Page 1: User Manual
USER MANUAL INSTALLATION AND QUICK-START GUIDE CONNECTION GUIDE OPERATING GUIDE Lightning Series REMOTE COMMUNICATIONS GUIDE REFERENCE GUIDE High Brightness Digital Video Projector Rev C May 2013 113-178C... - Page 2 NOTE: this symbol indicates that there is some important information that you should read. Product revision Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior notice.
-
Page 3: Table Of Contents
Digital Projection Lightning Series CONTENTS INSTALLATION AND QUICK-START GUIDE ......1 ....................13 Shift Adjusting the image................14 WHAT’S IN THE BOX? ..............3 ..........14 Orientation and On-Screen Display settings GETTING TO KNOW THE PROJECTOR .......... 4 ................... 14 Keystone Chassis - lamp, lens and filter ............... - Page 4 Digital Projection Lightning Series CONTENTS (continued) Differences between the two Connection Panels ........ 18 Control connections ................27 ..19 ..................27 3D sources up to 60Hz requiring frame doubling and left/right interleaving Update port ........19 ................27 3D sources above 60Hz not requiring frame doubling Wired remote control ..................
- Page 5 Digital Projection Lightning Series CONTENTS (continued) REMOTE COMMUNICATIONS GUIDE Color menu..................39 ..........63 ....................39 Gamut INTRODUCTION ................65 ..............39 Black Level and Gain slides Network setup ..................65 Geometry menu .................. 40 Serial Port settings ................65 ..................41 Size &...
- Page 6 Digital Projection Lightning Series CONTENTS (continued) REFERENCE GUIDE Lens charts..................108 ................81 ..............108 How to use the lens charts THE DMD™ .................. 84 ..............109 1080p (1920 x 1080 pixels) ASPECT RATIOS EXPLAINED ............86 ..............110 WUXGA (1920 x 1200 pixels) Aspect ratio examples for DMD™...
- Page 7 Digital Projection Lightning Series CONTENTS (continued) Special considerations when using Inputs 9-11 ........ 126 ......... 126 Differences between Inputs 9-11 and Inputs 1-8 ............126 Input and processing architecture ............126 EDID on the DVI and VGA inputs Connection examples................ 127 ...............
- Page 8 Digital Projection Lightning Series This page is intentionally left blank.
-
Page 9: Installation And Quick-Start Guide
INSTALLATION AND QUICK-START GUIDE Lightning Series High Brightness Digital Video Projector Rev C May 2013... - Page 10 Digital Projection IN THIS GUIDE Installation and Quick-Start Guide Lightning Series IN THIS GUIDE What’s In The Box? ..................... 3 Operating The Projector ................. 12 Getting To Know The Projector..............4 Switching the projector on ..................Chassis - lamp, lens and filter ...................
-
Page 11: What's In The Box
Digital Projection WHAT’S IN THE BOX? Installation and Quick-Start Guide Lightning Series What’s In The Box? Notes Make sure your box contains everything listed. If any pieces are missing, contact your dealer. You should save the original box and packing materials, in case you ever need to ship your projector. -
Page 12: Getting To Know The Projector
Digital Projection GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide Lightning Series Getting To Know The Projector Notes Chassis - lamp, lens and filter For full details of how to use the Air outlet controls and the menu system, see the Operating Guide. -
Page 13: Lamp-Hours Meter
Digital Projection GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide Lightning Series Lamp-hours meter Notes LCD meter Display button The LCD Lamp-hours meter has two modes of operation: • When the lamp is switched on, the LCD will show lamp run hours. -
Page 14: Rear And Side Panels - Connection And Control
Rear and side panels – connection and control Remote control Notes Control panel Transmit The projector uses the standard Digital Projection infra-red remote indicator control. For full details of how to use the controls and the menu system, see the Operating Guide. -
Page 15: Control Panel Indicators
Digital Projection GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide Lightning Series Control panel indicators Notes Shutter Power The indicators on the control panel are as follows: Power off = NO POWER green = normal RUNNING mode amber = STANDBY mode... -
Page 16: Positioning The Screen And Projector
Digital Projection POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide Lightning Series Positioning The Screen And Projector Notes Always allow the projector • Install the screen, ensuring that it is in the best position for viewing by your audience. -
Page 17: Pitch And Roll Adjustment
Digital Projection POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide Lightning Series Pitch and Roll adjustment Notes The frame adjusters can provide approximately ±10mm of vertical movement relative to the rear right corner, giving approximately ±0.65° pitch Do not tilt the projector more than and ±0.85°... -
Page 18: Stacking Projectors
Digital Projection POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide Lightning Series Stacking projectors Notes The rigging frame is capable of supporting the weight of up to three other projectors, using the built-in stacking adapters. The projectors can be stacked on top of each other, or suspended below each other. -
Page 19: Fitting The Lens
Digital Projection FITTING THE LENS Installation and Quick-Start Guide Lightning Series Fitting The Lens Notes • Turn the lens release lever clockwise so Always allow the lamp to cool for that it is pointing upwards, to open the 5 minutes before: lock fully. -
Page 20: Operating The Projector
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Lightning Series Operating The Projector Notes Switching the projector on • Make sure the main power switch is off, then connect the power cable between the mains supply and the projector, depending on your... -
Page 21: Selecting An Input Signal Or Test Pattern
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Lightning Series Selecting an input signal or test pattern Notes Input signal When any of the three Lens • adjustment keys is pressed, the blue Connect an image source to the projector. The signal should be automatically detected by the Transmit indicator on the remote projector, and should be displayed within two or three seconds. -
Page 22: Adjusting The Image
Digital Projection OPERATING THE PROJECTOR Installation and Quick-Start Guide Lightning Series Adjusting the image Notes Orientation and On-Screen Display settings • Main Menu These can be set from the Setup menu. Setup Keystone • This can be set from the Geometry menu. -
Page 23: Connection Guide
CONNECTION GUIDE Lightning Series High Brightness Digital Video Projector Rev C May 2013... - Page 24 Digital Projection IN THIS GUIDE Connection Guide Lightning Series IN THIS GUIDE Signal Inputs And Outputs ................17 Wiring Details ..................... 21 Rear Connection Panel ..................... Signal inputs and outputs ..................(input 1) ....................Input 1: VGA ........................(input 2), (input 3) ................
