SERVICE MANUAL
15" LCD Monitor
VS15 Series
THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY
REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE
CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF
PUBLICATION AND DISCLAIMS RELIABILITY FOR CHANGES, ERRORS OR OMISSIONS.
MANUFACTURE DATA: Dec-29-2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS15 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP VS15 Series

Summary of Contents for HP VS15 Series

  • Page 1 SERVICE MANUAL 15” LCD Monitor VS15 Series THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RELIABILITY FOR CHANGES, ERRORS OR OMISSIONS.

  • Page 2: Table Of Contents

    HP VS15 Service Manual Table of Contents Table of Contents ---------------------------------------------------------------------------------- 02 Revision List ---------------------------------------------------------------------------------------- 1.Product Feature -------------------------------------------------------------------------------- 2.LCD Monitor Description ----------------------------------------------------------------------- 3.Operation Instructions -------------------------------------------------------------------------- 3.1 General Instructions ----------------------------------------------------------------------- 3.2 Control Button ------------------------------------------------------------------------------- 3.3 Adjusting The Picture --------------------------------------------------------------------- 4. Input/Output Specification ---------------- --------------------------------------------------- 4.1 Input Signal Connector --------------------------------------------------------------------10...
  • Page 3 HP VS15 Service Manual 7.1 For LG Panel (Scaler:TSU16AK) -------------------------------------------------21 7.1.1Main Board ---------------------------------------------------------------------21 7.1.2 Audio Board ---------------------------------------------------------------------27 7.1.3 Power Board --------------------------------------------------------------------28 7.2 For AU Panel (Scaler:ADE3800SXL) --------------------------------------------30 7.2.1Main Board ---------------------------------------------------------------------30 7.2.2 Audio Board ---------------------------------------------------------------------35 7.2.3 Power Board --------------------------------------------------------------------36 8. PCB Layout ---------------------------------------------------------------------------------------38 8.1 Main Board -----------------------------------------------------------------------------------38...

  • Page 4: Revision List

    HP VS15 Service Manual Revision List Revision Date Change Description Dec-29-04...

  • Page 5: Product Feature

    HP VS15 Service Manual 1. Product Feature 38.1cm (15”) a-si TFT Active matrix LCD panel, 0.297mm dot pitch Scalar chipset: MST TSV15AK Microprocessor controlled scan technology 450:1 Typical Contrast Ratio and 250-nits typical Brightness Response time 16ms and Viewing Angle 130(Horizontal) and 100(Vertical) 11 factory presets, user mode 10 Vertical refresh rate 50Hz to 76Hz;...

  • Page 6: Operation Instructions

    HP VS15 Service Manual 3. Operation Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located on the side of the front panel. By changing these settings, the picture can be adjusted to your personal performance.

  • Page 7: Control Button

    HP VS15 Service Manual 3.2 Control Buttons...

  • Page 8: Adjusting The Picture

    HP VS15 Service Manual 3.3 Adjust the Picture...

  • Page 9: Input/Output Specification

    HP VS15 Service Manual Brightness Adjust the brightness. Contrast Adjust the contrast Adjust the: Auto Adjustment: Adjusts the main settings and produces a stable, centered image. Image H-Position: horizontal position of the screen image. Control V-Position: vertical position of the screen image.

  • Page 10: Factory Preset Display Modes

    HP VS15 Service Manual VGA connector layout PIN 1 PIN 5 PIN 11 4.2 Factory Preset Display Modes Factory Pre-set Video Input Modes Horizontal Vertical Frequency Pre-set Pixel Format Frequency (kHz) (Hz) 640 x 480 31.5 60.0 640 x 480 37.9...

  • Page 11: Power Supply Requirements

    HP VS15 Service Manual 1024 x 768 48.4 60.0 1024 x 768 56.5 70.0 1024 x 768 60.0 75.0 4.3 Power Supply Requirements PARAMETER RANGE AC Input Voltage 90 to 264V AC Input Frequency 47 to 63 Hz Inrush Current...
  • Page 12 HP VS15 Service Manual CPT CLAA150XP02...

  • Page 13: Optical Characteristics

    HP VS15 Service Manual 5.2 Optical Characteristics SUMSANG LTM150XO-LO1...
  • Page 14 HP VS15 Service Manual CPT CLAA150XP02...

  • Page 15: Block Diagram

    HP VS15 Service Manual 6. Block Diagram 6.1 Monitor Exploded View...

