Technical Information - Reloop iPhono 2 Instruction Manual

NoTe! If a cD player with a very high output is used, the input recording level can exceed 1V rms, this
will result in slight digital noise and distortion. And the LED will turn from green to orange. To find
the correct signal location rotate the Gain Dial -3- counterclockwise until the LeD returns to green.

TechNIcAL INFoRMATIoN

Global Distribution GmbH GmbH did not test the following manufacturers' specification for plausibility
and accuracy:
Inputs:
Outputs:
Frequency range:
Distortion:
Stereo separation:
S/N ratio:
USB:
Power supply:
Dimensions:
Weight:
hAVe FUN WITh yoUR ReLooP!
Reloop - Solution for DJs
Global Distribution GmbH
Schuckertstraße 28
48153 Muenster
Germany
Fax +49.251.6099368
www.reloop.com
16
Phono 5 mV/47 kOhm +1/-3dB
Line 200 mV/10 kOhm +1/-2dB
Master Normal 0.77V / 600 Ohm
Headphones Normal 1.1V / 32 Ohm
20 Hz - 20KHz, +/-1 dB (RIAA +/- 3 dB)
> 0.1 %
< 65 dB
Phono 70 dB
Line 75 dB
A/D & D/A converter 16 bit
Interface USB 1.1 or USB 2.0 with FullDuplex support
5 V DC
80 x 74 x 33 mm
0.094 kg (without mains adapter)