-
Page 25: Signal Inputs And Outputs
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Lightning Series Signal Inputs And Outputs Notes Rear Connection Panel For a complete listing of pin configurations for all signal and VGA (input 1) control connectors, see Wiring • Auto Setup in the Image/VGA Setup menu. -
Page 26: Side Connection Panel
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Lightning Series Side Connection Panel Notes DVI (input 9) • Single or Dual Link DVI-D input, or For a complete listing of pin • configurations for all signal and For Twin-Link DVI, Input 9 (DVI) is the Main input, Input 10 (DVI/HDMI) is the control connectors, see Wiring Sub input. -
Page 27: Sources Up To 60Hz Requiring Frame Doubling And Left/Right Interleaving
Digital Projection SIGNAL INPUTS AND OUTPUTS Connection Guide Lightning Series 3D connections Notes 3D sources up to 60Hz requiring frame doubling and left/right interleaving For a complete listing of pin • Connect to any of the Inputs on the Rear Connection Panel. -
Page 28: Control Connections
LAN) should be used at any one • time. The Service Port port is used to download, via USB, firmware updates issued from time to time by Digital Projection. Note that plugging in the remote control cable will disable the infra- Wired remote control red. -
Page 29: Wiring Details
Digital Projection WIRING DETAILS Connection Guide Lightning Series Wiring Details Notes Signal inputs and outputs For full details of all input settings, see the Operating Guide. Input 1: VGA 15 way D-type connector VGA: pin view of female connector unused... -
Page 30: Input 2: Hdmi
Digital Projection WIRING DETAILS Connection Guide Lightning Series Input 2: HDMI Notes 19 way type A connector TMDS Data 2+ For full details of all input settings, TMDS Data 2 Shield see the Operating Guide. HDMI: pin view of panel connector... -
Page 31: Input 3: Dvi
Digital Projection WIRING DETAILS Connection Guide Lightning Series Input 3: DVI Notes 24 way D-type connector Pin 1 TMDS data 2− Digital red− (link 1) High-bandwidth Digital Content Pin 2 TMDS data 2+ Digital red+ (link 1) Protection (HDCP) is supported on... -
Page 32: Input 4: 3G-Sdi
Digital Projection WIRING DETAILS Connection Guide Lightning Series Input 4: 3G-SDI Notes 75 ohm BNC 3G-SDI signals are very high 3G-SDI connector speed digital signals which require better quality coaxial cable than Input 5: Composite 1 conventional analogue video. The data rate is 3 Gigabits per second. -
Page 33: Input 9: Main/Dvi
Digital Projection WIRING DETAILS Connection Guide Lightning Series Input 9: MAIN/DVI Notes 24 way D-type connector Pin 1 TMDS data 2− Digital red− (link 1) High-bandwidth Digital Content Pin 2 TMDS data 2+ Digital red+ (link 1) Protection (HDCP) is supported on... -
Page 34: Input 10: Sub/Hdmi
Digital Projection WIRING DETAILS Connection Guide Lightning Series Input 10: SUB/HDMI Notes 19 way type A connector TMDS Data 2+ For full details of all input settings, TMDS Data 2 Shield see the Operating Guide. HDMI: pin view of panel connector... -
Page 35: Control Connections
Digital Projection WIRING DETAILS Connection Guide Lightning Series Control connections Notes Update port RJ45 socket For full details of all network settings, see the Operating Guide. Update port Service port USB type B socket Pin 1 VCC (+5 V) Pin 2 Data−... -
Page 36: Rs232
Digital Projection WIRING DETAILS Connection Guide Lightning Series RS232 Notes 9 way D-type connector 1 unused Only one remote connection (RS232 2 Received Data (RX) or LAN) should be used at any one time. RS232: 3 Transmitted Data (TX) pin view of female connector... -
Page 37: Operating Guide
OPERATING GUIDE Lightning Series High Brightness Digital Video Projector Rev C May 2013... - Page 38 Digital Projection IN THIS GUIDE Operating Guide Lightning Series IN THIS GUIDE Using The Menus ....................31 Reset Default Settings ....................Menus and sub-menus ..................... Input Configuration ......................Drop-down lists ......................Network ........................... Sliders ........................On Screen Display ......................Commands .........................