  • Page 16: Software Flow Chart

    HP VS15 Service Manual 6.2 Software Flow Chart MCU initialize. Is the eeprom blank? Program the eeprom by default values. Get the PWM value of brightness from eeprom. Check the pin PANEL1 and PANEL2 to tell which panel to get with it.

  • Page 17: Electrical Block Diagram

    HP VS15 Service Manual 6.3 Electrical Block Diagram 6.3.1 Scalar Board Block Diagram...

  • Page 18: Inverter/Power Board

    HP VS15 Service Manual 6.3.2 Inverter / Power Board Block Diagram Inverter Block Diagram...
  • Page 19 HP VS15 Service Manual Power Block Diagram...

  • Page 20: Schematic

    HP VS15 Service Manual 7. Schematic FOR SAMSUNG Panel (Scaler: TSU16AK) 7.1.1 Main Board GNDR GNDR GNDG GNDG DDC_CLK VCC1.8 VCC3.3 VAA1 VAA2 VAA3 VAA4 DDC_DAT GNDB GNDB ST_DET1 HSYNC HSYNC VSYNC VSYNC DDC_WP VCC1.8 3.INPUT VCC3.3 VAA1 DDC_WP ST_DET1...
  • Page 21 HP VS15 Service Manual 3,4,5,6,7 VCC5V+ VCC5V U201 change to 1.8V TO-252 VCC12V D202 U201 DIODE R202 VCC1.8 AZ1117D-1.8 CN201 　 1/16W VCC1.8 ON_OFF 　 R201 4.7K 1/16W C209 C210 C211 C212 VCC12V VCC12V D201 DIODE SCHOTTKY 　 C201 R212 4.7K...
  • Page 22 HP VS15 Service Manual CN301 DB15 　 　 FB301 1/16W R301 1/16W C304 0.047uF FB302 　 1/16W R302 　 1/16W C305 0.047uF D323 　 　 MLL5232B 5.6V FB303 1/16W R303 1/16W C306 0.047uF 　 R304 1/16W C307 0.001uF D322 PC5V...
  • Page 23 HP VS15 Service Manual VCC3.3 FB401 VCC1.8 FB402 VCC3.3 VCC1.8 600 OHM 600 OHM C405 C414 10uF/16V 10uF/16V VPLL VDVI VDPLL C406 C407 C408 C409 C410 C411 C412 C413 C415 C416 C417 C418 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF...
  • Page 24 HP VS15 Service Manual CN501 PA[0..9] PA[0..9] PA[0..9] PA[0..9] LVA3P RA1P CN503 LVA3M FB0N RA1N RA3N LVACKP RA2P RA3P FB0P LVACKM LVB0M RXO0- RXO0+ LVB0P RA2N LVA2P RA3P RA2N FB1N LVB1M RXO1- RXO1+ LVB1P LVA2M FB1P LVB2M RXO2- RXO2+ RA3N...
  • Page 25 HP VS15 Service Manual VCPU VCPU R602 RP601 RP602 RP603 　 　 R601 C601 1/16W 1/16W 　 1/16W RP604 0.1uF 　 　 1/16W 1/16W C602 R606 R607 　 　 　 22pF 1/16W 1/16W 1/16W R644 　 U601 1/16W X601 CHANGE TO 24M HZ EA/VP P0.0...

  • Page 26: Audio Board

    HP VS15 Service Manual 7.1.2 Audio Board CN701 300 OHM 　 1/16W R701 U701 300 OHM 　 1/16W R702 C701 0.1uF/16V C702 0.1uF/16V LINN RINN C728 C729 C703 0.1uF/16V C704 0.1uF/16V LINP RINP LINE IN GREEN AGND 470pF 470pF AGND...

  • Page 27: Power Board

    HP VS15 Service Manual 7.1.3 Power Board (include inverter and power)
  • Page 28 HP VS15 Service Manual...

