Summary of Contents for Dirty hand 100481
- Page 1 5-Ton Electric Log Splitter MODEL # 100481 Operation Manual This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 100350 Rev B...
- Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
-
Page 3: Table Of Contents
Table of Contents Important Safety Information .............4 Intended Use ................4 Personal Protective Equipment ..........4 General Safety ................5 Safety Decals ................5 Operation ..................6 Preparation of the Log ...............6 Work Area ..................6 Operation of the Log Splitter .............6 Repair and Maintenance .............7 Hydraulic Safety .................7 Fire Prevention ................9 Transportation ................ -
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. -
Page 5: General Safety
UNPLUG THE LOG SPLITTER WHEN NOT IN USE. Do not pull on power supply cable to unplug your log splitter. SAFETY DECALS Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Contact Dirty Hand Tools at 1-877-487-8275 for replacement decals. -
Page 6: Operation
Operation PREPARATION OF THE LOG Both ends of the log should be cut as square as possible to prevent the log from rotating out of the splitter during operation. Do not split logs greater than 20 in. in length. DANGER WORK AREA •... - Page 7 Operation OPERATION OF THE LOG SPLITTER (Continued) DANGER • Do not straddle or step over the log splitter during operation. • Do not reach or bend over the log splitter to pick up a log. • Do not attempt to split two logs on top of each other. •...
-
Page 8: Repair And Maintenance
Repair and Maintenance WARNING • Do not operate the log splitter when it is in poor mechanical condition or in need of repair. Frequently check that all nuts, bolts, screws, hydraulic fittings and hose clamps are tight. • ALWAYS unplug the power cable before performing any maintenance and repair. -
Page 9: Fire Prevention
Precautions FIRE PREVENTION CAUTION • DO NOT operate the log splitter near an open flame or spark. Hydraulic oil is flammable and can explode. • Keep a Class B fire extinguisher on hand when operating this log splitter in dry areas as a precautionary measure against possible flying sparks. -
Page 10: Assembly Instructions
Assembly Instructions This log splitter was completely assembled at the factory. The product has been filled with hydraulic oil at the factory. Refer to the photo and parts list should it become necessary to disassemble the unit for repair or replacement of parts. Remove the log splitter from the shipping container. -
Page 11: Operating Instructions
Operating Instructions NOTE: This machine is only intended for homeowners and non- commercial users to split firewood as detailed in the instructions and not for any other purpose. NOTE: Ensure the power supply is not connected while preparing the log splitter for use. WARNING WARNING: Read and thoroughly understand all instructions and safety information before operating this log splitter. - Page 12 Operating Instructions IMPORTANT: Before operating the log splitter turn the bleed screw as shown below one or two turns to allow air to be released from the hydraulic system. A flow of air through the bleed screw should be detectable while the log splitter is in use. Close the bleed screw after operation.
- Page 13 Operating Instructions WARNING Always wear safety glasses, safety shoes, and suitable work clothes when operating the log splitter. Do not wear neckties, scarfs or other loose clothing that could get caught in moving parts. Keep hands and feet clear of the ram and wedge at all times. Keep away from flammable liquids and gases before starting.
-
Page 14: Replacing The Hydraulic Fluid
Operating Instructions WARNING Always split the log along the grain of the wood. Splitting across the grain may cause some types of wood to burst or splinter resulting in possible injury. If a log becomes stuck on the wedge, remove both hands, unplug the log splitter from the power source and knock the log off of the wedge with a hammer. -
Page 15: Maintenance
Operating Instructions MAINTENANCE 1) Switch off and unplug power cable before performing any maintenance, adjustment or repair. Make sure to remove any tools and accessories from the work area when done. 2) Always check the oil level of the hydraulic reservoir before operation. -
Page 16: Warranty & Specifications
106 Lbs with Fluids Warranty 2 Year Limited Warranty *Tonnage and cycle times may vary dependent upon mechanical and environmental conditions. For Service or Questions Dirty Hand Tools® is a brand of Call 1-877-487-8275 720-287-5182 1100 W 120th Ave., Suite 600 www.dirtyhandtools.com...
