Gas stove - EN 613.
Model : 154 05 12
Propane (type G31)
Category I
3P.
Technical manual
to be saved
by the user
for future reference
Description of the appliance
Installation instructions
Operating instructions
Les Fonderies Franco-Belges
Spare parts
59660 MERVILLE
Phone : 03.28.43.43.43
Fax : 03.28.43.43.99
Warranty certificate
RC Hazebrouck 445750565B
Subject to modifications
Advertisement
Table of Contents
Related Manuals for Belfort 154 05 12
Summary of Contents for Belfort 154 05 12
- Page 1 Belfort Document n° 1044-2 ~ 17/05/2001 Français English Gas stove - EN 613. Model : 154 05 12 Propane (type G31) Category I Technical manual to be saved by the user for future reference Description of the appliance Installation instructions...
-
Page 2: Table Of Contents
Gas stove "Belfort" Ref. 154 05 12 FRANCO BELGE congratulates you on your choice. FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Product Information
Providing a highly efficient heat source, the Belfort has the look a n d c h a r m o f a ‘ r e a l ’ s t o v e c o u p l e d w i t h t h e 1.2. -
Page 4: Installation Instructions
The flue pipe required is either a single or double walled NATIONAL REGULATIONS. pipe of 126 mm diameter. • The Belfort is a gas stove designed to run LPG. • The stove is a radiant convector fuel effect stove. The 2.1.1. Clearance requirements... -
Page 5: Flue Connection
50 mm above the floor. 2.2. Flue connection The Belfort is suitable for both Class 1 and 2 flues (the building Regulations 1984). The appliance is also suitable for pre-cast flues, pre-cast chimney block, pre-cast flue block and ridge tile vent. -
Page 6: Coals Layout
FRANCO BELGE accept no responsibility for any injury sustained whilst handling hot ceramics. Instructions for the layout of the prefixed ceramic matrix and loose coals for Belfort fitted with gas burner unit. Parts : 1 Ceramic mat, 9 Ceramic coals. -
Page 7: Test For Spillage
Ref. 154 05 12 Installation instructions Gas stove "Belfort" 2.8. Service section 2.8.1. Troubleshooting chart Piezo-electric igniter : Th e s p a rk b e tw e e n th e electrode and the head of the pilot light is not clean ;... -
Page 8: User Instructions
Depress control knob fully Whilst depressed, turn knob sharply 90 degrees • Whilst the appliance is called a ‘stove’ the Belfort is not anticlockwise to ‘PILOT’ setting. Repeat until pilot light designed to be used in any way as a cooker. The... -
Page 9: Extinguishing The Stove Fully
The Belfort has a Piezo ignition which requires no 3.5. Safety mechanisms external power source. The piezo works on the same principle as a cigarette lighter, providing a spark when The Belfort in both natural gas and LPG, incorporates a required. number of safety mechanisms. 3.6. Cleaning 3.5.1. -
Page 10: List Of Components
B : 1540512J = *79 the part and the part number, including the colour index. C : 1540512K = *MJ Example : “Belfort" stove, Ref. : 154 05 12 Y, top 352136 EF. D : 1540512C = *MK N° Codes Description . - Page 11 Ref. 154 05 12 Exploded view Gas stove "Belfort" Figure 9 - Stove - Exploded view Technical manual...
- Page 12 Gas stove "Belfort" List of components Ref. 154 05 12 352136 MJ Top plate ......... . C ....
- Page 13 Ref. 154 05 12 Gas stove "Belfort" Notes Technical manual...
- Page 14 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Date of installation : __ __ / __ __ /__ __ __ __ ❑ 154 05 12 Model of the appliance : ❑ C ❑...