  • Page 29: For Au Panel (Scaler:ade3800Sxl)

    HP VS15 Service Manual 7.2 For CPT Panel (Scaler:ADE3800SXL) 7.2.1 Main Board 　 1/16W DB-RXD R101 RS232-RX [5] 　 2.7K 1/16W C100 D100 R100 56pF AGND1 　 　 L101 1/16W R104 1/16W C102 0.1uF INR+ [3] 　 　 R-GND L102...
  • Page 30 HP VS15 Service Manual OVDD18 VDDPLL18 RSDS_B1- RSDS_B1- [4] L100 120 OHM RSDS_B1+ RSDS_B1+ [4] Kona Exposed Pad Size 3.9mmx3.9mm. RSDS_B2- RSDS_B2- [4] RSDS_B2+ Put vias on the expose pad. RSDS_B2+ [4] C118 C119 C120 C121 C122 C123 C124 C125 Don't put green-mask in vias of expose pad.
  • Page 31 HP VS15 Service Manual CN303 CN101 RSDS_B2+ LVDS_O0 RXO0- RXO0+ LVDS_O1 LCD_GND RSDS_B2- LVDS_O2 RXO1- RXO1+ LVDS_O3 RSDS_B1+ LVDS_O4 RXO2- RXO2+ LVDS_O5 RSDS_B1- LVDS_O6 RXOC- RXOC+ LVDS_O7 LVDS_O8 RXO3- RXO3+ LVDS_O9 LVDS_E0 RXE0- RXE0+ LVDS_E1 LVDS_O0 LVDS_E2 RXE1- RXE1+ LVDS_E3...
  • Page 32 HP VS15 Service Manual +5V-MCU +5V-MCU +5V-MCU 6/24 Modify from +12V to +5V-MCU +12V +5V-MCU U104 C168 R146 　 0.1uF/16V 1/16W R148 　 C0603 R0603 1/16W R0603 EPR-SCL R151 EPR-SDA 　 1/16W R142 C162 R0603 C163 C164 0.1uF/16V Q101 Q102...
  • Page 33 HP VS15 Service Manual +12V +5VA +3.3V CN106 U105 DVDD33 ON_OFF D118 SR34 R172 2.7K 　 1/16W BRIGHTNESS [5] VOUT VCC12V VCC12V +5AV +5AV L111 VCC5V VCC5V C183 + C179 120 OHM C177 AIC1084-33CE TO263 0.1uF/16V 47uF/25V CON402(PITCH 2.00) 0.1uF/16V...

  • Page 34: Audio Board

    HP VS15 Service Manual 7.2.2 Audio Board U601 C601 0.1uF/16V C602 0.1uF/16V LINN RINN C603 0.1uF/16V C604 0.1uF/16V LINP RINP AUDIO-SD1 SHUTDOWN BYPASS C605 1uF/50V +5VA1 PVDDL PVDDR FB601 300 OHM FB603 300 OHM ROUT+ LOUT+ LOUTP ROUTP R625 R624...

  • Page 35: Power Board

    HP VS15 Service Manual 7.2.3 Power Board (include inverter and power)
  • Page 36 HP VS15 Service Manual...

  • Page 37: Pcb Layout

    HP VS15 Service Manual 8. PCB Layout 8.1 MAIN BOARD...
  • Page 38 HP VS15 Service Manual...

  • Page 39: Inverter/Power Board

    HP VS15 Service Manual 8.2 POWER BOARD...
  • Page 40 HP VS15 Service Manual...
  • Page 41 HP VS15 Service Manual...
  • Page 42 HP VS15 Service Manual...
  • Page 43 HP VS15 Service Manual 8.3 KEY BOARD...

  • Page 44: Maintainability

    HP VS15 Service Manual 9. Maintainability 9.1 Equipments and Tools Requirement 1.) Multi-meter. 2.) Oscilloscope. 3.) Pattern Generator. 4.) DDC Tool with an IBM Compatible Computer. 5.) Alignment Tool. 6.) LCD Color Analyzer. 7.) Service Manual. 8.) User Manual.

  • Page 45: Trouble Shooting

    HP VS15 Service Manual 9.2 Trouble Shooting 9.2.1 Main Board No power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the power section...
  • Page 46 HP VS15 Service Manual No picture (LED is orange) No picture Y601 oscillate waveforms Key is under control? are normal Replace Y601 X401 oscillate waveforms are normal Replace U601 Replace X401 Replace U401 Check if the sync signal from computer is output and video...
  • Page 47 HP VS15 Service Manual Panel Power Circuit Measure Q204 base is high level? Y601 oscillate waveforms are normal Check Q204 and Q203 Replace Y601 are broken or CN503 Replace U601 Check Correspondent component. Replace U401 Replace PANEL...
  • Page 48 HP VS15 Service Manual 9.2.2 Power Board No Power No power Check AC line volt 110V or 220V Check AC line Check the voltage of C905(+) Check F901, bridge rectified circuit Check start voltage for the pin3 of IC901 Check R906, R907,IC901...
  • Page 49 HP VS15 Service Manual No Backlight Check C201(+) =12V Change F902 Check D201/Q209/Q210 Check ON/OFF signal Check Interface board Check U201 pin9=12V voltage Change Q201 or Q202 Check the pin1 of U201 have saw tooth wave Change U201 Check D201(-) have the output of square wave at short time.

