- Page 1 APPLICATIONS MANUAL RENAULT ANTI THEFT SYSTEM PAGE CONTENTS APPLICATIONS CONNECTOR LOCATIONS GENERAL OPERATION SPECIAL FUNCTIONS Version 1.0 09/02 APM106...
- Page 2 APPLICATIONS VEHICLE MODEL YEAR CABLE CLIO II ALL MODELS ADC110 KANGOO II ALL MODELS ADC110 MEGANE 99 >ON ADC110 MEGANE SCENIC 99 > ON ADC110 LAGUNA II ALL MODELS ADC110 TRAFFIC II ALL MODELS ADC110 KANGOO II SYSTEM IDENTIFICATION NORMAL KANGOO KANGOO II...
-
Page 3: Connector Locations
CONNECTOR LOCATIONS CLIO II MEGANE... - Page 4 CONNECTOR LOCATIONS LAGUNA II MEGANE SCENIC...
- Page 5 GENERAL OPERATION INTRODUCTION The Renault Immobiliser system uses either Infra Red or Radio Frequency for Plip key operation and transponder key technology for key entry and starting. The Infra Red and RF systems uses a rolling code system to ensure the vehicle system cannot be breached.
- Page 6 GENERAL OPERATION Decoder Unit (BII) This system is similar to many other immobilizer systems as it uses a transponder within the head of the key to send its code to the immobilizer when interrogated via the immobi- lizer ignition key barrel antenna. The code from the key is transferred to the Decoder Unit which has the following functions: •...
- Page 7 GENERAL OPERATION Coded Card The coded card system was introduced for the latest Laguna models and eliminates the use of 'ignition keys' and, optionally, 'door locking keys'. Instead of a key the driver has a coded card that, optionally, unlocks the door and after insertion into a card reader, sets self-retaining relays to supply the various systems/circuit in the vehicle (equivalent to the ignition switch), deactivates the immobiliser to allow the vehicle to be started and unlocks the electric steering lock.
- Page 8 GENERAL OPERATION Model Year Immobilizer Type Version Kangoo 10/97 10/97 10/97 Master (XD0) 10/97 10/97 10/97 Clio I 07/94 04/95 04/95 V1 & V2 12/95 12/96 Clio II 03/98 06/01 Safrane 01/93 05/93 02/95 10/95 09/96 01/97 Laguna I 02/94 07/94 01/95 11/95...
- Page 9 GENERAL OPERATION All systems have the same end function, immobilizing the vehicle until the correct code is presented to the immobiliser unit. Type 'A' Infrared Remote Control Fixed Code - Petrol This system uses a combined immobiliser and central door locking control unit with a re- mote infrared transmitter contained in the plastic keyhead.
- Page 10 GENERAL OPERATION Type 'E' Infrared Remote Control Rolling Code - Diesel This system uses a combined immobiliser and central door locking control unit with a re- mote infrared transmitter contained in the plastic keyhead. The transmitted code is rolling to reduce the chances of the code being captured and used to enter the vehicle. The code when received by the control unit receiver it will generate a door open signal and simultaneously pass the code to the Coded Solenoid Valve.
- Page 11 Press 8 To ENTER selection. _ _ _ _ _ _ _ _ _ _ _ _ Press 8 To Finish PIN selection. NOTE : RENAULT MEGANE USES 8 DIGIT SECURITY CODE, OTHER VEHI- SWITCH IGNITION ON CLES USE 12 DIGIT.
- Page 12 SPECIAL FUNCTIONS KEY PROGRAMMING If only one key is required press the BACK BACK TO EXIT key. ENTER TO PROGRAMME NEXT KEY INSERT NEXT KEY Further keys can be added by pressing the EN- TER key. THEN PRESS ENTER Follow on screen instructions and repeat for up to 4 keys.
