eyeLCD-4600/5500-LE-700
EYEVIS LCD LINE
(Version 1)
User´s Manual
User´s Manual
Version 1.0 (November 2013)
Version 1.0 (November 2013)
Technical changes reserved.
Technical changes reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eyeLCD-4600-LE-700 and is the answer not in the manual?

Questions and answers

Related Manuals for Eyevis eyeLCD-4600-LE-700

Summary of Contents for Eyevis eyeLCD-4600-LE-700

  • Page 1 EYEVIS LCD LINE (Version 1) User´s Manual User´s Manual Version 1.0 (November 2013) Version 1.0 (November 2013) Technical changes reserved. Technical changes reserved.
  • Page 2 The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by eyevis GmbH. eyevis GmbH resumes no responsibility or liability should not be construed as a commitment by eyevis GmbH. eyevis GmbH resumes no responsibility or liability for any errors or inaccuracies that may appear in this documentation.

  • Page 3: Table Of Contents

    EYE-LCD-4600/5500-LE-700 EYE-LCD-4600/5500-LE-700 Table of Content SAFETY/SICHERHEIT/SÉCURITÉ SAFETY PRECAUTION SICHERHEITSVORKEHRUNGEN PRÉCAUTIONS DE SÉCURITÉ FEATURES PACKING CONTENTS CONNECTORS ENVIRONMENTAL STATE MAIN POWER SWITCH AND AC INLET POWER SWITCHES INPUT AND OUTPUT CONNECTORS OPERATING THE MONITOR SETUP PROCESS TURNING MONITOR ON AND OFF ADJUSTING VOLUME AND INPUT SOURCE OSD KEYPAD FUNCTION LIST THE LED INDICATE STATUS...
  • Page 4 EYE-LCD-4600/5500-LE-700 EYE-LCD-4600/5500-LE-700 TROUBLESHOOTING GUIDELINES TO AVOID UNDESIRED EFFECTS INTRODUCTION ADVANTAGES OF THE EYE-LCD SERIES OVER OTHER TECHNOLOGIES THE LCD/TFT TECHNOLOGY OF THE EYE-LCD SERIES: EVALUATION OF VISUAL RANGE FAILURE OF PIXEL POLLUTIONS OVERVIEW ACCEPTABLE TOTAL NUMBER OF DOT DEFECTS CHRONOLOGICAL EFFECTS SUMMARY HOW TO MINIMIZE THE DANGER OF IMAGE RETENTION WARRANTY TERMS AND CONDITIONS...
  • Page 5 EYE-LCD-4600/5500-LE-700 EYE-LCD-4600/5500-LE-700 Revision History Page / Version Date Description section 2013-11 Specification first issued.

  • Page 6: About This Manual

    EYE-LCD-4600/5500-LE-700 ABOUT THIS MANUAL Read and pay attention to this manual. It contains important information on the product. In particular, note all of the safety instructions and warnings. Keep this manual in a safe place! WARNINGS USED NOTICE Indicates a hazard that could lead to damage or destruction of the product. The general warning symbol indicates a hazard that could lead to injuries or death.
  • Page 7 EYE-LCD-4600/5500-LE-700 ZU DIESEM HANDBUCH Lesen und beachten Sie diese Handbuch. Darin stehen wichtige Informationen zum Produkt. Beachten Sie insbesondere alle Sicherheits- und Warnhinweise. Bewahren Sie diese Anleitung sorgfältig auf! VERWENDETE WARNHINWEISE ACHTUNG Kennzeichnet eine Gefahr, die zur Beschädigung oder Zerstörung des Produkts führen kann.
  • Page 8 EYE-LCD-4600/5500-LE-700 À PROPOS DE CE MANUEL Lisez et suivez ces instructions. Ils contient des informations importantes sur le produit. Faites particulièrement attention à toutes les consignes de sécurité et aux avertissements. Conservez ce manuel soigneusement! DES SYMBOLES D`AVERTISSEMENT UTILISÉS ATTENTION! Indique un danger qui peut endommager ou détruire le produit.

