Waste Compactor Model 8075
Installation, Use & Care Guide
Start Button (with Ram Status LED)
Door Interlock
Interlock Actuator
Key Lock
Compact Mode Switch
Bag Storage Area
Odor Disk
Ram
Compaction Plate Release Tab
Compaction Plate
Trash Bucket Latches (2)
Sliding Trash Bucket
Leveling Rollers
Leveling Legs
DISPERATOR AB Mälarvägen 9, SE-141 71 Segeltorp, Sweden
Tel: +46 8 724 01 60, Fax:+46 8 724 60 70
E-mail: info@disperator.se, www.disperator.se
Ref. 8075/Inst,Oper/Eng/101129

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8075 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for disperator 8075

Summary of Contents for disperator 8075

  • Page 1 Compaction Plate Release Tab Compaction Plate Trash Bucket Latches (2) Sliding Trash Bucket Leveling Rollers Leveling Legs DISPERATOR AB Mälarvägen 9, SE-141 71 Segeltorp, Sweden Ref. 8075/Inst,Oper/Eng/101129 Tel: +46 8 724 01 60, Fax:+46 8 724 60 70 E-mail: info@disperator.se, www.disperator.se...

  • Page 2: Table Of Contents

    1. Do not push waste into compactor container 2. A 10Amp fuse is required for compactor Model with hands or feet. Waste might contain broken 8075-E connected to 220-240V, 50/60Hz, AC, a glass, sharp pieces of metal etc. which would 15Amp fuse for compactor Model 8075-L cause injury.

  • Page 3: Installation

    1. Installation Plan to provide an electrical outlet in the opening that meets all applicable electrical codes and 1.1 Unpackning the Compactor requirements. See heading “Grounding instructions” on page 2 above for specific information. To protect the compactor mechanism the unit is Electrical outlet shall be minimum 305mm above shipped from the factory with packing material in the waste container and the compacting plate in...

  • Page 4: Door Reversing

    To level the front of the compactor d) Turn the bracket over and install the bracket on the opposite side of the cabinet using the same 2 screws (see above picture). Tip the front of the compactor up and onto a wood block.

  • Page 5: Preparation

    Waste food and glass are not recommended for Compactor NOTE: Opening the door during operation will Model 8075. DISPERATOR food waste disposers stop the compactor. If it is stopped during its and glass crushers are better suited for these cycle, the compaction plate will always return up purposes.

  • Page 6: Install Waste Bag

    Slide waste container completely into the compactor cabinet. Replacement odor discs are available from b) Turn key lock switch to “ON”-position. DISPERATOR. c) Select one of the two compact modes as described below by pushing the compact mode button to “Normal” or “Hold”.

  • Page 7: Compacting Tips

    Glass bottles can make a loud noise when they break during compaction. Try to avoid compacting glass bottles. DISPERATOR glass crushers are better suited for this purpose. d) Place a couple of folded sheets of news paper on top of the waste to be compacted when: •...

  • Page 8: Waste Bag Removal

    3.3 Waste Bag Removal a) Pull out waste container until it stops. b) Remove screw, one from each of the container a) Open the door and slide out the waste slides (see picture below). container. c) Press down on left and right bucket (container) b) Release the two container latches and lower slide release tabs, while pulling the container out front of the container (see picture below).

  • Page 9: Troubleshooting

    The compaction plate is cleaned as follows: a) Remove possible waste bag from container (see item 3.3 above). TRASH BUCKET b) Push the waste container into the cabinet. Unlatch and lower the container front. c) Press the compaction plate release tab on the front of the ram to disengage the plate (see picture below).

  • Page 10: Warranty

    If broken / damaged – the compactor will not operate. Order a spare interlock actuator from Disperator Co., and do not attempt to operate the compactor in any other manner.
  • Page 13 Drawing of optional accessory for fixing compactor feet to deck (floor plate) All measurements in mm Front of compactor Position of adjustable feet 4pcs. Electrical connection plug with cable *) Additional 70mm for optional Toe Kick Support used for free standing installation. Compactor can be removed for service by loosening the screw holding the leg fixing clamp...
