PLASMA TV
SERVICE MANUAL
CHASSIS : PA75A
MODEL : 60PY3D
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CANADA : http//biz.lgservice.com
USA
: http//www.lgservice.com
: http//biz.lgservice.com
60PY3DF-UJ
Internal Use Only

Advertisement

loading
Need help?

Need help?

Do you have a question about the 60PY3D and is the answer not in the manual?

Questions and answers

Related Manuals for LG 60PY3D

Summary of Contents for LG 60PY3D

  • Page 1 Internal Use Only CANADA : http//biz.lgservice.com : http//www.lgservice.com : http//biz.lgservice.com PLASMA TV SERVICE MANUAL CHASSIS : PA75A MODEL : 60PY3D 60PY3DF-UJ CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

  • Page 2: Safety Precautions

    : LG Customer Interactive Center P.O.Box 240007, 201 James Record Road Huntsville, AL 35824 Digital TV Hotline 1-800-243-0000 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 2 - Only for training and service purposes...

  • Page 3: Table Of Contents

    ADJUSTMENT INSTRUCTIONS ..........5 BLOCK DIAGRAM ..............11 EXPLODED VIEW...............20 EXPLODED VIEW PARTS LIST .........21 SCHEMATIC DIAGRAM............PRINTED CIRCUIT BOARDS ..........Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 3 - Only for training and service purposes...

  • Page 4: Specifications

    Less than 80% Operating Humidity Environment condition -4 ~ 140°F (-20 ~ 60°C) Storage Temperature Less than 85% Storage Humidity Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 4 - Only for training and service purposes...

  • Page 5: Adjustment Instructions

    - Full White Pattern when the main power is turned on again after being turned off 3) Pattern Mode is deselected by pressing CH +/-, Exit Key. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 5 -...
  • Page 6 – terminal to GND pin of P12. 2) Adjust VR951 voltage to match that of the label on the Top/Right of the panel. (Deviation : ±0.5V) Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 6 -...
  • Page 7 (2) Select Component1 as the input with 100% Horizontal Color Bar Pattern(HozTV31Bar) in 1080p Mode and select ‘Normal’ in screen. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 7 - Only for training and service purposes...
  • Page 8 60 | 26 36 80 A0 70 38 1F 40 30 20 25 00 C4 8E 21 00 70 | 00 1A 00 00 00 00 00 00 00 00 00 00 00 00 00 17 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only...
  • Page 9 R/C to enter Ez Adjust 7.White-Balance, and the pattern is automatically displayed. (When you set the Option to INNER, the default is always set to INNER) Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 9 -...
  • Page 10 Á KEY) button to move to the Ez –Adjust screen. Press the ADJ KEY to exit the adjustment mode. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 10 - Only for training and service purposes...

  • Page 11: Block Diagram

    BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 11 - Only for training and service purposes...
  • Page 12 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 12 - Only for training and service purposes...
  • Page 13 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 13 - Only for training and service purposes...
  • Page 14 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 14 - Only for training and service purposes...
  • Page 15 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 15 - Only for training and service purposes...
  • Page 16 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 16 - Only for training and service purposes...
  • Page 17 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 17 - Only for training and service purposes...
  • Page 18 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 18 - Only for training and service purposes...
  • Page 19 BLOCK DIAGRAM Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 19 - Only for training and service purposes...

  • Page 20: Exploded View

    EXPLODED VIEW Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only - 20 - Only for training and service purposes...

  • Page 21: Exploded View Parts List

    Supporter Assembly,60PY30, Filter Supporter Top, SKD AJJ30996502 Supporter Assembly,60PY30, Filter Supporter Bottom Assy C/SKD 5230V00026B Filter,CUTTING ACRYL TOP PDP 60 LG CHEMICAL GLASS FILTER AJJ30996603 Supporter Assembly,60PY30, SKD, Filter Supporter Right Assy AJJ30996703 Supporter Assembly,60PY3, SKD, Filter Supporter Left Assy ACQ30995608 Cover Assembly,Rear 60PY3DF-ZA PD75A 60 Back Cover Assy, SKD, Without DVR &...
  • Page 22 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 23 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 24 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 25 MAIN(TOP) SIDE A/V(TOP) SIDE A/V(BOTTOM) PREAMP(TOP) PREAMP(BOTTOM) MAIN(BOTTOM) Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
  • Page 26 Nov., 2007 P/NO : MFL42558102 Printed in Korea CANADA: LG Electronics Canada, Inc. 550 Matheson Boulevard East Mississauga, Ontario L4Z 4G3 : LG Electronics Alabama, Inc. P.O.Box 240007, 201 James Record Road Bldg 3 Huntsville, AL 35824...