  • Page 9: Safety/Sicherheit/Sécurité

    EYE-LCD-4600/5500-LE-700 SAFETY/Sicherheit/SÉCURITÉ SAFETY PRECAUTION Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product.
  • Page 10 EYE-LCD-4600/5500-LE-700 • When the power cord or plug is damaged. • When a liquid was spilled on the product or when objects have fallen into the product. • When the product has been exposed to rain or water. • When the product does not operate properly as described in the operating instructions.
  • Page 11 If dust collects inside the monitor, it may lead to excessive heat, outbreak of fire, or malfunction. Please request a cleaning of the inside of the monitor from an authorized Eyevis servicing dealer or service centre.
  • Page 12 EYE-LCD-4600/5500-LE-700 THE POWER CORD Do not damage the power cord nor place heavy objects on it, stretch it or over bend it. Also, do not add extension cords. Damage to the cord may result in fire or electric shock. Use only the power cord supplied with the monitor. Do not use the power cord with a power tap.
  • Page 13 EYE-LCD-4600/5500-LE-700 NOTICE! This is a class A product according EN 55022: 2010. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate counter measures. NOTICE! To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: PC/AV DVI-D output terminal, PC/AV DVI-D input terminal, PC/AV HDMI input terminal, PC D-SUB input terminal, PC RGB input terminals, and...

  • Page 14: Sicherheitsvorkehrungen

    EYE-LCD-4600/5500-LE-700 SICHERHEITSVORKEHRUNGEN Elektrizität erfüllt viele nützliche Aufgaben, kann aber auch Personen- und Sachschäden verursachen, wenn sie unsachgemäß gehandhabt wird. Dieses Produkt wurde mit Sicherheit als oberster Priorität konstruiert und hergestellt. Dennoch besteht bei unsachgemäßer Handhabung u.U. Stromschlag- und Brandgefahr. Um mögliche Gefahren zu vermeiden, befolgen Sie beim Aufstellen, Betreiben und Reinigen des Produkts bitte die nachstehenden Anleitungen.
  • Page 15 EYE-LCD-4600/5500-LE-700 Wartung — Versuchen Sie auf keinen Fall, selbst Wartungsarbeiten am Gerät durchzuführen. Durch das Entfernen von Abdeckungen setzen Sie sich hohen Spannungen und anderen Gefahren aus. Lassen Sie sämtliche Wartungsarbeiten ausschließlich von qualifiziertem Service-Personal ausführen. Reparaturen — Ziehen Sie in den folgenden Situationen sofort das Netzkabel und lassen Sie das Produkt von qualifiziertem Service-Personal reparieren: •...
  • Page 16 Vermeiden Sie es, den Monitor mit harten Gegenständen abzureiben oder zu berühren. Wir bitten um Ihr Verständnis, dass eyevis über die gesetzlich anerkannte Leistungshaftung hinaus keine Haftung für Fehler übernimmt, die sich aus der Verwendung durch den Kunden oder einen Dritten ergeben, und auch nicht für sonstige Funktionsstörungen oder Schäden, die während der...
  • Page 17 Staub im Inneren des Monitors ansammelt, kann es zu einer Überhitzung des Geräts und in der Folge zu einem Brand oder Fehlfunktionen kommen. Bitte lassen Sie das Innere des Monitors von einem autorisierten eyevis-Händler oder einem eyevis Servicecenter reinigen. Bilder können auf diesem Monitor nicht gedreht werden. Wenn Sie den Monitor in vertikaler Ausrichtung verwenden, müssen Sie die Bilder zuvor...
  • Page 18 EYE-LCD-4600/5500-LE-700 ACHTUNG! Dieses Gerät ist ein Produkt der Klasse A gemäß EN 55022: 2010. In Wohnräumen kann dieses Gerät Störsignale erzeugen, die durch entsprechende Abhilfemaßnahmen durch den Benutzer beseitigt werden müssen. ACHTUNG! Verwenden Sie EMV-gerechte, abgeschirmte Kabel, um die folgenden Anschlüsse zu verbinden: PC/AV DVI-D-Ausgangsanschluss, PC/AV DVI-D-Eingangsanschluss, PC/AV HDMI-Eingangsanschluss, PC D-sub-Eingangsanschluss, PCRGB-...

