GE JRP15 Installation Instructions

24" built-in oven.
Hide thumbs


Advertisement

INSTALLATION INSTRUCTIONS FOR YOUR NEW
Before you begin - Read these instructions completely and carefully.
IMPORTANT - Save these instructions for local inspector's use.
IMPORTANT - OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer - Be sure to leave these instructions with the Consumer.
Note to Consumer - Keep these instructions with your Use and Care Book for future
reference.
FOR YOUR SAFETY
Be sure your oven is installed properly by a qualified
installer or service technician.
• Be sure the oven is securely installed in a cabinet
that is firmly attached to the house structure.
Weight on the oven door could cause the oven to
tip resulting in serious personal injury or death.
Never allow anyone to climb, sit, lean, stand, or
hang on the oven door.
• The wall coverings, countertop and cabinets
around the oven should be able to withstand the
heat (up to 200°F) generated by the oven.
TOOL LIST
• 1/8" Drill Bit
• Electric or Hand Drill
• Flat Blade screwdriver
LOCATION
Cabinet space must be provided to enclose the
recessed part of your built-in oven. SINGLE OVEN
INSTALLATION — See Figure 1 for all necessary
dimensions. DOUBLE OVEN INSTALLATION
— See Figure 2 for all necessary dimensions. It is
best to make a template to insure accurate cutting.
Place the bottom of the template on a level base line,
above the floor. See dimension E in Figure 1 (Single
Oven) or Figure 2 (Double Oven).
It is important that the oven be installed at or above
the minimum height specified. The unit has been
tested and approved, in accordance with safety
standards, at this height.
Pub. No. 31-10241
INT224-14
24" BUILT-IN OVEN
• Ruler
• Hand or saber saw
• Pencil
ELECTRICAL REQUIREMENTS
CAUTION:
the oven supply line must be shut
off while connections are being
made. Failure to do so could result
in serious injury or death.
This appliance must be supplied with the proper
voltage and frequency, and connected to an
individual, properly grounded branch circuit,
protected by a circuit breaker or fuse having
amperage as noted on rating plate. (Rating plate
is located on oven frame.)
We recommend you have the electrical wiring and
hookup of your oven done by a qualified electrician.
After installation, have the electrician show you
where your main range disconnect is located.
Check with your local utilities for electrical codes
which apply in your area. Failure to wire your range
according to governing codes could result in a
hazardous condition. If there are no local codes,
your range must be wired and fused to meet the
requirements of the National Electrical Code, ANSI/
NFPA No. 70-Latest Edition. You can get a copy of
the National Electrical Code, ANSI/NFPA NO. 70-
Latest Edition by writing:
National Fire Protection Association
Battery March Park
Quincy, MA 02269
Effective January 1, 1996, the National Electrical
Code requires that new, but not existing,
construction utilize a 4 conductor connection to an
electric range. When installing an electric range in
new construction, follow the instructions in NEW
CONSTRUCTION AND FOUR-WIRE CORD
CONNECTION KIT.
You must use a three-wire, single-phase A.C.
208Y/120 Volt or 120/240 Volt, 60 Hertz electrical
system. If you connect to aluminum wiring, properly
installed connections approved for use with
aluminum wiring must be used.
1
The electrical power to

Advertisement

   Related Manuals for GE JRP15

   Summary of Contents for GE JRP15

  • Page 1

    INSTALLATION INSTRUCTIONS FOR YOUR NEW 24" BUILT-IN OVEN Before you begin - Read these instructions completely and carefully. IMPORTANT - Save these instructions for local inspector's use. IMPORTANT - OBSERVE ALL GOVERNING CODES AND ORDINANCES. Note to Installer - Be sure to leave these instructions with the Consumer. Note to Consumer - Keep these instructions with your Use and Care Book for future reference.

  • Page 2

    PREPARE OPENING Fig. 1 — SINGLE OVEN NOTE: Locate an approved junction box in the suggested location, a minimum of 23 7/8" above the runners. Be sure the oven support is solid enough to support 90 pounds. Also be sure the oven support is level and straight.

  • Page 3

    NOTE TO ELECTRICIAN: The three power IMPORTANT: Remove all packing leads supplied with this appliance are U. L. material and literature from the recognized for connection to larger gauge cooktop before connecting any household wiring. The insulation of these three electrical supplies.

  • Page 4

    REPLACE THE OVEN DOOR INSTALLING OVEN 1. Hold the door over the hinges with the slots at To remove the oven door: the bottom edge of the door lined up with the 1. Open the door to the stop position (see Fig. 3A). hinges.
