TopPage LC-32D41U/LC-32M41U/LC-40C32U SERVICE MANUAL No. S56T6LC32D41U LCD COLOR TELEVISION LC-32D41U LC-32M41U LC-40C32U MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
LC-32D41U/LC-32M41U/LC-40C32U CONTENTS SAFETY PRECAUTION IMPORTANT SERVICE SAFETY PRE- CAUTION............i PRECAUTIONS A PRENDRE LORS DE LA REPARATION..........ii PRECAUTIONS FOR USING LEAD- FREE SOLDER..........iii CHAPTER 1. SPECIFICATIONS SPECIFICATIONS ........1-1 CHAPTER 2. OPERATION MANUAL OPERATION MANUAL ......
LC-32D41U/LC-32M41U/LC-40C32U LC-32D41U/LC-32M41U/LC-40C32U SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.
LC-32D41U/LC-32M41U/LC-40C32U PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT • A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ...
LC-32D41U/LC-32M41U/LC-40C32U PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
* Emergency alert messages via Cable are unreceivable. As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.
LC-32D41U/LC-32M41U/LC-40C32U CHAPTER 4. LC-32D41U/LC-32M41U/LC-40C32U REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Remove the SD Card Cover. 2. Remove the 4 lock screws and detach the Stand Base Ass'y. 3. Remove the 9 lock screws, 3 lock screws and detach the Rear Cabinet.
Page 12
LC-32D41U/LC-32M41U/LC-40C32U 4. Remove the 2 lock screws and detach the Stand Assist Angle. 5. Remove the 4 lock screws and detach the Center Angle-L and R. 6. Remove the 3 lock screws and detach the Stand Cover. 7. Remove the 5 lock screws and detach the Stand Fix Angle.
Page 13
LC-32D41U/LC-32M41U/LC-40C32U 10.Disconnect all the connectors from all the PWBs. 4 – 3...
Page 14
LC-32D41U/LC-32M41U/LC-40C32U 11.Remove the Speaker-L and R. 12.Remove the 2 lock screws and detach the R/C, LED Unit. 13.Remove the Top Cover Ass'y. Remove the 3 lock screws from the Top Cover Ass'y and detach the KEY Unit. 14.Remove the 4 lock screws and detach the Tray Chassis.
Page 15
LC-32D41U/LC-32M41U/LC-40C32U 19.Remove the 14 lock screws and detach the Rug Angles and LCD Panel Module. Rug Angle Rug Angle 4 – 5...
1. After replacement of any PWB unit and/or IC for repair, please note the following. • When replacing the following units, make sure to prepare the new units loaded with updated software. MAIN Unit: DUNTKD640FM22 (LC-32D41U) MAIN Unit: DUNTKD640FM23 (LC-32M41U) MAIN Unit: DUNTKD640FM21 (LC-40C32U)
Page 17
LC-32D41U/LC-32M41U/LC-40C32U 2. When the formatting is over, the following window appears. Click [OK]. 3. Click [Exit] to finish the formatting. NOTE: When you are done, take out the SD card once to make sure it is finished, and then insert it again.
Page 18
LC-32D41U/LC-32M41U/LC-40C32U 9. Even a single failure in the process will trigger the upgrade failure screen as shown below. The word “NG” changes to red for the item failed. NOTE: In the event of a failure, repeat the upgrading process. If the process repeatedly fails, it is likely that the hardware is troubled.
Page 19
2.4. Video signal adjustment procedure 1) Image adjustment 1. Device check Before adjustment, make sure that the adjusting device and signal source are set for the Sharp LCD US. Signal generator level adjustment check (Adjustment to the specified level) • Composite signal 0.714Vp-p ±...
Page 20
LC-32D41U/LC-32M41U/LC-40C32U 2. Entering the adjustment process mode Adjustment item Adjustment conditions Adjustment procedure Adjustment pro- Enter the process adjustment mode using the process adjustment remote control. cess mode 3. N358 composite signal / Tuner adjustment Adjustment item Adjustment conditions Adjustment procedure...
Page 21
LC-32D41U/LC-32M41U/LC-40C32U 6. DVI-I (analog) signal adjustment Adjustment item Adjustment conditions Adjustment procedure Adjustment DVI-I (analog) Feed the XGA (100%) white 1/2 window to DVI-I (analog). signal: XGA (1024 x 768) 60Hz SYNC: HV separate 100% White 0% Black Auto adjustment Bring the cursor on [ DVI ANALOG ADJ] and press [ENTER].