  • Page 19: Précautions De Sécurité

    EYE-LCD-4600/5500-LE-700 PRÉCAUTIONS DE SÉCURITÉ L’électricité remplit de nombreuses fonctions utiles, mais elle peut provoquer des blessures et des dégâts matériels si elle n’est pas utilisée correctement. Cet appareil a été conçu et fabriqué en attachant la plus grande importance à la sécurité.
  • Page 20 EYE-LCD-4600/5500-LE-700 Réparation — Dans les cas suivants, débranchez le cordon d’alimentation au niveau de la prise secteur et demandez à un personnel qualifié d’effectuer les réparations. • Dégât sur le cordon ou la prise de courant. • Infiltration d’un liquide ou pénétration d’un objet à l’intérieur de l’appareil. •...
  • Page 21 Ne frottez pas, ne grattez pas le moniteur avec un objet dur. Il faut savoir que la Eyevis décline toute responsabilité en cas d’erreurs commises durant l’utilisation par le client ou par une tierce personne, ainsi qu’en cas de dysfonctionnement ou de dommage survenu à...
  • Page 22 EYE-LCD-4600/5500-LE-700 LE CORDON D’ALIMENTATION N’endommagez pas le cordon d’alimentation, ne déposez pas d’objets lourds sur le cordon d’alimentation, ne tirez pas dessus et ne le pliez pas de manière excessive. De même, n’ajoutez pas de rallonges. Tout endommagement du cordon d’alimentation peut provoquer un début d’incendie ou un choc électrique.
  • Page 23 EYE-LCD-4600/5500-LE-700 ATTENTION! Ce produit appartient à la Classe A d‘après la norme EN 55022: 2010. Dans un environnement résidentiel, il peut provoquer des interférences radio et, dans ce cas, l’utilisateur peut être obligé de prendre les mesures nécessaires. ATTENTION! Afin de satisfaire aux normes EMC, utiliser des câbles blindés pour connecter les bornes suivantes : Borne de sortie PC/AV DVI-D, borne d’entrée PC/AV DVI-D, borne d’entrée PC/ AV HDMI, borne d’entrée PC D-sub, bornes d’entrée PC RVB, et bornes...

  • Page 24: Features

    EYE-LCD-4600/5500-LE-700 Features This monitor supports a 1920 x 1080 HDTV format and can display true 1.073 billion colours. It also provides the optimised 120 Hz frame rate. It supports a full range of interface types, including: DisplayPort, HDMI, VGA, DVI, Component video, S-video, Composite video, Audio in, Audio line out, IR extender and RS232.

  • Page 25: Packing Contents

    EYE-LCD-4600/5500-LE-700 Packing Contents Unpacking • EYE-LCD-Series display is packed in a carton box and may be banded to 2 types of custom pallet depends on the number of units shipped. The EYE- LCD-Series display is packed using cushions to protect the monitor during shipping.
  • Page 26 EYE-LCD-4600/5500-LE-700 contents of the Accessory Box Item Q’ty Power cord VGA Cable-Black IR Extender Remote Control Batteries Power Cord –black IR Extender VGA Cable (D-sub) OSD Remote Control 2 piece batteries (AAA) inside. VCOM LAN Driver (included with Ethernet option) See “Appendix”...

