19" LCD Color Monitor

2.LCD Monitor Description

The LCD Monitor will contain main board, power board, key board and an audio board which house the flat panel
control logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Power Board
(Include adapter and inverter)
AC-IN
110V-240V
3. Operation Instructions

3.1 General Instructions

Press the power button to turn the monitor on or off. The other control buttons are located at front of the panel. By
changing these settings, the picture can be adjusted to your personal performance.
The power cord should be connected and insert to adaptor.
-
Connect the video cable from the monitor to the computer VGA card.
-
-
Press the power button to turn on the monitor, the power indicator will light up to Green.
3.2 Control Buttons
-
Power Button:
When pressed, the monitor enters the off mode, and the LED turns blank. Press again to restore normal status.
-
Left / Right Button:
When the OSD show on screen, Left/Right Button are used to control the monitor functions. Press to switch
functions or adjust settings. And if the OSD off, Left buttons is used to automatically set the H Position, V Position,
Clock and Phase.
-
Power Indicator:
Green
— Power On mode.
Orange — Power Saving mode.
Blank
— Power Off Mode.
Monitor Block Diagram
CCFT Drive.
Audio board
4
Flat Panel and
CCFL backlight
Main Board
Keyboard
HOST Computer
HP VS19E
RS232 Connector
For white balance
adjustment in
factory mode
Video signal, DDC
