Maycom AR-108 User's Operation Manual

Mini hand held type air / vhf band receiver
Hide thumbs Also See for AR-108:

Advertisement

Table of Contents

See also: User's Operation Manual
AR-108
MINI HAND HELD TYPE
AIR / VHF BAND RECEIVER
USER'S OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR-108 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maycom AR-108

Summary of Contents for Maycom AR-108

  • Page 1 AR-108 MINI HAND HELD TYPE AIR / VHF BAND RECEIVER USER'S OPERATION MANUAL...

  • Page 2: Table Of Contents

    CONTENTS PAGE ■ DESCRIPTION OF FEATURES ............4 -DISPLAY PANEL FEATURES ............. 4 -TOP PANEL FEATURES ..............6 -SIDE AND BACK PANEL FEATURES ..........7 -FRONT PANEL FEATURES ............….. 8 ■ OPTION SETTING MODE ..............15 ■ BATTERY PACK INSTRUCTION ............17 ■...

  • Page 3: Description Of Features

    ■ DESCRIPTION OF FEATURES Display Panel Features ● 1. " " (Function Mode) Indicates the "FUNC" button has been selected. 2. " DW " (Dual Watch) Indicates that the "Dual Watch" feature has been activated. 3. " PS " (Power Save) Indicates that the radio is in the "Battery Save"...
  • Page 4 11. " S-RF " (Signal strength indicator) The radio incorporates a ten segment incoming signal on the LCD. When receiving a signal, the meter will indicate how strong the signal is. A weak signal will be indicated by one or two segments, while a very strong signal will have 8 to 10 segments.

  • Page 5: Top Panel Features

    ● Top Panel Features 1. Power On/Off, Volume Turn the Volume switch clockwise to turn power on and set desired volume. Turn the Volume button anti-clockwise to turn the power off. 2. Squelch This control is to cut off or eliminate receiver background noise in the absence of an incoming signal.

  • Page 6: Side And Back Panel Features

    ● Side and Back Panel Features 1. MON (Monitor) Press and hold the "MON (Monitor)" button in the receiving mode to override squelch control. This is useful when a weak signal is to be monitored. 2. FUNC(Function) button This button, when used in conjunction with the buttons on the front panel, allows for access of each function.

  • Page 7: Front Panel Features

    1. AI/WR button Press the "AI/WR" button to change between air band and VHF band alternately. The AR-108 allows you to listen to Air band and VHF band. Press and release the "AI" button until you come to the band of your choice.
  • Page 8 2. ▼(Channel Down) button 1) ▼(Channel Down) button Press the "▼" button to move to a lower channel than is currently shown on the LCD. 2) Left Cursor function button Frequency Selection by Cursor function ("FUNC + ▼" button). The desired frequency can be directly entered using the cursor function in normal and memory mode.
  • Page 9 2) BP (Beep) button This feature gives the user an audible confirmation through a short beep tone that the radio has been turned on. The AR-108 comes with this feature already turned on. If you would like to deactivate this feature, press "FUNC + LAMP (BP)"...
  • Page 10 When frequency selection has been made, to store in to memory, press the MR (MW) or "MON" button. 2) While in the Memory Set mode, use up or down key to select the desired frequency. With this method the up or down key can only increment or decrement the frequency by the channel step value.
  • Page 11 6. SC(Scan), DW(Dual Watch) Button 1) SC (SCAN) button To Activate : Press the "SC" button to start the scanning process. The AR-108 will stop at any active channel. It will remain on that channel during scan delay time and reactivate scanning.
  • Page 12 2) DW (Dual Watch) Button To operate Dual Watch : (1) Not in the Scan Mode, select the channel in which you want to monitor which we will refer to as your "A" channel. (2) Press the "FUNC + SC/DW" button, then "DW" will appear on the LCD.
  • Page 13 ▶ Display of Channel Step message. 8. Speaker If there is any unforeseen fault in the microphone connections the unit will switch off power to the audio amplifier and it will display "SHORT" to indicate short circuit. 9. Battery Case See "Batteries"...

  • Page 14: Option Setting Mode

    ■ OPTION SETTING MODE Press and hold "FUNC" button under the condition of Power off, and then turn on the radio. To enter each option setting mode, press "FUNC + ▲ or ▼ " button. 1. Setting of Power Save mode This feature allows you to increase the useful life of your battery significantly.
  • Page 15 ▶ Display of Operating SCAN Delay Time Mode If you press the "▲ or ▼" button in this setting mode, Scan Delay Time will Increase (or decrease) 1 second per press of the button and changed value will appear on the LCD. NOTE : In the option setting mode, A.

  • Page 16: Battery Pack Instruction

    ■ BATTERY PACK INSTRUCTION 1. Press down the battery lock button on the bottom side of the radio.(①) 2. Open the battery cover on the back side of the radio.(②) 3. Install the battery as like shown.(③) 4. Put on the battery cover.(④) 5.

  • Page 17: To Receive

    ■ TO RECEIVE Keep the radio turned on and select the channel you want to listen to. If the Squelch is activated more than 20ms in the receiving mode, BUSY will appear on the LCD and speaker mute will be removed and the audio on that channel will be heard through speaker.
  • Page 18 Home page : http://www.emaycom.com e-mail : maycom@emaycom.com...