  • Page 27: Connectors

    EYE-LCD-4600/5500-LE-700 Connectors Environmental State When operating the eyevis monitor, ambient room conditions should not exceed the following: • Operating temperature: 5°C to 35°C (41°F to 95°F) • Humidity : less than 75% RH (Max) Main Power Switch and AC Inlet The included power cord is used to connect the side controls of the LCD monitor and the wall outlet.

  • Page 28: Input And Output Connectors

    EYE-LCD-4600/5500-LE-700 Input and Output Connectors Name Connector Remarks RS232C input x1 D-Sub 9 pin Communication Port LAN input x1 RJ-45 Communication Port RS485 in/out x1 RJ-45 Communication Port (Option) DisplayPort HDMI 1 input HDMI 2 input DVI-D input x1 D-Sub 24 pin VGA (PC) input x1 D-Sub 15 pin PC audio in...

  • Page 29: Operating The Monitor

    EYE-LCD-4600/5500-LE-700 Operating The Monitor Setup Process Step 1. Plug in the power cable and turn on the AC power switch (without turning on the signal source device(s)). “ I “ is power on “O” is power off Step 2. Plug in the signal source cables. Step 3.

  • Page 30: Turning Monitor On And Off

    EYE-LCD-4600/5500-LE-700 Turning Monitor On and Off Turning the monitor on • Connect the monitor to an AC power outlet • Ensure the AC switch is set to “ON“. • Press the power button on the remote control or keypad. Turning the monitor off If the monitor is switched on, press the power button on the remote control or keypad to put the monitor into standby mode.

  • Page 31: Osd Keypad Function List

    EYE-LCD-4600/5500-LE-700 OSD Keypad Function List Description Power Standby button Source Source selection; Activate selection ► Menu right / Value increasing ◄ Menu left / Value decreasing ▲ Menu up ▼ Menu down Menu / Exit Menu/Exit selection The LED Indicate Status 3 Power ON-Stand by Indicator 3 Remote Control Receiver Power Status...

  • Page 32: Avoiding Image Retention

    EYE-LCD-4600/5500-LE-700 Avoiding Image Retention Fixed images displayed over a long periods of time may cause image “burn-in” or image retention. Image retention is not covered under warranty. Follow the recommendations below to avoid image retention. Operate display within its rated ambient environment •...

  • Page 33: Remote Control

    EYE-LCD-4600/5500-LE-700 Remote control ON/OFF Turns the monitor on and off INFO Provides source and resolution information Selects the PC RGB source Selects the PC DVI source HDMI 1 Selects the HDMI 1 source COMP Not available at this model. AV (VIDEO ) Not available at this model.

  • Page 34: Changing The Remote Control Batteries

    EYE-LCD-4600/5500-LE-700 Changing the Remote Control Batteries Remove the battery cover Slide back and remove the battery cover in the direction of the arrow. Insert the batteries Align and insert two AAA batteries according to their plus and minus ports (as indicated on the button of the battery case of the remote control).

  • Page 35: Using Pip (Picture-In-Picture) Mode

    EYE-LCD-4600/5500-LE-700 Using PIP (Picture-in-Picture) Mode Select the main source – Using the remote, press the desired source button (VGA, HDMI1, HDMI2, DVI, DisplayPort, Composite Video (Video), S-V, or Component). Turn on PIP: Using the remote, press PIP. Main Large PIP Medium PIP Small PIP To select the PIP/ sub-source: Using the remote, press P-SOURCE and use...
  • Page 36 EYE-LCD-4600/5500-LE-700 Note: For additional PIP functionality, press MENU and navigate to the Display Settings menu. Use the arrow buttons (▼▲) to navigate to the desired PIP feature and press ENTER. Press ► to toggle through the associated options and press ENTER to select the highlighted option. Main Sub Source Side by Side (Picture-by-Picture): Press P-POSITION button choose “Side by...

