SYSCONTROL WC 90
INSTALLATION &
GB
OWNER'S MANUAL
　

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYSCONTROL WC 90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SystemAir SYSCONTROL WC 90

Summary of Contents for SystemAir SYSCONTROL WC 90

  • Page 1 SYSCONTROL WC 90 INSTALLATION & OWNER’S MANUAL 　...
  • Page 3 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of the wire controller pl ease read this manual carefully before using the unit. ● For convenience of future reference, keep this manual after reading it.
  • Page 4 CONTENTS 1. Safety precautions.............1 2. Installation accessory ..........3 3. Installation method.............4 4. Wiring diagram for wiring wire controller with air conditioner..............7 5. Specification...............8 6. General functionler ............8 7. Name and operation of the button on the wire controller ..............9 8. Indicators and functions..........14 9.
  • Page 5 Read the safety precautions carefully before installing the unit. Stated below are important safety issues that must be obeyed. Means improper handling may lead to personal WARNING death or severe injury. Means improper handling may lead to personal CAUTION injury or property loss. WARNING Please entrust the distributor or professionals to install the unit.
  • Page 6 Do not uninstall the unit randomly. Random uninstalling may lead to abnormal operation, heating or fire of the air condition. NOTE Do not install the unit in a place vulnerable to leakage of flammable gases. Once flammable gases are leaked and left around the wire controller, fire may occure.
  • Page 7 Select the installation location Don’t install at the place where contents with heavy oil, vapor or sulfureted gas, otherwise, this product would be deformed that would lead to system malfunction. Preparation before installation 1. Please confirm that all the following parts you have been supply. Qty.
  • Page 8 Simplified schematic of wire controller Transmitting tube wire controller Employ shielded 5-core wire for connection the in here, the length should be set base Indoor unit display panel on field installation(<15m). Indoor unit Fig 3-1 Installation diagram Connective wires for the display panel (accessory) The shielded 5-core wire Display panel pre-embedded into wall.
  • Page 9 If there is no terminal,the 5-core wire should be connected directly. The shielded 5-core wire pre-embedded into wall. Fig 3-3 Fig 3-4...
  • Page 10 Fig 3-5 1. Connect the male joint of 5-core wires group of the display panel with the female 5-core terminal of display panel. (See Fig.3-2) 2. Please connect the other side of display panel with the wall pre-bedded 5-core cable reliability. 3.
  • Page 11 Indoor unit The rear side of electric cabinet wire controller Insert of the electric control A B C D E Electric control of indoor unit 10-cored Shielded 5-core cable (See Installation connective wires preparation sheet 1 for the specification.) Connective wires Display panel group of display panel Fig 4-1...

  • Page 12: General Function

    Input voltage DC 5V Ambient temperature -5~43 ℃ Ambient humidity RH40%~RH90% 6. General function Main functions of this wire controller as follows: Connect with indoor unit via the five ports of A, B, C, D, E. Set operation mode via buttons control. Provided with LCD display function.
  • Page 13 ⑨ ⑦ ⑧ ⑤ ⑥ CLOCK TIMER CANCEL SWING SPEED ③ ④ MODE ① ② ① ④ ⑦ MODE Select Button Adjust Button TIMER Button ② ⑤ ⑧ ON/OFF Button Time Button SWING Button ③ ⑥ ⑨ Adjust Button CANCEL Button FAN SPEED Button...
  • Page 14 ⑨ ⑦ ⑧ ⑤ ⑥ SPEED CLOCK TIMER CANCEL SWING ③ ④ ① ② ① ④ ⑦ NO Use Adjust Button TIMER Button ② ⑤ ⑧ ON/OFF Button Time Button SWING Button ③ ⑥ ⑨ Adjust Button CANCEL Button FAN SPEED Button...
  • Page 15 ⑦ ⑨ ⑤ ⑥ ② CLOCK TIMER CANCEL ③ ⑧ MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE MODE TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP TEMP...

  • Page 16: Adjust Button

    ① MODE Select Button: Each time you push the button, a mode is selected in a sequence that goes from AUTO 、 COOL 、 DRY 、 HEAT and FAN as the following figure indicates: AUTO → COOL → DRY → HEAT → FAN NOTE HEAT function is invalid for cool only type unit.

  • Page 17: Cancel Button

    ⑤ Time Button: Normally, LCD displays the current time of the setting clock (however, LCD would display 12:00 when the first time power to the wire controller or reset the wire controller). Press this key lasting for 4 seconds, the clock will flashing at the frequency of 0.5 Sec.
  • Page 18 ① AUTO COOL HEAT TEMP SET TIME ON ③ ④ TIME OFF ⑤ ② SPEED ⑥ ① ② Operation mode indication Temperature display zone ③ ④ Time ON indication Time indication ⑤ ⑥ Time OFF indication Fan speed indication...
  • Page 19 ① Operation mode indication: Press MODE to display current running mode. AUTO, COOL, DRY, HEAT and FAN can be selected. (HEAT function is invalid for cool only type unit.) ② Temperature display zone : Display the set temperature. Adjust temperature via .

  • Page 20: Auto Operation

    9.1 AUTO operation Switch on the power and running indicator light on indoor unit flashes. 1. Press MODE to select AUTO. 2. Adjust temp via . Generally the range is 17 ℃ ~30 ℃ . 3. Press ON/OFF and running indicator light on indoor unit is lightened. Air conditioner will work on AUTO mode and fan speed is AUTO which is nonadjustable.Press the ON/OFF button again to stop the unit operation.

  • Page 21: Dry Operation

    3. Press FAN SPEED to select AUTO, LOW, MED or HIGH. 4. Press ON/OFF and running indicator light on indoor unit is lightened. Air conditioner will work on the set mode. Stop operation via ON/OFF. NOTE The FAN mode cannot be used to control the temperature. While in this mode, only steps 1 、...
  • Page 22 9.4 Timing set TIMER button is for set TIME ON /TIME OFF these two types of timing. Timing ON time and CLOCK are display at the same displayed zone. When the Timing ON has been set, the CLOCK displayed zone would show the Timing ON information.
  • Page 23 9.4-2 Set Timing ON and OFF In case originally provide with timing set in the system, please press the CANCEL button to cancel the current settings. 1. Press the TIMER button, the LCD in the wire controller will show “TIME ON”, at the same time the time zone will display the last setting time, which flash at the frequency of 1Hz, the wire control enters to Timing ON status.
  • Page 24 T he design and specifications are subject to change without prior notice for product improvement.Consult with the sales agency or manufacturer for details.