-
Page 39: Using The Menus
Digital Projection USING THE MENUS Operating Guide Lightning Series Using The Menus Notes Use the buttons on the projector control panel or on the remote control, to access the menu system. Some menu items may not be • available due to settings in other To open or close the on-screen display (OSD), press menus. -
Page 40: Drop-Down Lists
Digital Projection USING THE MENUS Operating Guide Lightning Series Drop-down lists Notes To use a drop-down list, press , select an item using , then press again or press to exit without changing. Some menu items may not be available due to settings in other menus. -
Page 41: Sliders
Digital Projection USING THE MENUS Operating Guide Lightning Series Sliders Notes To use a slider, press to adjust it. Some menu items may not be available due to settings in other menus. These will be grayed out on the actual menu. -
Page 42: Editing Fields
Digital Projection USING THE MENUS Operating Guide Lightning Series Editing fields Notes Some features require a text or numeric field to be edited. Some menu items may not be • To edit a field, first select it using , then press available due to settings in other menus. -
Page 43: A Tour Of The Menus
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series A Tour Of The Menus Notes See also Using the Menus earlier in this guide and Menu Map later in Main menu this guide. • Input Selection Main Menu Select an input source from the drop-down list. -
Page 44: Lens Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Lens menu Notes Zoom Main Menu To move the lens in or out: Lens Select Zoom In Zoom Out , then press When the image is the desired size, select... -
Page 45: Lens Presets
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Lens Presets Notes This menu allows you to save up to five custom lens presets, which you can recall later. Main Menu Lens Lens Presets Rev C May 2013... -
Page 46: Image Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Image menu Notes • Brightness, Contrast, Gamma, Hue and Saturation Set the slider or select from the drop-down list as required, to improve the quality of the image. Main Menu Image •... -
Page 47: Color Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Color menu Notes Gamut Main Menu Peak gives you the brightest possible image. Color Choose HDTV for high definition standards and SDTV for standard definition standards. A value between selects the relevant color temperature. -
Page 48: Geometry Menu
Explained in the Reference Guide. • Warp Map Using an external Digital Projection computer application, up to eight customised warp maps can be created and uploaded to the projector. If Warp is selected, and any warp maps have been uploaded, you can select from the drop-down list. -
Page 49: Size & Position
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Size & Position Notes • Enable • to choose: Setting Main Menu Geometry , in which case these settings will be applied to all signals on all inputs. Global Size &... -
Page 50: Edge Blend Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Edge Blend menu Notes When several projectors are used to create a large tiled image, the edges need to be blended to avoid the overlaps appearing brighter than the rest of the image. The Edge Blend menu is available only when >... - Page 51 Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Blend Width Notes • Use this to set the width of the blended regions. To apply the settings in these menus, use the command at the bottom of each page.
-
Page 52: Pip Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series PIP menu Notes Two images can be combined, in three different ways using this feature. The PIP menu is available only when Setup > System > Configuration is set to... -
Page 53: 3D Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series 3D menu Notes • 3D Enable as required. • Use the Frame Rate Multiplier to reduce flicker when the incoming 3D video signal has a low Main Menu frame rate. -
Page 54: Lamp Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Lamp menu Notes Set the slider to vary the Power between 60% and 100%. Main Menu Lamp Rev C May 2013... -
Page 55: Setup Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Setup menu Notes • Orientation Depending on how the projector is mounted, select the appropriate setting from the drop-down Main Menu Setup list. • Latency Affects interlaced sources only. For fastest response, the... -
Page 56: Input Configuration
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Input Configuration Notes This menu allows adjustment of various technical parameters specific to each of the signal inputs, regardless of which input is being used. Main Menu • should normally be set to... -
Page 57: Network
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Network Notes The fields at the bottom of the menu show the current settings. • if the IP Address is to be assigned by a DHCP server, or if it is to be set here. -
Page 58: On Screen Display
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series On Screen Display Notes • Select a display Language from the drop-down list. • The menus will disappear if no buttons are pressed within the selected from the drop-... -
Page 59: System
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series System Notes • Configuration : switch between Edge Blend The other settings in this menu are provided mainly to allow control from the Web Configuration Utility. Main Menu Setup •... -
Page 60: Information Menu
Digital Projection A TOUR OF THE MENUS Operating Guide Lightning Series Information menu Notes This menu gives information about lamp operating times, software and hardware configuration, input source and network settings. Please note that the values shown in the menus on this page are examples and may differ significantly on your OSD. -
Page 61: Menu Map
Digital Projection MENU MAP Operating Guide Lightning Series Menu Map Notes Main Menu Sub Menus Some of the information in this menu map is summarised. See the actual Input Selection menu on the projector for full detail. CVBS 1, CVBS 2, S-Video, Component, VGA, 3G-SDI, DVI, HDMI, Test Pattern, Main/DVI, Sub/HDMI, Dual Pipe... -
Page 62: Image
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu Image map is summarised. See the actual Brightness (slider, value range -50 ~ 50 [0]) menu on the projector for full detail. -
Page 63: Geometry
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu Geometry map is summarised. See the actual Aspect Ratio Source, Fill Display, Fill & Crop, Anamorphic, TheaterScope menu on the projector for full detail. -
Page 64: Edge Blend
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu Edge Blend map is summarised. See the actual Array Width (slider, value range 1 ~ 4) menu on the projector for full detail. -
Page 65: Pip
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu map is summarised. See the actual Option Off, PIP, PAP, POP menu on the projector for full detail. Input CVBS 1, CVBS 2, S-Video, Component, VGA, 3G-SDI, DVI, HDMI... -
Page 66: Setup
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu Setup map is summarised. See the actual Orientation Desktop Front, Desktop Rear, Ceiling Front, Ceiling Rear menu on the projector for full detail. -
Page 67: Information
Digital Projection MENU MAP Operating Guide Lightning Series Notes Main Menu Sub Menus Some of the information in this menu Information map is summarised. See the actual Lamp menu on the projector for full detail. Lamp 1 Hours, Lamp 1 Starts... -
Page 68: Web Configuration Utility
Digital Projection WEB CONFIGURATION UTILITY Operating Guide Lightning Series Web Configuration Utility Notes The LAN IP Address of the projector can be set by using the Network submenu, which can be found in the Setup menu. For full details of how to use the... - Page 69 Digital Projection WEB CONFIGURATION UTILITY Operating Guide Lightning Series Examples (continued) Notes • Sliders are represented by similar sliders, as in the Array Width Array Height sliders shown here. For full details of how to use the • Items that are not available are shown grayed-out, as shown here.