Page 22
LC-32D41U/LC-32M41U/LC-40C32U Adjustment item Adjustment conditions Adjustment procedure ±0.0020 ±0.0035 Point 2 Point 1 X=0.272 LEV20264 y=0.277 MG2G**** Note Test conditions of the set: MG2B**** AV MODE: [DYNAMIC] (Reset) MG2R**** Monochrome: ON Aging Time: Min. 60 minutes Point 1 LEV10200 MG1G****...
Page 23
LC-32D41U/LC-32M41U/LC-40C32U 2. Adjustment sequence (adjustment according to the G adjustment value of gradation 6) * Make sure the adjusting point gradations are correct since they are different for each model. Set the light level to MAX with the light control command (SBSL0016 for 45).
Page 24
LC-32D41U/LC-32M41U/LC-40C32U Start measurement Adjust RB to the target xy values. MG5RXXXX MG5BXXXX * XXXX indicates the adjusted values between 0000 and 1023 (4 digit decimal number with zero fill). * G is fixed. * The default adjustment value of RGB is the parameter value Repeat until RGB of the LEV5 command multiplied by 2.
Page 25
LC-32D41U/LC-32M41U/LC-40C32U Start measurement Adjust RB to the target xy values. MG3RXXXX MG3BXXXX * XXXX indicates the adjusted values between 0000 and 1023 (4 digit decimal number with zero fill). * G is fixed. * The default adjustment value of RGB is the parameter value of Repeat until RGB the LEV3 command multiplied by 2.
Page 26
LC-32D41U/LC-32M41U/LC-40C32U Start measurement Adjust RB to the target xy values. MG1RXXXX MG1BXXXX * XXXX indicates the adjusted values between 0000 and 1023 (4 digit decimal number with zero fill). * G is fixed. * The default adjustment value of RGB is the parameter value of Repeat until RGB the LEV1 command multiplied by 2.
Page 27
LC-32D41U/LC-32M41U/LC-40C32U 2.8. Menu list in process A mode Page Line Item MAIN Version Main microcomputer software version BOOT Version Monitor Version Monitor microcomputer software version EQ DATA CHECKSUM Sound parameter checksum TEMPERATURE Read value of temperature sensor LAMP ERROR Number of lamp error...
Page 28
LC-32D41U/LC-32M41U/LC-40C32U Page Line Item MONITOR GAMMA R 1 White balance adjustment OUT R-Point1 MONITOR GAMMA G 1 White balance adjustment OUT G-Point1 MONITOR GAMMA B 1 White balance adjustment OUT B-Point1 MONITOR GAMMA R 2 White balance adjustment OUT R-Point2...
Page 31
LC-32D41U/LC-32M41U/LC-40C32U Code Indication Description OFF_232C /* Set by the command from RS232C */ AVC_TACT /* Set by the front switch at the AVC center */ BSBOOKED /* The pre-set time has passed since TV was turned on from standby by the BS timer. */...
LC-32D41U/LC-32M41U/LC-40C32U CHAPTER 6. LC-32D41U/LC-32M41U/LC-40C32U TROUBLE SHOOTING TABLE Service Manual [1] TROUBLE SHOOTING TABLE <Power supply> No power supply (Front LED does not light up) and no power-up even is turned on (Front LED light up to blue) Is the AC cord connected? Connect the AC cord and turn on the power.
Page 33
LC-32D41U/LC-32M41U/LC-40C32U No audio output during UHF/VHF reception Is SIF output from the tuner (TU1101_Pin3) normal? Check the tuner and peripheral circuits. Is input signal fed to pin 21 (SOUNDIF 1) of IC1401 (SIF Demod- Check the filter circuits (Q1144 and Q1102-3) and peripheral cir- ulator) normal? cuits.
Page 34
LC-32D41U/LC-32M41U/LC-40C32U No audio output from external input <<INPUT-1>> Is L-ch audio signal fed from pin 12 of input terminal J501 to pin 53 of IC1403? Is R-ch audio signal fed from pin 18 of input terminal J501 to pin 54 of IC1403? <<INPUT-2>>...
