19" Rackmount (2U)
High power output
Combo XLR/6.3mm jack and RCA inputs
Speaker, 6.3mm jack and binding-post outputs
Fan cooled
Output circuit overload protection
Mains powered via IEC connector
Output Max per channel @ 4Ω
Output RMS per channel @ 4Ω
Output Max per channel @ 8Ω
Output RMS per channel @ 8Ω
Dimensions
Weight (unpacked)
QA Series Power Amplifiers
QA400
QA1000 (172.025UK)
QA1600 (172.030UK
QA2400 (172.018UK)
QA400
QA1000
200W
500W
100W
250W
140W
340W
70W
170W
88 x 482 x 270mm
88 x 482 x 340mm
6.8kg
9.1kg
(172.020UK)
QA1600
800W
400W
540W
270W
88 x 482 x 340mm
12.3kg
QA2400
1200W
600W
840W
420W
88 x 482 x 340mm
15.4kg
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for qtxsound QA400
Summary of Contents for qtxsound QA400
- Page 1 QA Series Power Amplifiers QA400 (172.020UK) QA1000 (172.025UK) QA1600 (172.030UK QA2400 (172.018UK) 19” Rackmount (2U) High power output Combo XLR/6.3mm jack and RCA inputs Speaker, 6.3mm jack and binding-post outputs Fan cooled Output circuit overload protection ...
- Page 2 Thank you for purchasing this QTX Sound QA-series power amplifier. This product is intended to give long term, reliable service in normal usage. Please read these instructions before use to avoid incorrect operation and outline the functions and controls. VENTILATION GRILLE - Do not cover or restrict airflow CHANNEL A+B LEVEL - Attenuate output levels INDICATOR LEDS - Show signal present, clipping or protect mode POWER SWITCH - Switches mains power on/off...
- Page 3 Check mains for correct voltage as indicated near to the IEC mains inlet on the rear panel. Connect to mains supply using the IEC cable provided. Connect the outputs A+B to speakers via speaker connectors, jack or binding posts, ensuring that the minimum impedance is no lower than 4Ω...