  • Page 50: Keypad Board

    HP VS15 Service Manual 9.2.3 Keypad Board OSD is unstable or not working Is Keypad board connecting normally Connect Keypad Board Is Button Switch normally Replace Button Switch Replace Keypad Board Is Keypad board normally Check main board...

  • Page 51: White-Balance, Luminance Adjustment

    C. SRGB SRG color temp. parameter is x = 313±10, y = 329 ±10, Y = 210 ±10 cd/m 3. Into factory mode of HP L1902 A. Press MENU button during 2 seconds along with press Power button will activate the factory mode, then MCU will do AUTO LEVEL automatically.
  • Page 52 HP VS15 Service Manual 7. Repeat above procedure ( item 4,5,6) until chroma 7120 RGB value meet the tolerance =100±2 B. Adjust SGB color-temperature 1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button ) 2. Switch the MEM .Channel to Channel 4( with up or down arrow on chroma 7120 ) 3.

  • Page 53: Bom List

    HP VS15 Service Manual 12. BOM List T560KCFDKHHPA CBPC560KCFHPA CONVERSION BOARD KEPC561KD4 KEY BOARD PWPC1521CPH3 POWER BOARD 15L8118 2 MAIN FRAME 23L3178690 6A LOGO 33L4788 PD L STAND-CAP 34L1462APC B BEZEL 44L3577 1 44L3577 2 44L3577 3EPE 44L3577624 1A CARTON...
  • Page 54 HP VS15 Service Manual 40L 457624 1B CPU LABEL 40L 45762412B CBPC LABEL C118 67L305V470 4 CAPEC 47uF/25 C128 67L215V470 4N LOW ESR EC 47UF 25V NC C132 67L305V100 3 10UF +-20% 16V 105 C134 67L305V100 3 10UF +-20% 16V 105...
  • Page 55 HP VS15 Service Manual C113 65L0603470 31 CHIP 47PF 50V NPO C114 65L0603470 31 CHIP 47PF 50V NPO C115 65L0603104 12 0.1UF +-10% 16V X7R C116 65L0603330 32 CHIP 33PF 50V X7R C117 65L0603330 32 CHIP 33PF 50V X7R C119 65L0603104 32 CHIP 0.1UF 50V X7R...
  • Page 56 HP VS15 Service Manual C168 65L0603104 12 0.1UF +-10% 16V X7R C169 65L0603104 32 CHIP 0.1UF 50V X7R C170 65L0603104 32 CHIP 0.1UF 50V X7R C171 65L0603104 32 CHIP 0.1UF 50V X7R C172 65L0603104 32 CHIP 0.1UF 50V X7R C173 65L0603104 32 CHIP 0.1UF 50V X7R...
