PARTS LIST

EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH
THE IEC SYMBOL
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE COMPONENTS IN WHICH SAFETY
! ! !
CAN OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED , USE ONLY THE REPLACEMENT
PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE
DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST
BE MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT
BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION :
Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50V and less than 1000µF of Ceramic type and Electrolytic type.
PACKING & ACCESSORIES
REF.NO.
PART NO.
614 335 1115 CARTON CASE
614 334 4841 CUSHION,REAR
614 334 4858 CUSHION,FRONT
614 335 1153 INSTRUCTION MANUAL
945 011 9737 POLY BAG-0250X0350*NC,
945 068 7281 POLY SHEET-0340X0280*NC,SET
945 037 8103 POLY BAG-0150X0500*NC,
945 037 9834 POLY BAG-0180X0250*NC,
614 325 5536 CARD,WARRANTY,SAP
945 063 7484 ASSY,ANTENNA,LOOP
945 079 7430 REMOCON
58
614 334 9846 ASSY,BOX,SPEAKER
CABINET & CHASSIS
REF.NO.
PART NO.
1
614 334 4704 LID,CASSETTE
2
914 334 4804 SPRING,DOOR DECK,CASSETTE
3
614 334 4636 KNOB,SLIDE
4
914 316 2491 KNOB,ROTARY,VOL
5
614 335 4017 ASSY,PANEL FRONT
6
914 309 7960 ASSY,GEAR,CASSETTE
7
614 334 6173 PWB,CONNECT2,CASSETTE GEAR
8
614 334 4643 KNOB,DECK,MECHA,REC
9
614 334 4650 KNOB,DECK,MECHA,PLAY
10
614 334 4667 KNOB,DECK,MECHA,REW
11
614 334 4674 KNOB,DECK,MECHA,FFWD
12
614 334 4681 KNOB,DECK,MECHA,STOP/EJECT
13
614 334 4698 KNOB,DECK,MECHA,PAUSE
14
614 334 4728 MOUNTING,DECK,KNOB
15
614 327 8023 SPRING,REC
16
614 334 4582 GEAR
17
614 334 4766 SHAFT
18
614 334 4629 KNOB,TUNING
19
914 310 3890 SPACER,MECHA
20
614 335 4147 COVER,PICK-UP
21
614 334 4506 BUTTON,POWER
22
914 322 2133 ASSY,GEAR,LID,CD
23
614 335 4154 MOUNTING,CD
24
914 334 4811 SPRING,DOOR CD
25
914 303 0264 LATCH,PUSH,CD DOOR LOCKING
26
614 334 4711 LID,CD
27
614 334 6166 PWB,CONNECT1,AC CORD
28
614 335 1061 ASSY,CABINET,REAR
29
914 327 7669 ASSY,MECHA,DA11B3N
or
914 333 0395 ASSY,MECHA,DA11B3V
30
614 334 4513 BUTTON,PLAY,4 KEY
31
914 333 3389 ASSY,MECHA,TK20FX-S898001
PRODUCT SAFETY NOTICE
DESCRIPTION
INST MANUAL
AC CORD
ACCESSORY
DESCRIPTION
FIXING PARTS
REF.NO.
PART NO.
Y01
411 193 8603 SCR S-TPG BRZ+FLG 3X10,
Y02
411 193 8603 SCR S-TPG BRZ+FLG 3X10,
Y03
411 021 3404 SCR S-TPG BIN 3X10,
Y04
411 184 0906 SCR S-TPG BIN 2.3X10,
Y05
411 021 3404 SCR S-TPG BIN 3X10,
Y06
411 021 3404 SCR S-TPG BIN 3X10,
Y07
411 204 2101 SCR S-TPG PAN 2X3,
Y08
411 178 4903 SCR S-TPG BIN 2.6X8,SHAFT+PWB
Y09
411 021 3404 SCR S-TPG BIN 3X10,
Y10
411 045 1509 SCR PAN+SW 2.6X6,GEAR+VC
Y11
411 205 8508 WASHER Z 2.6X10X0.5,
Y12
411 205 8409 SCR S-TPG BIN 2.6X8,
Y13
411 021 3404 SCR S-TPG BIN 3X10,
Y14
411 194 8503 WASHER Z 2.6X10X0.5,
Y15
411 021 1608 SCR S-TPG BIN 2.6X10,
Y16
411 184 0906 SCR S-TPG BIN 2.3X10,
Y17
411 021 3404 SCR S-TPG BIN 3X10,
Y18
411 021 3404 SCR S-TPG BIN 3X10,
Y19
411 021 3404 SCR S-TPG BIN 3X10,
Y20
411 021 3404 SCR S-TPG BIN 3X10,
Y21
411 098 7701 SCR S-TPG FLT 3X10,
Y22
411 021 3404 SCR S-TPG BIN 3X10,MTG+REAR
Y23
411 126 4108 SCR S-TPG BIN 3X16,PANEL+REAR
Y24
411 191 4201 SCR S-TPG BRZ+FLG 3X12,
ELECTRICAL-PARTS
REF.NO.
PART NO.
32
914 309 8790 ASSY,WIRE,DECK MAC
33
914 309 8806 ASSY,WIRE,DECK MAC
51
914 274 2014 CORD,ID CONNECTOR
52
323 032 8104 FUSE 250V 2.5A
! ! !
53
914 335 1369 ASSY,WIRE,CD-MAC
54
614 335 8558 FLEXIBLE FLAT CABLE,CD-LASER
! ! !
55
914 335 1352 ASSY,WIRE,AMP-SW
56
645 083 7630 TRANS,POWER
! ! !
57
945 068 1050 CORD,POWER-2.0MK
! ! !
- 4 -
DESCRIPTION
DECK GEAR
DECK PWB+PANEL FRONT
DECK PWB+PANEL
PANEL+FRONT PWB
PANEL+MTG DECK KNOB
PANEL+DECK MECHA
SPRING REC+DECK MECHA
MTG CD+AMP PWB
KNOB TUNING+SHAFT
SHAFT+KNOB TUNING
MTG CD+CD PWB
MECHA CD+MOUNTING
MTG CD+MECHA CD
BUTTON POWER PWB+MTG
MTG CD+ASSY GEAR
MTG+CD PWB SWITCH
REAR+PWB POWER
REAR+STOPPER
PANEL+REAR+MTG
REAR+TRANS
DESCRIPTION
