 1005 651 / 701 1"...
- Page 16 Type OKCV 125 OKCV 160 Type OKCV 180 NTR OKCV 200 NTR 1046 1235 1200 1300 1008 All inlets and outlets have an internal G 3/4“ thread. All inlets and outlets have an internal G 3/4“ thread. August 2006...