-
Page 70: Using The Discovery Tool To View Your Network
Digital Projection WEB CONFIGURATION UTILITY Operating Guide Lightning Series Using the Discovery Tool to view your network Notes The Discovery Tool allows you to view the IP addresses of all projectors in your network. The tool opens the following page in your browser:... -
Page 71: Remote Communications Guide
REMOTE COMMUNICATIONS GUIDE Lightning Series High Brightness Digital Video Projector Rev C May 2013... - Page 72 Digital Projection IN THIS GUIDE Remote Communications Guide Lightning Series IN THIS GUIDE Introduction ......................65 Network setup ......................Serial Port settings ....................Remote communications commands ..............Examples ........................Command Guide ....................67 Input Selection menu ....................Test Pattern menu .....................
-
Page 73: Introduction
Digital Projection INTRODUCTION Remote Communications Guide Lightning Series Introduction Notes The projector can be controlled by using an external control system or a PC via an RS232 or LAN interface, using a terminal-emulation program, such as HyperTerminal. Network setup Connect the projector to a network via an RS232 or LAN interface. -
Page 74: Remote Communications Commands
Digital Projection INTRODUCTION Remote Communications Guide Lightning Series Remote communications commands Notes Commands are used to simulate menu operations and determine the settings of the projector, and use the following format: • All commands consist of ASCII text strings starting with an asterisk and ending with an ASCII Carriage Return character... -
Page 75: Command Guide
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Command Guide Notes <command> <operator> <values> Input Selection menu input 0 = CVBS 1 1 = CVBS 2 2 = S-Video 3 = Component 4 = VGA 5 = 3G-SDI 6 = DVI... -
Page 76: Lens Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Lens menu zoom.in (execute) zoom.out (execute) focus.near (execute) focus.far (execute) calibrate.zoom (execute) calibrate.focus (execute) lens.centre (execute) nudge.up Nudge time, 0 = shortest, 3 = longest nudge.down Nudge time, 0 = shortest, 3 = longest nudge.left... -
Page 77: Image Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Image menu brightness -50 to 50 (integer) contrast -50 to 50 (integer) gamma 0 = 1.0 1 = 1.8 2 = 2.0 3 = 2.2 4 = 2.4 5 = 2.6... -
Page 78: Color Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> vga.samples vga.samples 0 to 1444 (integer) operation is identical to the Total H Samples vga.auto (execute) setting in the Image > VGA Setup Color menu menu. gamut 0 = Peak vga.auto... -
Page 79: Geometry Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Geometry menu aspect.ratio 0 = Source 1 = Fill & Display 2 = Fill & Crop 3 = Anamorphic 4 = Theatrescope sizepos.enable is identical overscan 0 = 0%... -
Page 80: Edge Blend Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> 4corner.ulx 4corner -1000 to +1000 operations provide 4corner.uly X and Y adjustment for each corner 4corner.urx of the image. They are identical to the settings within the Geometry >... - Page 81 Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> eb.left eb.right eb.left eb.right 0 to a value of up to 1280, depending on (integer, pixels) identical to Left Blend Region and Right Blend Region from the Edge eb.right...
-
Page 82: Pip Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> PIP menu pip.mode 0 = Off 1 = PIP 2 = PAP 3 = POP pip.input 0 = CVBS 1 1 = CVBS 2 2 = S-Video... -
Page 83: 3D Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> 3D menu commands are applicable to 3D models only. 3d.enable On, Off 3d.frmultiplier 1 = x1 2 = x2 3 = x3 3d.format auto, seq, fpack, tab, sbs 3d.darktime... -
Page 84: Setup Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Setup menu orientation 0 = Desktop Front 1 = Ceiling Front 2 = Desktop Rear 3 = Ceiling Rear latency 0 = Low Latency 1 = Best Video dvi.boosteq... -
Page 85: Information Menu
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Information menu sw.version sw.version returns the software release version - identical to the board.id Interface field in the Information > fw.version Configuration menu. from.version board.id is identical to the lens.version... -
Page 86: Miscellaneous Commands
Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> Miscellaneous commands model.name serial lamp1.serial lamp1.status 0 = Off 1 = Pre cooling 2 = Ignition 3 = Ignition confirm 4 = Enable communication 5 = Delay cooling... - Page 87 Digital Projection COMMAND GUIDE Remote Communications Guide Lightning Series Notes <command> <operation> <values> formatter.pattern 0 = white 1 = black 2 = green 3 = red 4 = blue 5 = magenta 6 = cyan 7 = yellow 8 = checker...
