Page 1: User Manual
IP Speaker User manual IS-640 VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299... -
Page 2: Table Of Contents
【Content】 1.Introduction ....................1 2.Parts list: ..................... 1 3.Panel description ..................2 4.Web Page Setting ..................3 5 Network ......................5 5.1 Network Status ....................5 5.2 WAN Setting ....................... 5 6. SIP Setting ....................6 6.1 Service Domain ....................6 6.2 Port Setting ...................... -
Page 3: Introduction
1.Introduction IS-640 IP Speaker provide a user-friendly control and simple voice broadcasting. Theproduct is designed to provide easy use for any office,department store,factory,school to be able to quickly broadcast announcements to their any assigned office or branch orclasses (or a group of office or branch or classes) . -
Page 4: Panel Description
3.Panel description 3.1 IP Reset Button : please press the button in 7-8 seconds till the status led flash blink to restore the factory default IP 192.168.0.100 3.2 Status : 1. light turn off : standby 2. light turn on : call in status 3. -
Page 5: Web
4.Web Page Setting Step 1: Browse the IP address http://192.168.0.100 from Internet Explorer Step 2: Please enter the username and password for authentication. (default username: voip，Password: 1234). The page follows when the username and password are correct Step 3: When you login the web page,you can see current System Information like Model Name,Firmware Version,Codec, Version .etc in this page. - Page 6 You also can see the function lists in the left side Include Network ,SIP Setting,STUN Settings, Update,System Authority,Save Change , Reboot . 4.1.Network : provide Status,WAN Setting 4.2.SIP Settings : Provide Service Domain Port Setting (SIP and RTP port setting),Code Setting,Audio Setting,Other Setting 4.3.STUN Setting : provide STUN Setting to penetrate the Firewal。...
-
Page 7: Network
5 Network 5.1 Network Status Network Status: you can check the current Network Setting in this page 5.2 WAN Setting (1) The TCP/IP Configuration item is to setup the WAN port’s network environment. You may refer to your current network environment to configure the system properly. -
Page 8: Sip Setting
6. SIP Setting 6.1 Service Domain In Service Domain Function you need to input the account and the related informations in this page, please refer to your ISP Provider. You can register three SIP accounts. field explain Realm 1 (Default) Active Default:Off , on: active this account Display Name... -
Page 9: Port Setting
6.2 Port Setting You can setup the SIP and RTP port number in this page. Each ISP provider will have different SIP/RTPport setting, please refer to the ISP to setup the port number correctly. When you finished the setting, please click the Submit button and “Save Charge”... -
Page 10: Audio Setting
6.4 Audio Setting Set speaker volume and voice detect function Field description Speaker Volume Default :50,maximum: 64 , minimum: 0. Detection Sensitivity Default:32,maximum: 32 , minimum: 0 Send Detected Default:OFF;ON:send Voice detection packet,OFF:don’t send Voice detection packet. Send Destination Send IP Address for sending Voice detection packet. When you finished the setting, please click the Submit button and “Save Charge”. -
Page 11: Other Setting
6.5 Other Setting SIP Expire Time: Default:60; set register’s time interval ;range:30~86400 sec When you finished the setting, please click the Submit button and “Save Charge”. 7.STUN Setting you can setup the STUN Enable/Disable and STUN Server IP address in this page. -
Page 12: Update
8.Update In Update you can update the system’s firmware to the new one or execute the factory reset to let the system back to default setting. 8.1 New Firmware Field Description Code Type Default:Risc (.gz). Provide Risc (system firmware.gz) and DSP (DSP firmware.ds). - Page 13 Setep 2:choose [gz] file ,then click [open]. Setep 3:[File Location] will show the file location and file name. after confirm ,please click submit Setep 4: please don’t turn power off when system updating. It is important. The updating time is about 3 minutes. Setep 5: After finished update firmware,please click Refresh (F5),then you can set other settings VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 14: Default Setting
8.2 Default Setting In this page: Update/ Default Settings, you could restore the factory default settings to the system. All setting will restore default setting. IP will retain original IP as usual not default IP. Step1: choose Update Default Setting. When you want to restore default setting,please click [Restore]. -
Page 15: System Authority
9.System Authority In System Authority you can change your login name and password. When you finished the setting, please click the Submit button and “Save Charge”. 10.Save Change In Save Change you can save the changes you have done. If you want to use new setting in the VoIP system, you have to click the Save button. -
Page 16: Reboot
11.Reboot Reboot function you can restart the system. If you want to restart the system, you can just click the Reboot button, then the system will automatically. Please don’t turn power off while rebooting,thanks After reboot, webpage will be back to main page. Please click refresh(F5) ,then you can set other settings VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