  • Page 57 HP VS15 Service Manual C621 65L0603473 32 CHIP 0.047UF 50V X7R C622 65L0805225 17 CHIP 2.2UF 16V Y5V C623 65L0603473 32 CHIP 0.047UF 50V X7R C624 65L0603104 32 CHIP 0.1UF 50V X7R C626 65L0603104 32 CHIP 0.1UF 50V X7R C627 65L0603473 32 CHIP 0.047UF 50V X7R...
  • Page 58 HP VS15 Service Manual L119 71L 56K121 CHIP BEAD 120OHM 6A Q100 57L 417 6 PMBS3906/PHILIPS-SMT(0 Q101 57L 417 4 PMBS3904/PHILIPS-SMT(0 Q102 57L 417 6 PMBS3906/PHILIPS-SMT(0 Q103 57L 417 6 PMBS3906/PHILIPS-SMT(0 Q104 57L 417 4 PMBS3904/PHILIPS-SMT(0 Q105 57L 763 1...
  • Page 59 HP VS15 Service Manual R139 61L0603472 CHIPR 4.7K OHM +-5% 1/ R140 61L0603472 CHIPR 4.7K OHM +-5% 1/ R141 61L0603472 CHIPR 4.7K OHM +-5% 1/ R142 61L0603101 CHIPR 100 OHM +-5% 1/1 R143 61L0603103 CHIPR 10K OHM +-5% 1/1 R146...
  • Page 60 HP VS15 Service Manual R212 61L0603103 CHIPR 10K OHM +-5% 1/1 R213 61L0603103 CHIPR 10K OHM +-5% 1/1 R601 61L0603124 CHIP 120KOHM 1/10W R602 61L0603100 2F 10K 1% 1/10W R603 61L0603101 CHIPR 100 OHM +-5% 1/1 R604 61L0603200 2F CHIPR 20KOHM +-1% 1/10...
  • Page 61 HP VS15 Service Manual C101 65L0603121 31 CHIP 120PF 50V NPO C102 65L0603121 31 CHIP 120PF 50V NPO C103 65L0603121 31 CHIP 120PF 50V NPO C104 65L0603121 31 CHIP 120PF 50V NPO C105 65L0603471 31 CAP:CER 470PF 5%50V SM C106...
  • Page 62 HP VS15 Service Manual C925 67L215C102 3H EC LESR 1000UF16V HERM C926 67G215C4714HV EC 470UF 25V 10*13 CN102 95G8021 12526 CONNECTOR CN201 33L8020 2D AC CONN.2P R/A DIP BY ACE CN202 33L8020 2D AC CONN.2P R/A DIP BY ACE F901...
  • Page 63 HP VS15 Service Manual C936 65L0805104 32 CHIP 0.1UF 50V X7R D201 93L3004 3 SM340A D203 93L 39S 3 T BZT52-C11 Q201 57L 760 5 DTC144WKA BY ROHM SMT( Q202 57L 760 4 DTA144WKA BY ROHM SMT( Q203 57L 763 3...
  • Page 64 HP VS15 Service Manual R927 61L0805102 CHIPR 1K OHM +-5% 1/8W R928 61L0805102 CHIPR 1K OHM +-5% 1/8W R929 61L0603000 CHIPR 0OHM +-5% 1/10W R931 61L0603102 CHIPR 1K OHM +-5% 1/10 U201 56L 608 1 TL1451ACD ZD901 93L 39S 20 T...
  • Page 65 HP VS15 Service Manual 95L 900 43 HARNES 96G 29 6 SHRINK TUBE UL/CSA CN901 87G 501 12 RF AC SOCKET 90L6084 1 HEAT SINK AM1L1730 8128 GP SCREW M3*8 D910 93L 60249 FCH10U15 TO-220 90L6084 1 HEAT SINK AM1L1730 8128 GP...