- Page 88 Digital Projection Remote Communications Guide Lightning Series This page is intentionally left blank.
-
Page 89: Reference Guide
REFERENCE GUIDE Lightning Series High Brightness Digital Video Projector Rev C May 2013... - Page 90 Digital Projection IN THIS GUIDE Lightning Series IN THIS GUIDE The DMD™ ......................84 Lens charts ......................Aspect Ratios Explained ................86 How to use the lens charts ................... Aspect ratio examples for DMD™ resolution SX+ (SXGA+) ......... 1080p (1920 x 1080 pixels) ..................
- Page 91 Digital Projection IN THIS GUIDE Lightning Series IN THIS GUIDE (continued) Connection examples .................... DVI Input connection example ..................3D connection examples ....................Control Connections ..................129 LAN connection ...................... RS232 connection ....................Edge Blend And Black Level Uplift ............131 3D Setup ......................
-
Page 92: The Dmd
Digital Projection THE DMD™ Lightning Series The DMD™ Notes A DMD™ (Digital Micromirror Device™) is a true digital light modulator which utilises an array of up to 2.3 million moving aluminium mirrors, with each one representing a pixel in the final projected image. The outermost micromirrors in the array remain inactive and are not used in constructing the image. - Page 93 Digital Projection THE DMD™ Lightning Series The DMD™ (continued) Notes Depending on the voltage polarity applied, each mirror will either tilt to the left to produce a bright pixel or to the right for a dark pixel. When light is applied to the complete DMD™, only the light redirected from a mirror tilting to the left is projected.
-
Page 94: Aspect Ratios Explained
Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect Ratios Explained Notes The appearance of a projected image on the screen depends on a combination of the following: • The DMD™ resolution: • SX+ (SXGA+) with a 1400 x 1050 resolution, corresponding to an aspect ratio of 4:3 •... -
Page 95: Aspect Ratio Examples For Dmd™ Resolution Sx+ (Sxga+)
Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution SX+ (SXGA+) Notes Source: 4:3 (native resolution) Aspect Ratio: Source / Fill Display / Fill & Crop Unused screen areas Aspect Ratio: Anamorphic Rev C May 2013... - Page 96 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution SX+ (SXGA+) (continued) Notes Source: 16:9 Unused screen areas Aspect Ratio: Source Cropped parts of the image Aspect Ratio: Fill Display Aspect Ratio: Fill & Crop Rev C May 2013...
- Page 97 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution SX+ (SXGA+) (continued) Notes Source: 16:10 Unused screen areas Aspect Ratio: Source Cropped parts of the image Aspect Ratio: Fill Display Aspect Ratio: Fill & Crop Rev C May 2013...
-
Page 98: Aspect Ratio Examples For Dmd™ Resolution 1080P
Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution 1080p Notes Source: 4:3 Unused screen areas Cropped parts of the image Aspect Ratio: Source Aspect Ratio: Fill Display, Anamorphic Aspect Ratio: Fill & Crop Rev C May 2013... - Page 99 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution 1080p (continued) Notes Source: 16:9 (native resolution) Aspect Ratio: Source / Fill Display / Fill & Crop Rev C May 2013...
- Page 100 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution 1080p (continued) Notes Source: 16:10 Unused screen areas Cropped parts of the image Aspect Ratio: Source Aspect Ratio: Fill Display Aspect Ratio: Fill & Crop Rev C May 2013...
-
Page 101: Aspect Ratio Examples For Dmd™ Resolution Wuxga
Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution WUXGA Notes Source: 4:3 Unused screen areas Cropped parts of the image Aspect Ratio: Source Aspect Ratio: Fill Display Aspect Ratio: Anamorphic Aspect Ratio: Fill & Crop... - Page 102 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution WUXGA (continued) Notes Source: 16:9 Unused screen areas Cropped parts of the image Aspect Ratio: Source Aspect Ratio: Fill Display Aspect Ratio: Fill & Crop Rev C May 2013...
- Page 103 Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio examples for DMD™ resolution WUXGA (continued) Notes Source: 16:10 (native resolution) Aspect Ratio: Source / Fill Display / Fill & Crop Rev C May 2013...
