TopPage
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
IMPORTANT SERVICE SAFETY
Precaution........................................ . ............i
PRECAUTIONS A PRENDRE LORS DE
LA REPARATION ................................... . ...........ii
PRECAUTIONS FOR USING LEAD-FREE
SOLDER ................................................ . .......... iii
CHAPTER 1. SPECIFICATIONS
[1]
Specifications ................................. . ....... 1-1
CHAPTER 2. OPERATION MANUAL
[1]
Operation Manual .......................... . ....... 2-1
[1]
Dimensions (Lc-46Sb57U)................ . ....... 3-1
[2]
Dimensions (Lc-52Sb57U)................ . ....... 3-2
[1]
REMOVING OF MAJOR PARTS
(LC-46SB57U)........................................ . ....... 4-1
[2]
REMOVING OF MAJOR PARTS
(LC-52SB57U)........................................ . ....... 4-7
CHAPTER 5. ADJUSTMENT
[1]
Adjustment Procedure ............... . ....... 5-1
[2]
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOR TELEVISION

MODELS
CONTENTS
[1]
Troubleshooting Table ......................6-1
DIAGRAM
[1]
OVERALL WIRING DIAGRAM ......................7-1
[2]
System Block Diagram .........................7-2
CHAPTER 8. PRINTED WIRING BOARD
ASSEMBLIES
[1]
Key Unit ........................................................8-1
[2]
Main Unit ......................................................8-2
[3]
R/C, Led Unit ................................................8-6
[1]
DESCRIPTION OF SCHEMATIC
DIAGRAM......................................................9-1
[2]
Key Unit ........................................................9-2
[3]
Main Unit ......................................................9-3
[4]
R/C, Led Unit ..............................................9-19
LC-46SB57U/LC-52SB57U
No. S49Y6LC46SB57
LC-46SB57U
LC-52SB57U
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
