To set the gear mesh properly, slide the pinion until it fully
meshes up against the spur then back it up slightly. Run a
piece of paper between the two gears. If the paper is ripped,
the mesh is too tight. If the paper is not tightly creased the gear
mesh is too loose. Once the gear mesh is set, tighten the motor
screws.
5. Install the gear cover onto the motor plate and secure it
in place with the included 3x3mm screws.
6. Re-install the rear wheel back onto the truck.
7. Connect the motor to your ESC according to the ESC's
instructrion manual.

BATTERY INSTALLATION

Remove the pin and
lift the strap to
install/remove the
battery pack.
1. Remove the body pin from the battery strap post, and
remove the battery strap from the Evader ST.
Install the strap
between the bumps.
2. Install the charged 6 or 7 cell battery into the battery slot.
Re-install the battery strap onto the Evader ST. Note that
there is a channel in the rear of the chassis for the
battery strap to rest in. Re-install the body clip into the
battery strap post.

PAINT THE BODY

1. Clean the body thoroughly using a small amount of dish
soap and water. Make sure that all of the soap is rinsed out
of the body. Let the body completely air dry.
2. Apply the included window masks to the inside of the
body. Try to get as much air as possible out from under the
mask during application.
3. Use Hobbico Master Mask liquid masking film or a quality
masking tape to mask the inside of the body to your desired
paint scheme.
4. Spray a light coat of lexan compatible paint onto the
inside of the body and let it completely dry before applying
the next coat. Continue applying light coats until the desired
area of the body is adequately covered.
5. Once the body is painted as desired, remove the window
masks and apply the desired decals.
6. Secure the body to the chassis using the included body clips.
7