  • Page 37: Using The Menus

    EYE-LCD-4600/5500-LE-700 Using the Menus Navigating through the Menu System • The Image Settings menu will display by pressing the MENU button. • Use ▲, ▼, ◄, ► and ENTER to navigate through the menus and adjust options. • Press MENU to return to the previous menu. •...
  • Page 38 EYE-LCD-4600/5500-LE-700 Audio Settings Basic Settings RTC Setup Advanced Settings Network Setup Video Wall Setup (Optional) System Status...
  • Page 39 EYE-LCD-4600/5500-LE-700 Image settings Menu This menu is used for making common image adjustments. Selects a predefined preset of image adjustment. Press ◄ or ► to select one of the following: Scheme Options: User, Vivid, Cinema, Game, Sport (Default: User) Increases or decreases the brightness of image. Press ◄...
  • Page 40 EYE-LCD-4600/5500-LE-700 Image settings Menu (continued) Gamma Options: Off, 2.2 (Default: 2.2) Adjusts the colour temperature of the image. Press ◄ or ►, select the desired temperature, and then press ENTER. Color Temp Options: User, 5000K, 6500K, 7500K and 9300K (Default: 9300K) Set Colour Temperature to “User Mode”...
  • Page 41 EYE-LCD-4600/5500-LE-700 Display settings Menu This menu is used for common source adjustments. Main Selects a predefined preset of image adjustment. Press ◄ or ► to select one of the following options: Aspect Ratio Options: Full screen, Pillar Box, Letter Box ,Native (Default: Full screen) Increases or decreases the zoom of image.

  • Page 42: Audio Settings Menu

    EYE-LCD-4600/5500-LE-700 Audio settings Menu This menu is used for adjusting volume settings. Adjusts the sound. Press ◄ or ►, select the desired level, and then press ENTER. Volume Range: 0~100 (Default: 50) Adjusts the sound in low tones (Bass). Press ◄ or ►, select the desired level, and then press ENTER. Bass Range: 0~20 (Default: 10) Adjusts the high tones (treble).
  • Page 43 EYE-LCD-4600/5500-LE-700 Basic Settings Menu This menu is used to make initial set-up adjustments to the OSD (On-Screen Display) menu and other On-Screen messages. Sets the menu transparency. Press ◄ or ► to select the desired level and then press ENTER. OSD Transparent Range: 0~100 (Default: 0) Adjusts the menu location on the monitor.
  • Page 44 EYE-LCD-4600/5500-LE-700 Basic settings menu (continued) Current time setting Current Time Year / Month / Date, Hour: Minutes Power on timer setup Options: User / Same Settings On All / Same Settings On Work Days. Default: Same Settings On All • User: Select the power on/off timer and specify the on/off times for each day of the week.
  • Page 45 EYE-LCD-4600/5500-LE-700 Advanced Settings Menu This menu is used for adjusting advanced settings. Forces the monitor to reacquire and lock to the input signal. This is useful Auto Adjustment when the signal quality is marginal. Note: This feature does not continually reacquire the signal.
  • Page 46 EYE-LCD-4600/5500-LE-700 Advanced Settings Menu (Network Setup) This menu is used for adjusting network settings. Enables network feature. Press ◄ or ► to enable or disable the network and then press ENTER. Enable Network Options: No, Yes (Default: No) Enables Dynamic IP mode. Press ◄...
  • Page 47 EYE-LCD-4600/5500-LE-700 Advanced Settings Menu (Video Wall Setup: option) This menu is used for adjusting video wall settings. Sets the Monitor ID from 1 to 25 Press ◄ or ► to set the monitor ID and then press ENTER. Monitor ID Options: 1~25 Enables or disable video wall function - setup the one image across multiple displays.