-
Page 104: Aspect Ratio Example: Theaterscope
Digital Projection ASPECT RATIOS EXPLAINED Lightning Series Aspect ratio example: TheaterScope Notes TheaterScope setting is used in combination with an anamorphic lens to restore 2.35:1 images packed into a 16:9 frame. Such images are projected with black lines at the top and bottom of the 16:9 screen to make up for the difference in aspect ratios. -
Page 105: Screen Requirements
Digital Projection SCREEN REQUIREMENTS Lightning Series Screen Requirements Notes Fitting the image to the DMD™ The images are shown here scaled If the source image supplied to the projector is smaller than the DMD™ resolution, the image will not fill the DMD™. The following examples automatically by the projector. -
Page 106: 1080P Images Displayed Full Width
Digital Projection SCREEN REQUIREMENTS Lightning Series 1080p images displayed full width Notes The images are shown here scaled automatically by the projector. The image may be scaled differently if the aspect ratio is set differently in menu. Geometry full width = 1920 pixels 1080p images displayed full height 4:3 = 1.33:1 = 1440 pixels... -
Page 107: Wuxga Images Displayed Full Width
Digital Projection SCREEN REQUIREMENTS Lightning Series WUXGA images displayed full width Notes The images are shown here scaled automatically by the projector. The image may be scaled differently if the aspect ratio is set differently in menu. Geometry full width = 1920 pixels... -
Page 108: Wuxga Images Displayed Full Height
Digital Projection SCREEN REQUIREMENTS Lightning Series WUXGA images displayed full height Notes Only WUXGA or UXGA images can fill the full height of the DMD™, using all 1200 pixels. UXGA = 4:3 = 1.33:1 = 1600 pixels WUXGA = 16:10 = 1.6:1 = 1920 pixels... -
Page 109: Diagonal Screen Sizes
Digital Projection SCREEN REQUIREMENTS Lightning Series Diagonal screen sizes Notes Screen sizes are sometimes specified by their diagonal size (D). When dealing W = width with large screens and projection distances at different aspect ratios, it is more convenient to measure screen width (W) and height (H). -
Page 110: Fitting The Image To The Screen
Digital Projection SCREEN REQUIREMENTS Lightning Series Fitting the image to the screen Notes It is important that your screen is of sufficient height and width to display images at all the aspect ratios you are planning to use. Use the conversion chart, or the sample calculations below to check that you are able to display the full image on your screen. -
Page 111: Positioning The Screen And Projector
Digital Projection SCREEN REQUIREMENTS Lightning Series Positioning the screen and projector Notes For optimum viewing, the screen should be a flat surface perpendicular to the floor. The bottom of the screen should The projector should be installed be 1.2m (4 feet) above the floor and the front row of the as close to the power outlet as audience should not have to look up more than 30°... -
Page 112: Choosing A Lens
Digital Projection CHOOSING A LENS Lightning Series Choosing A Lens Notes A number of lenses are available. Which lens you choose will depend on the screen size, image aspect ratio, projection distance and light output. In addition, each lens is available in two versions: High Brightness and High Contrast. -
Page 113: Choosing A Lens By Calculation
Digital Projection CHOOSING A LENS Lightning Series Choosing a lens by calculation Notes For any screen size not listed above, or if you need to be more precise, you can use the calculations below. Identify the width of the image in pixels. -
Page 114: Throw Distance And Lens Extension
Digital Projection CHOOSING A LENS Lightning Series Throw distance and lens extension Notes The throw distance is calculated to the outer end of the lens. The nominal distance between the front of the projector and the outer end of the lens is called lens extension. -
Page 115: Useful Lens Calculations
Digital Projection CHOOSING A LENS Lightning Series Useful lens calculations Notes DMD width Throw distance Throw ratio = TRF = The throw ratio for a particular lens Image width in pixels Screen width x TRF is fixed, but assumes that the image fills the width of the DMD. -
Page 116: Lens Charts
Digital Projection CHOOSING A LENS Lightning Series Lens charts Notes How to use the lens charts The lens charts on the following pages provide a quick For information about individual lens guide to the type of lens needed for a particular projector. -
Page 117: 1080P (1920 X 1080 Pixels)
Digital Projection CHOOSING A LENS Lightning Series 1080p (1920 x 1080 pixels) Notes Full width images For information about individual lens Formats that fit the width of the DMD™ without applying a throw ratio factor (TRF) include: part numbers, see Appendix A at the end of this document. -
Page 118: Wuxga (1920 X 1200 Pixels)
Digital Projection CHOOSING A LENS Lightning Series WUXGA (1920 x 1200 pixels) Notes Full width images For information about individual lens Formats that fit the width of the DMD™ without applying a throw ratio factor (TRF) include: part numbers, see Appendix A at the end of this document. -
Page 119: Sx+ (1400 X 1050 Pixels)
Digital Projection CHOOSING A LENS Lightning Series SX+ (1400 x 1050 pixels) Notes Full width images For information about individual lens Formats that fit the width of the DMD™ without applying a throw ratio factor (TRF) include: part numbers, see Appendix A at the end of this document. -
Page 120: Dmd™ Resolution 1080P / Wuxga, Full Width Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution 1080p / WUXGA, full width images Notes For 1080p, full width images are 2.35:1 (Scope), 1.85:1 (Flat) 1.78:1 (native). For WUXGA, full width images are all of the above, plus 1.66:1 (Vista) and 1.6:1 (native). -
Page 121: Dmd™ Resolution 1080P, 1.25:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution 1080p, 1.25:1 images Notes This chart has a TRF of 1.42, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 122: Dmd™ Resolution 1080P, 1.33:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution 1080p, 1.33:1 images Notes This chart has a TRF of 1.33, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 123: Dmd™ Resolution 1080P, 1.6:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution 1080p, 1.6:1 images Notes This chart has a TRF of 1.11, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 124: Dmd™ Resolution 1080P, 1.66:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution 1080p, 1.66:1 images Notes This chart has a TRF of 1.07, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 125: Dmd™ Resolution Wuxga, 1.25:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution WUXGA, 1.25:1 images Notes This chart has a TRF of 1.28, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 126: Dmd™ Resolution Wuxga, 1.33:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution WUXGA, 1.33:1 images Notes This chart has a TRF of 1.2, for use 1.12 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.67 : 1 fixed lens 1.12 - 1 fixed lens... -
Page 127: Dmd™ Resolution Sx+, Full Width Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution SX+, full width images Notes For SX+, full width images are 2.35:1 (Scope), 1.85:1 (Flat) 1.78:1 (16:9), 1.66:1 (Vista), 1.6:1 (16:10), and 1.33:1 (4:3, native aspect ratio). This chart has a TRF of 1.0, for use with the following images: 1.21 : 1 fixed lens (short) -
Page 128: Dmd™ Resolution Sx+, 1.25:1 Images
Digital Projection CHOOSING A LENS Lightning Series DMD™ resolution SX+, 1.25:1 images Notes This chart has a TRF of 1.07, for use 1.21 : 1 fixed lens (short) with the following images: 20.0 m (65.6 ft) 0.73 : 1 fixed lens 1.21 - 1 fixed lens... -
Page 129: Positioning The Image
Digital Projection POSITIONING THE IMAGE Lightning Series Positioning The Image Notes The normal position for the projector is at the centre of the screen. However, you can set the projector above or below the centre, or to one side, and adjust the image using the Lens shift feature (known as rising and falling front) to maintain a geometrically correct image. - Page 130 Digital Projection POSITIONING THE IMAGE Lightning Series Positioning The Image (continued) Notes Any single adjustment outside the ranges specified on the following page may result in an unacceptable level of distortion, particularly at the corners of the image, due to the image passing through the periphery of the lens optics.
