Summary of Contents for HandHeld SIRIO 4000
- Page 1 Handheld Mobile Computer SIRIO 4000 User Manual...
-
Page 2: Table Of Contents
CATALOGUE ......................Chapter 1 Getting Started ..................... Chapter 2 About The Device ......................Chapter 3 Call Function ...................... Chapter 4 Barcode Reader ......................Chapter 5 RFID Reader ....................Chapter 6 Fingerprint Reader ....................Chapter 7 The Other Functions ....................Chapter 8 Device Specifications... -
Page 3: Chapter 1 Getting Started
Cortex-A9 1GHZ dual core processor technology, the operators need only one device to enjoy a convenient and easy job, SIRIO 4000 will be the ideal choice for key-fact business in mobile solutions, for simplified task flow, enhanced work efficiency, for shortened time to customer response, more satisfied customer care service. - Page 4 Routinely check the battery’s charge status. Carefully monitor batteries that are approaching the end of their estimated life. Consider replacing the battery with a new one if you note either of the following conditions: The battery run time drops below about 80% of the original run time. The battery charge time increases significantly.
-
Page 5: Chapter 2 About The Device
Chapter 2 About The Device 2.1 Structure <Front> <Back>... -
Page 6: Sim Card Installation
Buttons: Button Function Power Button Press and hold to turn the device on or off App List View Button View a list of apps running Home Button Press to return to the home screen Cancel Button Tap to return to the previous screen 2.2 SD Card Installation Detailed installation steps are as follows: 1. -
Page 7: Battery Charging
2. Push the battery to the direction of the array; 3. Turn the battery lock; 2.5 Battery Charging 2.5.1 Direct Charging Use the adapter to charge the battery via the USB connector of the snap-on;. 2.5.2 Cradle Charging Connect the adapter with the power cable to charge the device. 2.6 Device Turning on/off Press the ‘Power’... -
Page 8: Chapter 3 Call Function
Chapter 3 Call Function 3.1 Phone 1. Click this icon 2. Click the number button to input the numbers; 3. Click the button to confirm and dial; 4. Click the to end the calling; Contacts Logs Voice Calling Emulated Numeric Keypad... - Page 9 3.2 Contacts 1. Click ‘Contacts’ to open the contacts list; 2. Click ‘ ’ to add the new contact; Click ‘ ’ to import/export or delete the contact list; Group Favorites Contact List 3.3 Messaging Click ‘ ’ to open the message list; 2.
-
Page 11: Chapter 4 Barcode Reader
Chapter 4 Barcode Reader 1. Open the Barcode Demo within Handset Tools; 2. Press the ‘Scan’ button to start scanning, then the auto interval parameters can also be set;... - Page 12 Note: Please scan the barcode correctly, otherwise the scanning might be failed;...
-
Page 13: Chapter 5 Rfid Reader
Chapter 5 RFID Reader 5.1 Low Frequency 1. Open the RFID_LF Demo within Handset Tools and then press the ‘Scan’ button to start scanning; 2. Tag types including ID Card/Animal Tag/Hitag/HDX Tag/EM4450 can be also selected, and Hitag-S and EM4305 reading/writing are already supported by the device;... - Page 14 5.2 High Frequency 5.2.1 14443A 1. Open the RFID_14443A demo within Handset Tool, and press the ‘Scan’ button to start scanning; 2. Mifare and Ultra Light reading/writing are also supported; 5.2.2 15693 1. Open the RFID_15693 demo within Handset Tool, and press the ‘Scan’ button to start scanning;...
- Page 15 5.3 Ultra High Frequency 1. Open the UHF demo within Handset Tool, and press the ‘Scan’ button to start scanning; 2. Multiple tags reading and single tag reading/writing are also supported;...
-
Page 17: Chapter 6 Fingerprint Reader
Chapter 6 Fingerprint Reader 1. Open the Fingerprint Demo in Handset Tool and then press the ‘Scan’ button to start scanning; 2. Put the finger to the fingerprint module and set the ID/name of the template under ‘ACQUISITION’; 3. Put the finger to the fingerprint module properly and identify by ID/Name/Score under ‘IDENTIFICATION’;... -
Page 18: Chapter 7 The Other Functions
Chapter 7 The Other Functions 7.1 PING Tool 1. Open the Ping Tool in Handset Tool; 2. Set the Ping parameters and select the internal/external addresses; 7.2 Bluetooth 1. Open the Bluetooth demo in Handset Tool and turn on the Bluetooth; 2. - Page 20 7.3 GPS 1. Open the GPS demo in Handset Tool and turn on GPS module; Set the GPS parameters and get the GPS data information;...
- Page 21 7.4 Volume Settings...
- Page 22 1. Open the Volume Setting demo in Handset Tool; 2. Set the volumes based on the requirements; 7.5 Light And Sensor 1. Open the Light And Sensor demo in Handset Tool; 2. Test the lights and sensor based on the requirements; 7.6 Keyboard Tool 1.
- Page 23 7.7 Network Signal 1. Open the Network Signal demo in Handset Tool; 2. Test the WIFI/Mobile signal based on the requirements;...
- Page 24 7.8 Keyboard Emulator Keyboard Emulator can be used directly for multiple using environments and the output formats can including prefix/suffix/enter/tap can also be defined.
-
Page 26: Chapter 8 Device Specifications
Chapter 8 Device Specifications Physical Characteristics Dimensions 153mm*75mm*29mm/6.02*2.95*1.14in. Weight 286g/10.09oz. (includes main battery) Screen 4in.WVGA (480*800) TFT-LCD, capacitive dual touch Keyboard 3 function keys, 3 side buttons Battery Main bat. (rechargeable li-ion polymer, 3.7V, 3200 mAh) Expansion Slot MicroSD/TF, maximum capacity of 32G SIM Slot 1 PSAM, 1 SIM, 1 MicroSD Audio... - Page 27 2D CMOS laser scanner: Symbol SE4500 LF 125KHz/134.2KHz, HDX/FDX-B(optional) RFID HF 13.56MHz, ISO14443A/ISO15693(optional) UHF 860-960MHz, EPC C1 GEN2/ISO18000-6C Developing Environment MMS SDK Programming Language Java Developing Tool Eclipse...