  • Page 66: T560Ks4Dkhhpa

    HP VS15 Service Manual T560KS4DKHHPA CBPC560KS4HPA CONVERSION BOARD KEPC561KD4 KEY BOARD PWPC1521SEH3 LCD INVERTER BOARD 15L8118 1 MAIN FRAME 23L3178690 6A LOGO 33L4788 PD L STAND-CAP 34L1462APC B BEZEL 44L3577 1 44L3577 2 44L3577 3EPE 44L3577624 1A CARTON 45L 76 28 H...
  • Page 67 HP VS15 Service Manual 40L 45762412B CBPC LABEL C204 67L 215221 3H LOW ESR 220UF +-20% 16V C209 67L309V470 3 47UF 16V 85C C211 67L309V470 3 47UF 16V 85C C213 67L309V470 3 47UF 16V 85C C215 67L309V470 3 47UF 16V 85C...
  • Page 68 HP VS15 Service Manual C230 65L0603474 17 CHIP CAP.CER 0.47UF -20 C304 65L0603473 32 CHIP 0.047UF 50V X7R C305 65L0603473 32 CHIP 0.047UF 50V X7R C306 65L0603473 32 CHIP 0.047UF 50V X7R C307 65L0603102 32 1000PF +-10% 50V X7R C308 65L0603473 32 CHIP 0.047UF 50V X7R...
  • Page 69 HP VS15 Service Manual C604 65L0603220 31 CHIP 22PF 50V NPO C605 65L0603104 32 CHIP 0.1UF 50V X7R C606 65L0603102 32 1000PF +-10% 50V X7R C607 65L0603102 32 1000PF +-10% 50V X7R C608 65L0603102 32 1000PF +-10% 50V X7R C609...
  • Page 70 HP VS15 Service Manual D303 93L 6433P BAV99 D304 93L 64 42 P BAV70 SOT-23 D317 93L 39146 LL5232B SMT D318 93L 39146 LL5232B SMT D319 93L 39146 LL5232B SMT D320 93L 39146 LL5232B SMT D321 93L 39146 LL5232B SMT...
  • Page 71 HP VS15 Service Manual R203 61L0603102 CHIPR 1K OHM +-5% 1/10W R204 61L0603103 CHIPR 10K OHM +-5% 1/10 R205 61L0603472 CHIPR 4.7K OHM +-5% 1/1 R207 61L0603472 CHIPR 4.7K OHM +-5% 1/1 R208 61L0603103 CHIPR 10K OHM +-5% 1/10 R210...
  • Page 72 HP VS15 Service Manual R409 61L0603103 CHIPR 10K OHM +-5% 1/10 R410 61L0603472 CHIPR 4.7K OHM +-5% 1/1 R501 61L0603000 CHIPR 0OHM +-5% 1/10W R502 61L0603000 CHIPR 0OHM +-5% 1/10W R503 61L0603000 CHIPR 0OHM +-5% 1/10W R504 61L0603000 CHIPR 0OHM +-5% 1/10W...
  • Page 73 HP VS15 Service Manual R703 61L0603124 CHIP 120KOHM 1/10W R704 61L0603100 2F 10K 1% 1/10W R705 61L0603101 CHIPR 100 OHM +-5% 1/10 R706 61L0603200 2F CHIPR 20KOHM +-1% 1/10W R707 61L0603101 CHIPR 100 OHM +-5% 1/10 R708 61L0603200 2F CHIPR 20KOHM +-1% 1/10W...
  • Page 74 HP VS15 Service Manual C103 65L0603121 31 CHIP 120PF 50V NPO C104 65L0603121 31 CHIP 120PF 50V NPO C105 65L0603471 31 CAP:CER 470PF 5%50V SMT C106 65L0603471 31 CAP:CER 470PF 5%50V SMT 81L 14 9 HL HI-LIGHT LED FB101 71L 59G301...
  • Page 75 HP VS15 Service Manual CN102 95G8021 12526 CONNECTOR CN201 33L8020 2D AC CONN.2P R/A DIP BY ACES CN202 33L8020 2D AC CONN.2P R/A DIP BY ACES F901 84L 7H200 SL 250V/2A LIHEL FUSE FB903 71L 55 19 T FERRITE BEAD 9X3.5X0.8...
  • Page 76 HP VS15 Service Manual D203 93L 39S 3 T BZT52-C11 Q201 57L 760 5 DTC144WKA BY ROHM SMT Q202 57L 760 4 DTA144WKA BY ROHM SMT Q203 57L 763 3 AO4411 SO-8 BY AOS SMT R204 61L0603103 CHIPR 10K OHM +-5% 1/10...
  • Page 77 HP VS15 Service Manual R929 61L0603000 CHIPR 0OHM +-5% 1/10W R931 61L0603102 CHIPR 1K OHM +-5% 1/10W U201 56L 608 1 TL1451ACD ZD901 93L 39S 20 T RLZ22B BY ROHM ZD904 93L 39S 19 T PTZ7.5B 715L1425 1 33UF 105 　...
  • Page 78 HP VS15 Service Manual 96G 29 6 SHRINK TUBE UL/CSA CN901 87G 501 12 RF AC SOCKET 90L6084 1 HEAT SINK AM1L1730 8128 GP SCREW M3*8 D910 93L 60249 FCH10U15 TO-220 90L6084 1 HEAT SINK AM1L1730 8128 GP SCREW M3*8...
  • Page 79 文件名: AOC Service Manual- HP VS15 目录: D:\Service Manual\LCD\HP\AOC Service Manual- HP VS15 模板: C:\Documents and Settings\qiufen.mao\Application Data\Microsoft\Templates\Normal.dotm 标题: 主题: 作者: 关键词: 备注: 创建日期: 2005-1-3 11:10:00 修订号: 上次保存日期: 2005-1-10 11:17:00 上次保存者: stsngq 编辑时间总计: 1,043 分钟 上次打印时间: 2008-1-24 14:11:00 打印最终结果 页数:...
  • Page 80 字数: 8,322 (约) 字符数: 47,436 (约)