  • Page 48: User Analog Display Converter (Adc) Calibration

    EYE-LCD-4600/5500-LE-700 System Status Menu This read-only menu provides information on the active sources and the installed firmware version. User Analog display Converter (ADC) Calibration ► When using VGA as signal source, go to Advanced Settings in OSD menu and select VGA ADC Settings, then choose User ADC Calibration. A warning message (see image below) will show to make sure proper image is displayed on screen before ADC calibration begins Image in the green boxes, displayed on both side of the screen, has to be...

  • Page 49: Wake Up From Sleep (Wod)

    EYE-LCD-4600/5500-LE-700 Wake Up from Sleep (WOD) By default, the display will enter power saving (Sleep Mode) if no signal is received for 5 minutes. Normally, the RS-232, DisplayPort, HDMI and DVI inputs are inactive in Sleep Mode, to save power. To change the behavior of Sleep Mode, change the “Wake up from Sleep”...

  • Page 50: Controlling One Or Several Monitors Using Rs232

    EYE-LCD-4600/5500-LE-700 Controlling One or Several Monitors using RS232 Overview All monitor functions that can be controlled using via the on-screen display (OSD) can also be controlled via the display’s RS232 serial interface. The monitor can also be turned on and off using the RS232 interface. For a full list of RS232 commands, consult your sales representative or service technician.

  • Page 51: Supported Timings

    EYE-LCD-4600/5500-LE-700 Supported Timings HD-SDi is an optional. 480i means supported 480i @ 60Hz (YPbPr). 576i means supported 576i @ 50Hz (YPbPr)

  • Page 52: Eye-Lcd-4600/5500-Le-700

    EYE-LCD-4600/5500-LE-700 Troubleshooting Before calling service personnel, please check the following chart for a possible cause to the trouble you are experiencing. ► Perform the adjustments according to chapter “Operating the Monitor” ► If the problem you have experienced isn’t described below or you can’t correct the problem, stop using the monitor and call service personnel or your dealer.

  • Page 53: Guidelines To Avoid Undesired Effects

    EYE-LCD-4600/5500-LE-700 Guidelines to avoid undesired effects Introduction Thanks to their flexible possibilities of usage, their minor space requirement and their reliable display performance the displays of the EYE-LCD Series have become more and more popular for a wide range of applications. The displays have been especially designed for the sophisticated use in professional long-time applications.

  • Page 54: Advantages Of The Eye-Lcd Series Over Other Technologies

    LCD/TFT technology. The LCD/TFT Technology of the EYE-LCD Series: The backlight used in eyevis LCD/TFT technology, consisting of either CCFL or LED, is placed behind several different filter layers and a polarisation filter. In...

  • Page 55: Evaluation Of Visual Range

    EYE-LCD-4600/5500-LE-700 Evaluation of visual range Failure of Pixel A image point (Pixel) consist 3 sub pixel with basic colour red, green and blue. The physical dimension of pixel (also called pixel pitch) differs depending on the model (look at the data sheet for more information). If a pixel failure is larger than 1/2 pixel, it counts as pixel failure according to definition.

  • Page 56: Overview Acceptable Total Number Of Dot Defects

    EYE-LCD-4600/5500-LE-700 Overview Acceptable Total Number of Dot Defects Acceptable total number of dot defects according to ISO 9241-301 for Class II panels: ACCEPTABLE TOTAL NUMBER OF DEFECT DOTS RESOLUTION (IN RELATION TO THE RESOLUTION) Defect type 1 Defect type 2 Defect type 3 Defect bright Defect black...

  • Page 57: Chronological Effects

    EYE-LCD-4600/5500-LE-700 Chronological Effects False installation or use of the display during operating time may bring forth undesirable partly visible effects. The intern structure of imaging part (panel) may be changed by outside influences with partly visible effects. “Image Sticking” This phenomenon which named alternatively “image retention”, „ghost image“, „memory effect“...

  • Page 58: How To Minimize The Danger Of Image Retention

    EYE-LCD-4600/5500-LE-700 How to minimize the Danger of Image Retention NOTICE! Reduce Ambient Temperature The ambient temperature and therefore the temperature inside the LCD display plays a decisive role for the appearance of image retention. The risk of image retention increases the higher the surrounding temperature is.