Page 35
LC-32D41U/LC-32M41U/LC-40C32U <Composite video signal input> No video output (1) No video output from external input <<INPUT-1>> Select INPUT-1 and the input signal on the input switching menu screen. Is INPUT-1 selected on the input switching menu screen? When INPUT-1 cannot be selected since the characters INPUT-1 on the menu screen are gray.
Page 36
LC-32D41U/LC-32M41U/LC-40C32U <Composite video signal/S-video signal input> No video output (2) No video output from external input <<INPUT-2>> Select INPUT-2 and the input signal on the input switching menu screen. Is INPUT-2 selected on the input switching menu screen? When INPUT-2 cannot be selected since the characters INPUT-3...
Page 37
LC-32D41U/LC-32M41U/LC-40C32U No video output during digital broadcasting reception Is video signal sent to output terminal pin 4 of tuner (TU1101)? Check or replace the tuner's peripheral circuits. Is video signal fed to pin 7 of IC1103 (LEVEL ADJ)? Is control signal for level adjustment fed from pin 1 of IC1104 to pin 6 of IC1103? Check or replace IC1104 (CONTROL) and peripheral circuits.
Page 38
LC-32D41U/LC-32M41U/LC-40C32U <Component video signal input> No video output (3) No video output from external input <<INPUT-1>> Is INPUT-1 selected on the input switching menu screen? Select INPUT-1 and the input signal on the input switching menu screen. When INPUT-1 cannot be selected since the characters INPUT-1 on the menu screen are gray.
Page 39
LC-32D41U/LC-32M41U/LC-40C32U No video output from HDMI input (INPUT3) INPUT3 Are signals fed from HDMI (SC1501) connector to input terminals Is IC1501 (E PROM) accessed with I2C when connecting HDMI H_RX0± (pins 51 and 52), H_RX1± (pins 54 and 55), H_RX2±...
Page 40
LC-32D41U/LC-32M41U/LC-40C32U No video output from HDMI input (INPUT4) INPUT4 Are signals fed from HDMI (SC1502) connector to input terminals Is IC1502 (E PROM) accessed with I2C when connecting HDMI H_RX0± (pins 70 and 71), H_RX1± (pins 73 and 74, H_RX2±...
Page 41
LC-32D41U/LC-32M41U/LC-40C32U No video output from DVI input (INPUT 5) DIGITAL mode Analog mode Are signals fed from DVI (SC1503) connec- IS IC1505 (E2PROM) accessed with I2C Are signal fed from pins 25, 26, 27 (Ana- tor to input terminals H_RX0± (pins 8 and...
LC-32D41U/LC-32M41U/LC-40C32U CHAPTER 7. LC-32D41U/LC-32M41U/LC-40C32U MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS • IC8101 (RH-iXB145WJQZQ) An LSI of a MPEG-2 system decoder that performs back-end processing for digital broadcasting. This is equipped with a CPU (processor core: AM33-3), descrambler (DES), transport stream demultiplexer, video decoder (MPEG-2 MP @ HL compatible), graphic processor, audio decoder (AC3 compatible), and an NTSC video encoder.
Page 45
LC-32D41U/LC-32M41U/LC-40C32U ROL UNIT 73WJQZ INVERTER UNIT To LAMP To LAMP To LAMP QCNW-E847WJQZ CN5703 To LAMP To LAMP POWER UNIT To LAMP To LAMP To LAMP AC IN SP-R WJQZ 8 – 2...
LC-32D41U/LC-32M41U/LC-40C32U [2] SYSTEM BLOCK DIAGRAM MAIN 14.318MHz Xtal IC501 CVBS INPUT 14.318MHz CVBS/LR AV SWITCH MM1630CQ +3.3V +2.5V +1.8V YPbPr Component +9V_A Main Y/V Discrete CVBS1 83.5MHz Video1 CVBS2(Y) Main C/Cb LVDS OUT CVBS Main CVBS/LR INPUT Main Cr +2.5V...
LC-32D41U/LC-32M41U/LC-40C32U CHAPTER 9. LC-32D41U/LC-32M41U/LC-40C32U PRINTED WIRING BOARD ASSEMBLIES Service Manual [1] MAIN Unit • LC-32D41U MAIN Unit (Side-A) (LC-32D41U) 9 – 1...