-
Page 131: Maximum Offset Range
Digital Projection POSITIONING THE IMAGE Lightning Series Maximum offset range Notes The maximum offset range available with no distortion or vignetting is dependent on which lens is used. Shifting the lens beyond its undistorted limits may be physically possible, however you may experience some vignetting or distortion. -
Page 132: Input Connections
Digital Projection INPUT CONNECTIONS Lightning Series Input Connections Notes Inputs 1-8, on the rear of the projector, are limited input frame rates up to 60Hz, but provide access to the full geometric adjustment capabilities, including Blend and Warp. The side inputs, 9, 10 and 11 provide a very direct path to the DMD™ display, with minimal latency and high frame rate capability. -
Page 133: Dvi Inputs
Digital Projection INPUT CONNECTIONS Lightning Series DVI inputs Notes Input 3, single link DVI-D Sources up to 1920x1200 resolution; 24-60Hz; up to 12 bits per color. Supports HDCP. Input 9, dual link DVI-D WUXGA (1920x1200) is only available at 50 and 60Hz on Input 3. -
Page 134: Special Considerations When Using Inputs 9-11
Digital Projection INPUT CONNECTIONS Lightning Series Special considerations when using Inputs 9-11 Notes Differences between Inputs 9-11 and Inputs 1-8 Inputs 9 and 10 have been designed to offer access to a very high bandwidth digital video path, free of the limitations inherent to standard There is no scaler on Inputs 9-11. -
Page 135: Connection Examples
Digital Projection INPUT CONNECTIONS Lightning Series Connection examples Notes DVI Input connection example Input 3 Single link DVI video source Dual link DVI: high bandwidth/frame rate Input 9 Single or Dual link DVI video source Single link Input 10 DVI or HDMI video source... -
Page 136: 3D Connection Examples
Digital Projection INPUT CONNECTIONS Lightning Series 3D connection examples Notes Notes 3D sources up to 60Hz, requiring frame doubling and left/right interleaving Use inputs 1-8 if the geometry of the image needs to be adjusted. For more information on 3D settings, see the 3D Setup section further in this guide. -
Page 137: Control Connections
Digital Projection CONTROL CONNECTIONS Lightning Series Control Connections Notes LAN connection The projector’s features can be controlled via a LAN connection, using a standard internet browser package such as Internet Explorer. Crossed LAN cable Computer Projector Un-crossed LAN cables Computer... -
Page 138: Rs232 Connection
Digital Projection CONTROL CONNECTIONS Lightning Series RS232 connection Notes Null-modem cable Computer Projector Rear connection panel RS232 Rev C May 2013... -
Page 139: Edge Blend And Black Level Uplift
Digital Projection EDGE BLEND AND BLACK LEVEL UPLIFT Lightning Series Edge Blend And Black Level Uplift Notes Edge Blend setting is used to improve the appearance of multi-projector displays, by blending overlapping edges to present a seamless image. When several projectors are used to create a large tiled image, the overlapping edges may appear brighter than the rest of the image. -
Page 140: 3D Setup
Digital Projection 3D SETUP Lightning Series 3D Setup Notes In most situations you can use the Auto setting to have the projector automatically detect the format. Otherwise, consider the notes below to help you set up the 3D input manually. - Page 141 Digital Projection 3D SETUP Lightning Series • Frame Packing Notes This format will be detected, re-synchronised, frame-multiplied and displayed at 144Hz with the left eye / right eye dominance automatically extracted from the video data. You need to optimize Dark Time manually to suit your chosen switching glasses.