  • Page 59: Warranty Terms And Conditions

    Return-to-Base-Warranty (Bring-In Warranty) Defective parts or products must be sent back carriage free to eyevis. In certain circumstances can the product sent back to the specialist supplier (place of purchase) or to eyevis service centre (land of purchase).

  • Page 60: Warranty Exclusions

    The reaction time to claim a right given by this warranty starts with the customer’s announcement of the claim to the eyevis GmbH. It is calculated in accordance to the standard service hours of the eyevis GmbH (Monday - Friday...

  • Page 61: Advised Procedure For Raising A Claim

    There are no express or implied warranties, representations or conditions other than those stated in this warranty. Other legal or contractual claims, also towards the seller of the product, are excluded as far as the eyevis GmbH has provided service based on this warranty.

  • Page 62: Limitations Of Liability

    EYE-LCD-4600/5500-LE-700 Limitations of Liability In cases of slight negligent breaches of duty the liability of the eyevis GmbH is limited to the direct, foreseeable and contract-typical average damage. The slightly negligent breach of minor contractual obligations excludes the liability. eyevis will not be liable for any loss, damage or alterations to (1) third party furniture, hardware or software;...

  • Page 63: Appendix

    EYE-LCD-4600/5500-LE-700 APPENDIX Appendix : Specification LCD PANEL Model Name: EYE-LCD-4600-LE-700 EYE-LCD-5500-LE-700 Panel Type: TFT Active Matrix Type LCD non-glare/haze Installation: Landscape / Portrait Screen Size: 46“ (ca. 116 cm) 55“ (ca. 139 cm) Active Display Area: 1018,08 × 572,67 mm (W × H) 1209,6 ×...

  • Page 64: Appendix : Dimensions Eye-Lcd-4600-Le-700

    EYE-LCD-4600/5500-LE-700 APPENDIX : DIMENSIONS EYE-LCD-4600-LE-700...

  • Page 65: Appendix : Dimensions Eye-Lcd-5500-Le-700

    EYE-LCD-4600/5500-LE-700 APPENDIX : DIMENSIONS EYE-LCD-5500-LE-700...

  • Page 66: Appendix : Package Handling

    EYE-LCD-4600/5500-LE-700 Appendix : Package Handling Moving the Monitor Moving the monitor requires at least two people. Attempting to move the monitor with one person may result in dropping the monitor and/or serious injury. When moving a monitor in its shipping carton, lift the carton using the white handles.

  • Page 67: Appendix : Installing The Table Stand Kit

    EYE-LCD-4600/5500-LE-700 Appendix : Installing the Table Stand Kit NOTICE Portrait Mode would be turn right from front side. For more information see chapter „Rotating the monitor“ Installing the Table Stand Kit Place the monitor (LCD screen face down) on a flat, stable surface, which has been covered with a soft cloth.

  • Page 68: Appendix : Installing The Wall Mount Kit

    EYE-LCD-4600/5500-LE-700 Appendix : Installing the wall mount kit 3 Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualified service personnel. 3 Moving the monitor requires at least two people. 3 Before installing, please make sure the wall is strong enough to hold the necessary weight of the display and the mount.

  • Page 69: Appendix : Wall Mount Safety Notes

    EYE-LCD-4600/5500-LE-700 Wall Mount Safety Notes Appendix : ...
  • Page 70 EYE-LCD-4600/5500-LE-700 ...

