Summary of Contents for Gorenje BLG71112
- Page 1 Instructions for Use Tumble Dryer...
-
Page 2: Table Of Contents
Thank you for your trust and for buying our tumble drier. We congratulate you on your wise decision. This appliance is designed for drying clothes for home use only. The dryer enables quick drying of your laundry, leaving it soft and tender without affecting its shape. -
Page 3: Appliance Description
Appliance description 1. Front panel 6. Evacuation slots 2. Drying program button 7. Cooling air slot 3. Water container 8. Legs 4. Door 9. Front (depending on model) 5. Condenser Technical data Dimensions of the appliance (w x d x h): (depending on model) 600 mm x 600 mm x 850 mm Weight (net): evacuation dryer 33 kg,... -
Page 4: Warnings
Warnings • Use the dryer to dry only the laundry washed with water. Do not attempt to dry the laundry, washed or cleaned with fl ammable detergents or solutions (gasoline, trichloroethylene etc.), as it may cause explosion. • Do not let the children play with the appliance. Prevent your children or pets to enter the dryer drum. -
Page 5: Installation And Connection
The belt can be replaced by a servising engineer only, who incorporates an original spare part with the marking OPTIBELT EPH 1906, code 104265; OPTIBELT 8 EPH 1941, code 160165; HUTCHINSON 8 PHE 1942, code 270313 (depending on model). The symbol on the product or on its packaging indicates that this product may not be treated as household waste. - Page 6 Installation Installation • Appliance can either stand on its own or can be placed on top of a washing machine of the same dimensions - minimum width 517 mm, depth 476 mm. The surface for placing the dryer must be clean and fl at. Use supplied vacuum feet to prevent sliding of the appliance.
-
Page 7: Power Connection
The distance between the dryer and the moist air outlet (ventilation shaft, window) should not exceed 2 meters, otherwise water can accumulate in the tube. B - Condensation dryer • Moisture from laundry is extracted in the water condensation device and is either collected in the receptacle or discharged directly into the drain (drain height should not exceed 800mm). -
Page 8: Operation
Operation A - program selection jog B - lower temperature button C - XL program button D - START/PAUSE button E - ON/OFF LED F - fi lter alarm/water container alarm LED Drying procedure Drying procedure Open the dryer door by pushing the left-hand side of the door towards the appliance (make sure the drum is empty). - Page 9 Operating the dryer Operating the dryer - Select drying time • By turning the drying time selector, set the preferred drying period, according to the type and quantity of laundry and washing machine spin rpm (see drying program chart). Selector jog may be turned in both directions. Available time span is from 15 min.
- Page 10 • Open the dryer door by pushing the left-hand side of the door towards the appliance. • Remove the laundry from the dryer. • Turn the appliance off by turning the jog selector (A) to the position “0”. • Clean the lint fi lter (see chapter on Cleaning and Maintenance).
-
Page 11: Tips For Drying And For Economic Use Of The Dryer
• Water container is full (condenser appliance only) When the container is full, signal lamps (E) and (F) are fl ashing. The drying program is interrupted. When the container is emptied, press the START/PAUSE button (D) to reactivate the drying program. Tips for drying and for economic use of the dryer •... -
Page 12: Cleaning And Maintenance
Cleaning and maintenance Cleaning the fi lter Cleaning the fi lter • After every drying clean the fi lter, located in the inner part of the door. • Lift the fi lter lid (Fig.). • Pull your fi ngers over the fi lter to remove fi bers and threads lining. - Page 13 Cleaning the water condensation device Water condensation device should be cleaned three to four times a year, in case of very frequent use even more often. During cleaning a certain amount of water may drip out so it is good to put an absorbing cloth below the opening. •...
-
Page 14: Troubles
Troubles Interferences from the ambient (for example electrical wiring) could induce signalization of different faults. In such cases: - switch the appliance off, and wait for a few seconds; - plug in the appliance and repeat the drying program. If the fault repeats, call authorized service shop. Warranty shall not apply in case of failures due to interferences from the environment (lightning stroke, power supply circuit faults, natural disasters). -
Page 15: Tables
Tables Drying time table Type of Extra Revolutions per minute laundry functions 1200 rpm 800 rpm Drying time (min) Vent. Con. Vent. Con. 6kg 7kg 6kg 7kg 6kg 6kg 7kg Cotton dry for storage 85 98 95/90* 110/100* 105 140 120/110* 130/120* iron dry 75 89 85/80* 100/90* 95 110 100/90* 117/105*... - Page 16 Table of textile symbols Drying Drying in drier not permitted Drain, hang on washing line and dry Do not drain, hang wet and dry Drain, lay on a fl at surface and dry Machine drying not permitted Drying at normal temperature Drying at lower temperature We reserve the rights to make any changes or mistakes in these operation instructions.