-
Page 142: Some 3D Settings Explained
Digital Projection 3D SETUP Lightning Series Some 3D settings explained Notes Fully on Right Left Dark Time Ghosting can be caused by the left and right images overlapping 3D may not be present on some during the time that the ZScreen or 3D glasses are switching. -
Page 143: Frame Rate Multiplier
Digital Projection 3D SETUP Lightning Series Frame Rate Multiplier Notes If the 3D video is available only at low frame rates, it will be necessary to multiply the frame rate to obtain a flicker-free image. For example, a 60Hz frame rate can be doubled to 3D may not be present on some 120Hz, or a 48Hz frame rate could be tripled to 144Hz. -
Page 144: Appendix A: Lens Part Numbers
Digital Projection APPENDIX A: LENS PART NUMBERS Lightning Series Appendix A: Lens Part Numbers Notes Throw ratios Throw ratios Lens extension Throw distance range Part number for Part number for The Throw ratio for a particular lens for 1080p and WUXGA for SX+ projectors (±2%) -
Page 145: Appendix B: Supported Signal Input Modes
Digital Projection APPENDIX B: SUPPORTED SIGNAL INPUT MODES Lightning Series Appendix B: Supported Signal Input Modes Notes 2D input modes SDTV 480i 720 x 480 59.94 15.73 576i 720 x 576 50.00 15.63 EDTV... - Page 146 Digital Projection APPENDIX B: SUPPORTED SIGNAL INPUT MODES Lightning Series Notes HDTV continued 1080i60 1920 x 1080 60.00 1125 33.75 1080p60 1920 x 1080 60.00 1125 67.50 COMPUTER VGA59 640 x 480 59.94 31.47 ...
- Page 147 Digital Projection APPENDIX B: SUPPORTED SIGNAL INPUT MODES Lightning Series Notes COMPUTER continued WXGA50 1280 x 720 49.83 37.07 WXGA60 1280 x 720 59.86 44.77 WXGA50 1280 x 768 49.92 39.59 WXGA60 1280 x 768 59.87 47.78 ...
-
Page 148: 3D Input Modes
Digital Projection APPENDIX B: SUPPORTED SIGNAL INPUT MODES Lightning Series 3D input modes Notes 3D may not be present on some models. Only the Sub / HDMI input supports HDMI 1.4 3D formats. 720p50 Frame Packing 1280 x 720 50.00 1470 37.50... - Page 149 Digital Projection APPENDIX B: SUPPORTED SIGNAL INPUT MODES Lightning Series Notes 3D may not be present on some models. Only the Sub / HDMI input supports 1080p25 Dual Pipe 1920 x 1080 25.00 1125 28.13 HDMI 1.4 3D formats.
-
Page 150: Appendix C: Glossary Of Terms
Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Appendix C: Glossary Of Terms Notes 1080p An HDTV resolution which corresponds to 1920 x 1080 pixels (a widescreen aspect ratio of 16:9). 3D active glasses Wireless battery-powered glasses with LCD shutters. Synchronization information is communicated to the glasses by means of an infrared (IR) or radio frequency (RF) emitter which is connected to the Sync Out terminal on the projector. - Page 151 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Blanking (video signal) Notes The section of the video signal where there is no active video data. Not to be confused with blanking (projection). Brightness (electronic control) A control which adds a fixed intensity value to every pixel in the display, moving the entire range of displayed intensities up or down, and is used to set the black point in the image (see Contrast).
- Page 152 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Color temperature Notes The position along the black body curve on the chromaticity diagram, normally quoted in Kelvin. It takes into account the preset values for color balance in the service set-up to take up the variations in the prism. The projector allows you to adjust this temperature (i.e. adjust the picture color temperature).
- Page 153 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Dark time Notes The time inserted between frames when using 3D active glasses, to avoid ghosting caused by switching time between left and right eye. DDC (Display Data Channel) A communications link between the source and projector. DDC is used on the HDMI, DVI and VGA inputs. The link is used by the source to read the EDID stored in the projector.
- Page 154 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Frame rate multiplication Notes To stop low frame rate 3D images from flickering, frame rate multiplication can be used, which increases the displayed frame rate by two or three times. Gamma A nonlinear operation used to code and decode luminance.
- Page 155 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Hs + Vs Notes Horizontal and vertical synchronization. The graduation (red/green balance) of color (applicable to NTSC). Interlacing A method of updating the image. The screen is divided in two fields, one containing every odd horizontal line, the other one containing the even lines.
- Page 156 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Luminance Notes Also known as ‘Y’, this is the part of an S-Video or Component Video signal which affects the brightness, i.e. the black and white part. Modal setting A projector setting that only affects the currently displayed input.
- Page 157 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Resolution Notes The number of pixels in an image, usually represented by the number of pixels per line and the number of lines (for example, 1920 x 1200). RGB (Red, Green and Blue) An uncompressed component video standard.
- Page 158 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Synchronization Notes A timing signal used to coordinate an action. TheaterScope An aspect ratio used in conjunction with a special anamorphic lens to display 2.35:1 images packed into a 16:9 frame.
- Page 159 Digital Projection APPENDIX C: GLOSSARY OF TERMS Lightning Series Vista Notes An aspect ratio of 1.66:1. Warp A set of projector functions that allow you to intentionally distort the image, for example to fit an arbitrarily shaped screen. WUXGA A display resolution of 1920 x 1200 pixels with a 16:10 screen aspect ratio. (Stands for Widescreen Ultra Extended Graphics Array.) This is the luminance input (brightness) from an S-Video or Component Video signal.
