Summary of Contents for Velleman VT-SSD
- Page 1 VT-SSD SOLDERING-/DESOLDERING STATION SOLDEER-/DESOLDEERSTATION STATION DE SOUDAGE/DESSOUDAGE LÖT- UND ENTLÖTSTATION USER MANUAL GEBRUIKERSHANDLEIDING MANUEL D’UTILISATION GEBRAUCHSANLEITUNG...
- Page 2 1. Introduction Congratulations ! You have selected the ideal solution for all your soldering/desoldering applications ! We are confident that the versatility and the many special features of the VT-SSD will satisfy your every need. We advise you to read this instruction manual carefully. This will enable you to maximise the advantages of your new soldering/desoldering station.
- Page 3 This soldering/desoldering station is designed to meet the present and future needs of the electronic production industry. The VT-SSD is engineered to meet the stringent demands of hobbyists, maintenance personnel and production people alike. 4. Operating Temperature SOLDERING The most common soldering alloys used in the electronics industry consist of 60% tin and 40% lead.
- Page 4 (f) Use the included spring wire to clean the tip in case of insufficient suction. Also check the in-line filters. (g) Make sure that all filters are in place during operation in order to avoid damage to the vacuum pump. (h) Read "9. Maintenance" when you wish to replace the tip. VT-SSD...
- Page 5 IMPORTANT Remove and clean the tip daily. Remove excess solder from the barrel nut assembly when installing a new tip, otherwise the tip may be fused to the heating element or to the retaining assembly. VT-SSD...
- Page 6 6. Remove the stainless tube and shake loose the molten solder. The tip should now be unclogged (fig. 7). Put the tip back in place and screw down the barrel nut assembly. Do not screw it down too tightly ! VT-SSD...
- Page 7 Do this frequently to keep the station in proper working order. 4. Remove the cooling strip with a pair of pliers (fig. 11 & 12). 5. Clean the cooling strip and the glass collector with a wire brush (included). FIG. 8 FIG. 9 FIG. 10 VT-SSD...
-
Page 8: In-Line Filters
5. Remove the old filter and replace it with a new one (fig. 15 & 16). FIG. 13 FIG. 14 FIG. 15 FIG. 16 b. IN-LINE FILTERS 1. Unscrew the in-line filters and pull the two pieces apart (fig. 17 & 18). FIG. 17 VT-SSD... - Page 9 2. Replace the fillings of both filters as shown in fig. 18. FIG. 18 fillings TO STATION TO IRON BITDEST2 Note : Use a desoldering tip with a Ø of 1.2mm (BITDEST2). VT-SSD...