  • Page 71: Appendix : Controlling The Monitor Through Ethernet

    EYE-LCD-4600/5500-LE-700 Appendix : Controlling the Monitor through Ethernet Overview To control the monitor via an Ethernet (LAN) connection, the following steps need to be performed: 1. Check whether your monitor has the Ethernet option installed 2. Assign an IP address to the monitor 3.
  • Page 72 EYE-LCD-4600/5500-LE-700 Assigning an IP Address to the Monitor To assign an IP address to your monitor, access the Network Settings Menu under Advanced Settings -> Ethernet Setup (page 41). Consult your system administrator if you do not know how to configure the parameters shown in the menu.
  • Page 73 EYE-LCD-4600/5500-LE-700 Installing the VCOM Driver The virtual COM port driver simulates a serial interface on a PC. The data sent to this serial interface from any kind of application are forwarded to a connected EYE-LCD-4600/5500-LE-700 monitor via a TCP/IP connection. The client PC used to control the monitors must be connected to the network and must be running Windows 2000, XP, Vista or 7.
  • Page 74 EYE-LCD-4600/5500-LE-700 The monitor(s) connected to the network should appear as devices in the VCOM screen. Assign the designed COM value to each device and press “OK” to complete. Once this process is complete, the client computer can control the monitor(s) using RS-232 commands sent to the virtual COM port assigned to each monitor.

  • Page 75: Appendix : Rs232 Protocol

    EYE-LCD-4600/5500-LE-700 Appendix : RS232 Protocol RS232 Command Format • STX(1byte) + IDT(1byte) + Type(1byte) + CMD(3bytes) + [Value/ Reply(1byte)] + ETX(1byte) • STX : Start byte = 07 • IDT : 01~19 (Hex Num) for single control mode. 00 (Hex Num) for broadcast mode (Only for Video Wall).
  • Page 76 EYE-LCD-4600/5500-LE-700 Main Control Value Type Reply (DEC) Content Remark Item Item (DEC) (HEX) 0~100 Current value Back Light Brightness 42 52 49 0~100 Current value Digital Brightness Level 42 52 4C Off (Back Light) 42 4C 43 On (Back Light) 0~100 Current value Contrast...
  • Page 77 EYE-LCD-4600/5500-LE-700 Main Control Value Type Reply (DEC) Content Remark Item Item (DEC) (HEX) Native Fill 41 53 50 PILAR Box Scaling Letter Box Zoom in 54 4F 4D Zoom out 115200 38400 Baud Rate 42 52 41 Adjustment 19200 9600 MENU Key INFO Key UP Key...
  • Page 78 EYE-LCD-4600/5500-LE-700 Main Control Value Type Reply (DEC) Content Remark Item Item (DEC) (HEX) Video Wall Frameless Off 56 57 46 Video Wall Frameless On Matrix X, Y value X : 1~5 Current value High quarter is X : 7 ~ 4 bit 4D 41 54 Y : 1~5 Low quarter is Y : 3 ~ 0 bit...
  • Page 79 EYE-LCD-4600/5500-LE-700 Main Control Value Type Reply (DEC) Content Remark Item Item (DEC) (HEX) 0~23 0~23 Tuesday On Hour 49 4E 48 0~59 0~59 Tuesday On Minute 53 4E 4D Tuesday 0~23 0~23 Tuesday On Hour 53 46 48 0~59 0~59 Tuesday On Minute 53 46 4D 0~23...
  • Page 80 EYE-LCD-4600/5500-LE-700 Example: Power Control and Input Source Turn (01) monitor power off [CMD: POW] [Transmit] : PC → 07 01 02 50 4F 57 00 08 → Monitor [Return] : Monitor → 07 01 00 50 4F 57 00 08 → PC Turn (01) monitor power on [CMD: POW] [Transmit] : PC →...
  • Page 81 Notes/Notizen:...
  • Page 82 D-72766 Reutlingen Germany Tel: +49 (0) 7121 / 43303-0 Tel: +49 (0) 7121 / 43303-291 (Service Hotline) Fax: +49 (0) 7121 / 43303-22 E-Mail: info@eyevis.de www: www.eyevis.de Version: 1.0 | November 2013 Copyright © 2013 eyevis GmbH. All rights reserved.