LC-32D41U/LC-32M41U/LC-40C32U [3] R/C, LED Unit R/C, LED Unit (Side-A) C101 P101 D102 D103 RMC101 R104 IC101 Q101 SLD101 Q103 R102 R105 R112 Q102 D101 C104 R109 R/C, LED Unit (Chip Parts Side-A) [4] KEY Unit KEY Unit (Side-A) 9 – 19...
LC-32D41U/LC-32M41U/LC-40C32U CHAPTER 10. LC-32D41U/LC-32M41U/LC-40C32U SCHEMATIC DIAGRAM Service Manual [1] DESCRIPTION OF SCHEMATIC DIAGRAM 1. VOLTAGE MEASUREMENT CONDITION: 1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 120V. Signals are fed by a color bar signal generator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.
LCD PANEL (NOTE: THE PARTS 32M41U) HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT CABINET AND MECHANICAL INDEPENDENTLY.) PARTS DUNTKD640FM21/22/23 (MAIN SUPPLIED ACCESSORIES Unit) (LC-40C32U/LC-32D41U/LC- 32M41U) PACKING PARTS (NOT REPLACEMENT ITEM) DUNTKD641FM18/22/23 (R/C, LED Unit) (LC-40C32U/LC-32D41U/LC- [10] SERVICE JIGS (USE FOR 32M41U) SERVICING)
Page 120
RDENCA177WJQZ [2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN- DENTLY.) 32" WIDE LCD Panel Module Unit R1LK315T3LF15 [3] DUNTKD640FM21/22/23 (MAIN Unit) (LC-40C32U/LC-32D41U/LC-32M41U) C1101 Capacitor, 0.1 25V Ceramic VCKYCZ1EF104ZY C1102 Capacitor, 0.01 16V Ceramic...
Page 141
LC-32D41U/LC-32M41U/LC-40C32U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [5] DUNTKD643FM18/22/23 (IF Unit) (LC-40C32U/LC-32D41U/LC-32M41U) R578 Resistor, 0 1/16W Metal Oxide VRS-CY1JF000JY R579 Resistor, 1k 1/16W Metal Oxide VRS-TV1JD102JY R580 Resistor, 82 1/16W Metal Oxide VRS-CY1JF820JY R582 Resistor, 330 1/16W Metal Oxide...
Page 142
LC-32D41U/LC-32M41U/LC-40C32U [7] CABINET AND MECHANICAL PARTS...
Page 143
LC-32D41U/LC-32M41U/LC-40C32U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [7] CABINET AND MECHANICAL PARTS Front Cabinet Ass'y [LC-32D41U/LC-32M41U] CCABAB445WJ02 Front Cabinet Ass'y [LC-40C32U] CCABAB445WJ01 Front Cabinet Not Available Front Cover [LC-32D41U/LC-32M41U] GCOVAB740WJKA Front Cover [LC-40C32U] GCOVAB697WJKA Badge, SHARP Not Available...
Page 144
LC-32D41U/LC-32M41U/LC-40C32U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [7] CABINET AND MECHANICAL PARTS Connecting Cord (SP) QCNW-E285WJQZ Connecting Cord (LV) QCNW-E703WJPZ Connecting Cord (LA, LB) QCNW-E847WJQZ Speaker (L) RSP-ZA166WJZZ Speaker (R) RSP-ZA167WJZZ XBBS740P06000 Screw (for ANG), x6 Screw (for CAB-B), x3...
Page 145
LC-32D41U/LC-32M41U/LC-40C32U [9] PACKING PARTS (NOT REPLACEMENT ITEM) PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [9] PACKING PARTS (NOT REPLACEMENT ITEM) Packing Case [LC-32D41U] SPAKCC750WJZZ Packing Case [LC-32M41U] SPAKCC751WJZZ Packing Case [LC-40C32U] SPAKCC713WJZZ Stand Case SPAKFA916WJZZ SPAKPA382WJZZ Wrapping Paper (Monitor)
Page 146
LC-32D41U/LC-32M41U/LC-40C32U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [9] PACKING PARTS (NOT REPLACEMENT ITEM) Mirror Mat SPAKPA512WJZZ Frame SPAKXB028WJZZ No. Label TLABKA008WJZZ [10] SERVICE JIGS (USE FOR SERVICING) RCA Cable L=1500mm, Tuner to Terminal QCNW-C799WJPZ 12pins L=1000mm, Main to Power Unit (PE)
Page 148
LC-32D41U/LC-32M41U/LC-40C32U COPYRIGHT 2006 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
